B
Settings on [Contact input] window (for room
sub stations only)
Make settings for contact input.
•
[Contact type]:
Select either Normally open (NO) or Normally closed (NC).
•
[Call priority/Answering the page]:
You can select the action of the station when detecting
input between 'calling with appropriate priority' and
'answering the page'.
Select "Normal", "Priority", "Urgent" or "Answering the
page".
•
Close
Click this to close the current window and return to the
previous window.
C
Settings on [Other] window
•
[Transmit volume boost at PTT]:
Select whether to increase the press-to-talk sound
volume transmitted to the stations (ON) or not (OFF).
•
[Camera zoom image preset] (video door stations
only):
Select the default of camera's Zoom/Wide function at
calling from the 9 zoom positions and "0" (wide) from the
pull-down menu.
•
[Call acknowledge tone on/off]:
Select whether to sound the call acknowledge tone of
door station or room sub station (ON) or not (OFF).
•
[Backlight adjustment] (video door stations only):
Select the method of adjusting the backlight in the
daytime between "Exposure +" and "Exposure –".
•
[Speaker] (room sub stations only):
Select the speaker to be used between "Built-in speaker"
and "External speaker".
When "External speaker" is selected, no sound will be
*
output from the built-in speaker.
•
Close
Click this to close the current window and return to the
previous window.
About the priority
When receiving two or more functions (communication, calling,
paging, monitoring, etc.) at the same time, depending on the
priority setting, the order of priority for them is as follows.
Priority
Setting
1 (high)
[Urgent]
2
[Priority]
3
[Normal]
4 (low)
-
Function
Communication, calling,
paging, chime paging
Monitoring, scan-monitoring
Making detailed settings to master
stations
The following setting item buttons are displayed in the
"Advanced settings" window.
Click either the button
*
corresponding setting window, and then make the
settings in the displayed window(s). See the detailed
instructions for D or E below.
Close to close the current window and return to
*
Click
the previous window.
D
Settings on [Stations to be scan monitored]
window
Set the scan-monitoring target sub station(s).
Up to 20 sub stations can be set.
*
1
Click
to open another window, then select
Reference
the target stations, and then click
the previous window.
The selected stations are added and displayed in the
list.
To delete a station (or stations) from the list, check the
*
target station(s) in the list and click Delete .
2
Repeat step
1 to register more stations.
3
Click
to close the current window and return to
Close
the previous window.
E
Settings on [Other] window
•
[Master station function: paging, chime, monitor,
door release, and remote site call]:
Select whether to enable the following functions of
master station (ON) or not (OFF).
•
Starting paging
•
Starting chime paging
•
Monitoring/scan-monitoring
•
Releasing door
•
Remote site call (standard (IP) system only)
•
Close
Click this to close the current window and return to the
previous window.
D
E
D or E to open the
Close
to return to
15
