Problems with the printing quality

Printing is faint ................................................................................................................................................. 861

Paper rubs against the printhead .................................................................................................................... 862
The edges of the paper are dirty ..................................................................................................................... 863
The surface of the paper is dirty ...................................................................................................................... 863
The back side of the paper is dirty .................................................................................................................. 864
Printed colors are inaccurate ........................................................................................................................... 864
Banding in different colors occurs ................................................................................................................... 865
Colors in printed images are uneven ............................................................................................................... 865
Image Edges are Blurred or White Banding Occurs ....................................................................................... 866
Setting the Blue Switch on the Platen ......................................................................................................... 867
The contrast becomes uneven during printing ................................................................................................ 870
The length of printed images is inaccurate ...................................................................................................... 870
Documents are printed crooked ...................................................................................................................... 870
Documents are printed in monochrome .......................................................................................................... 870
Line thickness is not uniform ........................................................................................................................... 871
Lines are misaligned ....................................................................................................................................... 871
Problems with the printing quality caused by the type of paper ...................................................................... 872
Printing is faint
Cause
You may be printing on the wrong
side of the paper.
The Printhead nozzles are clogged.
Because the printer was left without
ink tanks installed for some time,
ink has become clogged in the ink
supply system.
Paper is jammed inside the Top
Cover.
During borderless printing, the ink
was not dry enough before cutting.
Printing may be faint if Print Qual-
ity in Advanced Settings in the
printer driver is set to Standard or
Draft.
iPF825
Troubleshooting
Print on the printing surface.
Print a test pattern to check the nozzles and see if they are clogged.
(See "Checking for Nozzle Clogging.")
After the ink tanks have been installed for 24 hours, run Head Cleaning B.
(See "Cleaning the Printhead.")
Follow the steps below to remove the jammed piece of paper inside the Top
Cover.
1. Press the Online button to bring the printer offline.
2. Open the Top Cover and make sure the Carriage is not over the Platen.
3. Remove any scraps of paper inside the Top Cover.
(See "Clearing Jammed Roll Paper.")
(See "Clearing a Jammed Sheet.")
4. Close the Top Cover.
Specify a longer drying period in the printer menu, in Roll DryingTime in Pa-
per Details.
(See "Main Menu Settings.")
In Advanced Settings of the printer driver, choose Highest or High in Print
Quality.
Printing in Draft or Standard mode is faster and consumes less ink than in
Highest or High modes, but the printing quality is lower.
> Problems with the printing quality
Corrective Action
→P.813
→P.815
→P.847
→P.851
→P.730
>
12
861
Printing is faint
