Prestige 316
Broadband Sharing Gateway/Wireless LAN
User's Guide
Version 3.26
August 2001

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications Prestige 316

Summary of Contents for ZyXEL Communications Prestige 316

  • Page 1 Prestige 316 Broadband Sharing Gateway/Wireless LAN User’s Guide Version 3.26 August 2001...

  • Page 2: Copyright

    The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval system, translated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical, chemical, photocopying, guide, or otherwise, without the prior written permission of ZyXEL Communications Corporation.
  • Page 3 Prestige 316 Broadband Sharing Gateway/Wireless LAN Federal Communications Commission (FCC) Interference Statement This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operations.

  • Page 4: Information For Canadian Users

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Information for Canadian Users The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operation and safety requirements. The Industry Canada does not guarantee that the equipment will operate to a user's satisfaction.

  • Page 5: Declaration Of Conformity

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Declaration of Conformity We, the Manufacturer/Importer, ZyXEL Communications Corp. No. 6, Innovation Rd. II, Science-Based Industrial Park, Hsinchu, Taiwan, 300 R.O.C declare that the product Prestige 316 is in conformity with (reference to the specification under which conformity is declared)
  • Page 6 Prestige 316 Broadband Sharing Gateway/Wireless LAN Surge immunity test. 1995 • EN 61000-4-5 Immunity to conducted disturbances, induced by radio-frequency 1996 • EN 61000-4-6 fields. • Power magnetism test. 1993 EN 61000-4-8 • Voltage dips, short interruptions and voltage variations immunity...
  • Page 7 Prestige 316 Broadband Sharing Gateway/Wireless LAN...

  • Page 8: Zyxel Limited Warranty

    Prestige 316 Broadband Sharing Gateway/Wireless LAN ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two years from the date of purchase. During the warranty period, and upon...

  • Page 9: Customer Support

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Customer Support Please have the following information ready when you contact customer support. • Product model and serial number. • Information in Menu 24.2.1 – System Information. • Warranty Information. • Date that you received your device.

  • Page 11: Table Of Contents

    Prestige 316 Broadband Sharing Gateway / Wireless LAN Table of Contents Copyright ............................ii Federal Communications Commission (FCC) Interference Statement........iii Information for Canadian Users ....................iv ZyXEL Limited Warranty ......................viii Customer Support ........................ix List of Figures........................... xviii List Of Tables..........................xxiii Preface .............................xxvi...
  • Page 12 Prestige 316 Broadband Sharing Gateway / Wireless LAN 2.5.1 Initial Screen........................2-6 2.5.2 Prestige 316 SMT Menu Overview ................. 2-7 Navigating the SMT Interface ....................2-10 2.6.1 Main Menu ........................2-11 2.6.2 System Management Terminal Interface Summary............2-11 Changing the System Password..................... 2-12 Resetting the Prestige ......................
  • Page 13 Prestige 316 Broadband Sharing Gateway / Wireless LAN Internet Access Setup......................3-13 3.6.1 Ethernet Encapsulation ....................3-13 3.6.2 PPTP Encapsulation....................... 3-15 3.6.3 PPPoE Encapsulation..................... 3-16 Internet Test Setup ......................... 3-18 Basic Setup Complete ......................3-18 ADVANCED APPLICATIONS......................II Chapter 4 Remote Node Setup ....................4-1 Remote Node Profile .......................
  • Page 14 Prestige 316 Broadband Sharing Gateway / Wireless LAN NAT Setup..........................6-7 6.3.1 Address Mapping Sets ..................... 6-8 NAT Server Sets – Port Forwarding..................6-13 6.4.1 Configuring a Server behind NAT................. 6-14 General NAT Examples......................6-16 6.5.1 Internet Access Only ..................... 6-16 6.5.2...
  • Page 15 Prestige 316 Broadband Sharing Gateway / Wireless LAN SNMP Traps ..........................8-5 Chapter 9 System Information and Diagnosis ................9-1 System Status........................... 9-1 9.1.1 To get to the System Status:..................... 9-2 System Information and Console Port Speed................9-4 9.2.1 System Information......................9-4 9.2.2...
  • Page 16 Prestige 316 Broadband Sharing Gateway / Wireless LAN 10.3.3 Restore Via Console Port....................10-9 10.4 Uploading Firmware and Configuration Files ..............10-11 10.4.1 Firmware File Upload....................10-11 10.4.2 Configuration File Upload ................... 10-12 10.4.3 FTP File Upload Command from the DOS Prompt Example........10-12 10.4.4...
  • Page 17 Prestige 316 Broadband Sharing Gateway / Wireless LAN Chapter 13 Telnet Configuration and Capabilities..............13-1 13.1 About Telnet Configuration....................13-1 13.2 Telnet Under NAT ......................... 13-1 13.3 Telnet Capabilities ......................... 13-2 13.3.1 Single Administrator ...................... 13-2 13.3.2 System Timeout ......................13-2 TROUBLESHOOTING, APPENDICES, GLOSSARY AND INDEX..........IV...

  • Page 18: List Of Figures

    Figure 1-1 Internet Access via Cable with Wireless LAN Structure .............. 1-4 Figure 1-2 Internet Access via xDSL with Wireless LAN Structure .............. 1-4 Figure 2-1 Front Panel ........................... 2-1 Figure 2-2 Prestige 316 Rear Panel and Connections ..................2-3 Figure 2-3 Initial Screen..........................2-6 Figure 2-4 Password Screen........................... 2-6 Figure 2-5 Getting Started SMT Menu Overview..................
  • Page 19 Prestige 316 Broadband Sharing Gateway / Wireless LAN Figure 3-10 Menu 4 Using PPTP ......................... 3-16 Figure 3-11 Menu 4 Using PPPoE........................ 3-17 Figure 3-12 Sample Internet Setup Test ....................... 3-18 Figure 4-1 Menu 11.1 Remote Node Profile for Ethernet Encapsulation............4-2 Figure 4-3 Menu 11.1 Remote Node Profile for PPPoE Encapsulation ............
  • Page 20 Prestige 316 Broadband Sharing Gateway / Wireless LAN Figure 6-17 Example 3: Menu 11.3......................6-20 Figure 6-18 Example 3: Menu 15.1.1.1......................6-20 Figure 6-19 Example 3: Final Menu 15.1.1 ....................6-21 Figure 6-20 Example 3: Menu 15.2 ......................6-21 Figure 6-21 NAT Example 4 ........................6-22 Figure 6-22 Example 4: Menu 15.1.1.1 —...
  • Page 21 Prestige 316 Broadband Sharing Gateway / Wireless LAN Figure 9-4 Menu 24.2.1 System Maintenance – Information................. 9-5 Figure 9-5 Menu 24.2.2 – System Maintenance – Change Console Port Speed ..........9-6 Figure 9-6 Log and Trace ..........................9-7 Figure 9-7 Examples of Error and Information Messages................9-7 Figure 9-8 Menu 24.3.2 –...
  • Page 22 Prestige 316 Broadband Sharing Gateway / Wireless LAN Figure 11-1 Command Mode in Menu 24 .....................11-1 Figure 11-2 Valid CI Commands........................11-2 Figure 11-3 Call Control ..........................11-2 Figure 11-4 Budget Management........................11-3 Figure 11-5 Call History ..........................11-4 Figure 11-6 System Maintenance – Time and Date Setting ................11-5 Figure 11-7 Menu 24.11 –...
  • Page 23 Prestige 316 Broadband Sharing Gateway / Wireless LAN List Of Tables Table 1-1 Internet Access Configuration Checklist ..................1-5 Table 2-1 LED Functions..........................2-1 Table 2-2 Main Menu Commands ........................2-10 Table 2-3 Main Menu Summary ........................2-11 Table 2-4 General Setup Menu Fields ......................2-15 Table 2-5 Configure Dynamic DNS Menu Fields ..................2-17...
  • Page 24 Prestige 316 Broadband Sharing Gateway / Wireless LAN Table 6-2 NAT Mapping Types ........................6-5 Table 6-3 Applying NAT in Menus 4 & 11.3....................6-7 Table 6-4 SUA Address Mapping Rules ......................6-9 Table 6-5 Fields in Menu 15.1.1........................6-11 Table 6-6 Menu 15.1.1.1 —...
  • Page 25 Prestige 316 Broadband Sharing Gateway / Wireless LAN Table 11-3 Time and Date Setting Fields...................... 11-5 Table 11-4 Menu 24.11 – Remote Management Control ................11-7 Table 12-1 Schedule Set Setup Fields......................12-2 Table 14-1 Troubleshooting the Start-Up of your Prestige ................14-1 Table 14-2 Troubleshooting the LAN Interface ....................14-2...

  • Page 26: Preface

    About This User's Guide This guide is designed to guide you through the SMT configuration of your Prestige 316 for its various applications. Structure of this Guide This guide is structured as follows: Part I.

  • Page 27: Related Documentation

    For brevity’s sake, we will use “e.g.,” as a shorthand for “for instance” and “i.e.,” for “that is” or “in other words” throughout this guide. • The Prestige 316 may be referred to as the Prestige or the P316 in this guide. Occasionally, SMT screens may refer to the Prestige as a router. Preface...

  • Page 29: Getting Started

    Prestige 316 Broadband Sharing Gateway/Wireless LAN GETTING STARTED This part is structured as a step-by-step guide to help you connect, install and setup your Prestige to operate on your network and access the Internet.

  • Page 31: Chapter 1 Getting To Know Your Prestige

    Internet via Cable/xDSL modem or broadband router. By integrating NAT capability, the Prestige 316 provides not only ease of installation and Internet access, but also a complete security solution to protect your Intranet and efficiently manage data traffic on your network.

  • Page 32: Pppoe Support

    Prestige 316 Broadband Sharing Gateway/Wireless LAN PPPoE Support PPPoE facilitates the interaction of a host with a broadband modem to achieve access to high-speed data networks via a familiar "dial-up networking" user interface. PPTP Support Point-to-Point Tunneling Protocol (PPTP) is a network protocol that enables secure transfer of data from a remote client to a private server, creating a Virtual Private Network (VPN) using TCP/IP-based networks.

  • Page 33: Applications For Prestige 316

    1.3.1 Broadband Internet Access via Cable or xDSL Modem A cable modem or xDSL modem can connect to the Prestige 316 for broadband Internet access via Ethernet port on the modem. The Prestige provides high speed Internet access and secured internal network protection and management as well.

  • Page 34: Figure 1-1 Internet Access Via Cable With Wireless Lan Structure

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Figure 1-1 Internet Access via Cable with Wireless LAN Structure Figure 1-2 Internet Access via xDSL with Wireless LAN Structure You can also use your xDSL modem in the bridge mode for always-on Internet access and high speed data transfer.

  • Page 35: Internet Access Configuration Checklist

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Internet Access Configuration Checklist The following table shows the minimum SMT menu configurations you’ll need to make (without changing the default Prestige values) in order to access the Internet. Please also refer to the Support CD that contains HTML help on the embedded web configurator, our handy web-based Internet access wizard designed to get you up and running as soon as possible.

  • Page 37: Chapter 2 Hardware Installation And Initial Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 2 Hardware Installation and Initial Setup This chapter shows you how to connect the hardware and perform the initial setup. Front Panel LEDs and Back Panel Ports 2.1.1 Front Panel LEDs The LEDs on the front panel indicate the operational status of the Prestige.

  • Page 38: Prestige 316 Rear Panel And Connections

    The wireless LAN is not ready, or has failed. The wireless LAN is ready. Flashing The wireless LAN is sending/receiving packets. Prestige 316 Rear Panel and Connections The following figure shows the rear panel connections of your Prestige 316. Hardware Installation and Initial Setup...

  • Page 39: Figure 2-2 Prestige 316 Rear Panel And Connections

    Figure 2-2 Prestige 316 Rear Panel and Connections This section outlines how to connect your Prestige 316 to the LAN and the WAN. In the case of connecting a cable modem you must connect the coaxial cable from your cable service to the threaded coaxial cable connector on the back of the cable modem.
  • Page 40 Prestige 316 Broadband Sharing Gateway/Wireless LAN port) of your workstation. You can use an extension RS-232C cable if the enclosed one is too short. After the initial setup, you can modify the configuration remotely through telnet connections. Step 2. Connecting the Prestige to the Broadband Modem Step 2a.

  • Page 41: Additional Installation Requirements

    Prestige 316 Broadband Sharing Gateway/Wireless LAN The two ports of the Prestige on the LAN side (Ethernet LAN and Wireless LAN ports) can transparently communicate with each other since there is bridging function between the two ports. Additional Installation Requirements In addition to the contents of your package, there are other hardware and software requirements you need before you can install and use your Prestige.

  • Page 42: Starting Your Prestige

    When you power on your Prestige, it performs several internal tests as well as line initialization. After the tests, the Prestige asks you to press [ENTER] to continue, as shown next. Copyright (c) 1994 - 2001 ZyXEL Communications Corp. initialize ch =0, ethernet address: 00:a0:c5:f5:f5:f5...

  • Page 43: Prestige 316 Smt Menu Overview

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 2.5.2 Prestige 316 SMT Menu Overview The following figures give you an overview of the various SMT menu screens of your Prestige. Figure 2-5 Getting Started SMT Menu Overview Hardware Installation and Initial Setup...

  • Page 44: Figure 2-6 Advanced Applications Smt Menu Overview

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Figure 2-6 Advanced Applications SMT Menu Overview Hardware Installation and Initial Setup...

  • Page 45: Figure 2-7 Advanced Management Smt Menu Overview

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Figure 2-7 Advanced Management SMT Menu Overview Hardware Installation and Initial Setup...

  • Page 46: Navigating The Smt Interface

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Navigating the SMT Interface The SMT (System Management Terminal) is the interface that you use to configure your Prestige. Several operations that you should be familiar with before you attempt to modify the configuration are listed in the next table.

  • Page 47: Main Menu

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 2.6.1 Main Menu After you enter the password, the SMT displays the Prestige 316 Main Menu, as shown next. Copyright (c) 1994 - 2001 ZyXEL Communications Corp. Prestige 316 Main Menu Getting Started Advanced Management 1.

  • Page 48: Changing The System Password

    Prestige 316 Broadband Sharing Gateway/Wireless LAN MENU TITLE DESCRIPTION System Password Use this menu to set up a new password. System Maintenance This menu provides system status, diagnostics, firmware upload, etc. Schedule Setup This menu allows the Prestige to manage a remote node and dictate when a remote node should be called and for how long.

  • Page 49: Resetting The Prestige

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Resetting the Prestige If you have forgotten your password or for some reason cannot access the Prestige you will need to reinstall the configuration (rom) file. Uploading the configuration file replaces the current configuration file with the default configuration file, you will lose all configurations that you had before and the speed of the console port will be reset to the default of 9600bps with 8 data bit, no parity and 1 stop bit (8n1).

  • Page 50: General Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Continue to hold the RESET button. The PWR/SYS LED will begin to blink and flicker very quickly after about 10 or 15 seconds. This indicates that the defaults have been restored and the Prestige is now restarting.

  • Page 51: Dynamic Dns Basics

    IP address, allowing the host to be more easily accessible from various locations on the Internet. Usually, the Prestige 316 users are asked to use the WAN IP of the Prestige to access internal servers. If this IP is dynamic, it is inconvenient for the users. Now, you do not have to hunt for the IP address whenever you dial up your ISP.

  • Page 52: Configure Dynamic Dns

    Prestige 316 Broadband Sharing Gateway/Wireless LAN ask to speak to you. Similarly, every time your computer comes online, you tell the Dynamic DNS server what your current address is and other users will be sent to the right place using DNS.

  • Page 53: Wan Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Table 2-5 Configure Dynamic DNS Menu Fields FIELD DESCRIPTION EXAMPLE Service Provider This read-only field is the name of the dynamic DNS client. WWW.DynDNS.ORG Press the [SPACE BAR] to choose Yes to activate Dynamic...

  • Page 54: Figure 2-12 Menu 2 - Wan Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 2 - WAN Setup MAC Address: Assigned By= IP address attached on LAN IP Address= 192.168.1.12 Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle Figure 2-12 Menu 2 – WAN Setup The MAC address field allows users to configure the WAN port's MAC address by either using the factory default or cloning the MAC address from a workstation on your LAN.

  • Page 55: Lan Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 2.11 LAN Setup This section describes how to configure the LAN using Menu 3 – LAN Setup (10/100 Mbps Ethernet). From the main menu, enter 3 to open Menu 3. Menu 3 - LAN Setup 1.

  • Page 57: Chapter 3 Internet Access

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 3 Internet Access This chapter shows you how to configure the LAN as well as the WAN of your Prestige for Internet access. TCP/IP and DHCP for LAN The Prestige has built-in DHCP server capability that assigns IP addresses and DNS servers to systems that support DHCP client capability.

  • Page 58: Private Ip Addresses

    Prestige 316 Broadband Sharing Gateway/Wireless LAN addresses, from 192.168.1.1 to 192.168.1.254 (zero and 255 are reserved). In other words, the first 3 numbers specify the network number while the last number identifies an individual workstation on that network. Once you have decided on the network number, pick an IP address that is easy to remember, e.g., 192.168.1.1, for your Prestige, but make sure that no other device on your network is using that IP.

  • Page 59: Dhcp Configuration

    Prestige 316 Broadband Sharing Gateway/Wireless LAN or In Only, it will incorporate the RIP information that it receives; when set to None, it will not send any RIP packets and will ignore any RIP packets received. The Version field controls the format and the broadcasting method of the RIP packets that the Prestige sends (it recognizes both formats when receiving).

  • Page 60: Ip Multicast

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Example of network properties for LAN servers with fixed IP addresses: Choose an IP: 192.168.1.2 to 192.168.1.32; 192.168.1.65 to 192.168.1.254 Netmask: 255.255.255.0 Gateway (or default route): 192.168.1.1 (Prestige LAN IP) 3.1.6 IP Multicast Traditionally, IP packets are transmitted in two ways – unicast or broadcast. Multicast is a third way to deliver IP packets to a group of hosts.

  • Page 61: Figure 3-1 Menu 3 - Lan Setup (10/100 Mbps Ethernet)

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 3 – LAN Setup 1. LAN Port Filter Setup 2. TCP/IP and DHCP Setup 5. Wireless LAN Setup Enter Menu Selection Number: Figure 3-1 Menu 3 – LAN Setup (10/100 Mbps Ethernet) To edit the TCP/IP and DHCP configuration, enter 2 to open Menu 3.2 – TCP/IP and DHCP Ethernet Setup as shown next Menu 3.2 - TCP/IP and DHCP Ethernet Setup...

  • Page 62: Table 3-1 Lan Dhcp Setup Menu Fields

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Table 3-1 LAN DHCP Setup Menu Fields FIELD DESCRIPTION EXAMPLE This field enables/disables the DHCP server. If it is set to Server, Server (default) DHCP your Prestige will act as a DHCP server. If set to None, DHCP service will be disabled and you must have another DHCP sever on your LAN, or else the workstation must be manually configured.

  • Page 63: Ip Alias

    Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION EXAMPLE Multicast Turn on/off IGMP support by selecting from IGMP-v2/IGMP-v1/ None (default) None. Edit IP Alias Toggle [SPACE BAR] to choose Yes or No. No (default) When you have completed this menu, press [ENTER] at the prompt “Press ENTER to Confirm…” to save your configuration, or press [ESC] at any time to cancel.

  • Page 64: Figure 3-6 Menu 3.2.1 - Ip Alias Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 3.2 - TCP/IP and DHCP Ethernet Setup DHCP= Server Configuration: Client IP Pool Starting Address= N/A Size of Client IP Pool= N/A Primary DNS Server= N/A Secondary DNS Server= N/A DHCP Server Address TCP/IP Setup: IP Address= 192.168.1.1...

  • Page 65: Wireless Lan Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Table 3-3 IP Alias Setup Menu Fields FIELD DESCRIPTION EXAMPLE Choose Yes to configure the LAN network for the Prestige. IP Alias 1/2 IP Address Enter the IP address of your Prestige in dotted decimal notation.

  • Page 66: Figure 3-7 Menu 3.5 - Wireless Lan Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 3.5 – Wireless LAN Setup ESSID= Wireless Channel ID= CH01 2412MHz RTS Threshold= 2432 Frag. Threshold= 2432 WEP= Disable Default Key= N/A Key1= N/A Key2= N/A Key3= N/A Key4= N/A Edit MAC Address Filter= No Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle.
  • Page 67 (Wired Equivalent Privacy) To prevent unauthorized wireless stations from 64-bit WEP accessing data transmitted over the network, the Prestige 316 offers a data encryption, known as WEP to help encrypt wireless data transmitted via wireless medium. Disable allows wireless adapters to communicate with the Access Points without any data encryption.

  • Page 68: Wlan Mac Address Filter

    Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION EXAMPLE When you have completed this menu, press [ENTER] at the prompt “Press ENTER to Confirm…” to save your configuration, or press [ESC] at any time to cancel. The Prestige LAN Ethernet and wireless ports can transparently communicate with each other (transparent bridge).

  • Page 69: Internet Access Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Table 3-5 Menu 3.5.1 - WLAN MAC Address Filter FIELD DESCRIPTION EXAMPLE Press the [SPACE BAR] to select Yes to make the wireless LAN Active MAC address filter active. Press the [SPACE BAR] to select Allow Association or Deny...

  • Page 70: Figure 3-9 Menu 4 - Internet Access Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 4 - Internet Access Setup ISP's Name= myISP Encapsulation= Ethernet Service Type= Standard My Login= N/A My Password= N/A Login Server IP= N/A IP Address Assignment= Dynamic IP Address= N/A IP Subnet Mask= N/A...

  • Page 71: Pptp Encapsulation

    TCP/IP-based networks PPTP supports on-demand, multi-protocol and virtual private networking over public networks, such as the Internet. The Prestige 316 supports only one PPTP server connection at any given time. To configure a PPTP client, you must configure My Login and My Password fields for PPP connection and PPTP parameters for PPTP connection.

  • Page 72: Pppoe Encapsulation

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 4 - Internet Access Setup ISP's Name= myISP Encapsulation= PPTP Service Type= N/A My Login= My Password= ******** Idle Timeout= IP Address Assignment= Dynamic IP Address= N/A IP Subnet Mask= N/A Gateway IP Address= N/A...

  • Page 73: Figure 3-11 Menu 4 Using Pppoe

    Prestige 316 Broadband Sharing Gateway/Wireless LAN By implementing PPPoE directly on the Prestige 316 rather than individual PC’s, the machines on the LAN do not need PPPoE software installed, since the Prestige 316 does that part of the task. If you enable PPPoE in Menu 4, you will see the next screen. For more information on PPPoE, please see the Appendices.

  • Page 74: Internet Test Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Internet Test Setup After configuring the Menu 4 fields when you press [ENTER] to confirm you will see the message, "Do you wish to perform the Internet Setup Test [y/n]:" if you have chosen PPTP or PPPoE as your encapsulation method.

  • Page 75: Advanced Applications

    Advanced Applications ADVANCED APPLICATIONS Advanced Applications describe the advanced applications of your Prestige, such as Remote Node Setup IP Static routes and NAT.

  • Page 76: Chapter 4 Remote Node Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 4 Remote Node Setup This chapter shows you how to configure a remote node. A remote node is required for placing calls to a remote gateway. A remote node represents both the remote gateway and the network behind it across a WAN connection.

  • Page 77: Figure 4-1 Menu 11.1 Remote Node Profile For Ethernet Encapsulation

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 11.1 - Remote Node Profile Rem Node Name= LAoffice Route= IP Active= Yes Encapsulation= Ethernet Edit IP= No Service Type= Standard Session Options: Service Name= N/A Edit Filter Sets= No Outgoing: My Login= N/A...
  • Page 78 Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION EXAMPLES Outgoing: My Enter the password assigned by your ISP when the Prestige calls this ***** Password remote node. Valid for PPTP/PPPoE encapsulation only. Outgoing: Server This field is valid for RoadRunner service type only. The Prestige will find the RoadRunner Server IP automatically if this field is left blank.

  • Page 79: Table 4-2 Fields In Menu 11.1 (Pptp/Pppoe Encapsulation Specific Only)

    Prestige 316 Broadband Sharing Gateway/Wireless LAN The following table describes the fields NOT already described in Table 4-1 already. Table 4-2 Fields in Menu 11.1 (PPTP/PPPoE Encapsulation Specific Only) FIELD DESCRIPTION EXAMPLES Encapsulation Toggle [SPACE BAR] to choose PPTP/PPPoE. You must also go to PPTP/ Menu 11.3 to check the IP address setting once you have selected the...

  • Page 80: Pppoe Encapsulation

    Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION EXAMPLES Telco Option: This field specifies if you want to make the connection to this remote Nailed-Up node a nailed-up connection. For more details, please see ahead. Connection Session This value specifies the idle time (i.e., the length of time there is no traffic...

  • Page 81: Editing Tcp/Ip Options

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 11.1 - Remote Node Profile Rem Node Name= LAoffice Route= IP Active= Yes Encapsulation= PPPoE Edit IP= No Service Type= Standard Telco Option: Service Name= Allocated Budget(min)= 0 Outgoing= Period(hr)= 0 My Login=...

  • Page 82: Table 4-3 Remote Node Network Layer Options Menu Fields

    Prestige 316 Broadband Sharing Gateway/Wireless LAN The next table gives you instructions about configuring remote node network layer options. Table 4-3 Remote Node Network Layer Options Menu Fields FIELD DESCRIPTION EXAMPLE If your ISP did not assign you an explicit IP address, select Dynamic;...

  • Page 83: Pptp/Pppoe Encapsulation

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 4.2.2 PPTP/PPPoE Encapsulation Make sure that Encapsulation is set to PPTP/PPPoE in Menu 11.1. Move the cursor to the Edit IP field in Menu 11.1, then press [SPACE BAR] to toggle and set the value to Yes. Press [ENTER] to open Menu 11.3 –...

  • Page 84: Remote Node Filter

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Remote Node Filter Move the cursor to the field Edit Filter Sets in Menu 11.1, then press [SPACE BAR] to toggle and set the value to YES. Press [ENTER] to open Menu 11.5 – Remote Node Filter.

  • Page 86: Chapter 5 Ip Static Route Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 5 IP Static Route Setup This chapter shows you how to configure static routes with your Prestige. Static routes tell the Prestige routing information that it cannot learn automatically through other means. This can arise in cases where RIP is disabled on the LAN.

  • Page 87: Ip Static Route Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN IP Static Route Setup You configure IP static routes in Menu 12.1, by selecting one of the IP static routes as shown next. Enter 12 from the main menu. Menu 12 - IP Static Route Setup 1.

  • Page 88: Table 5-1 Ip Static Route Menu Fields

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Table 5-1 IP Static Route Menu Fields FIELD DESCRIPTION Route # This is the index number of the static route that you chose in Menu 12. Route Name Enter a descriptive name for this route. This is for identification purposes only.

  • Page 90: Chapter 6 Network Address Translation (Nat)

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 6 Network Address Translation (NAT) This chapter discusses how to configure NAT on the Prestige. Introduction NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet, e.g., the source address of an outgoing packet, used within one network to a different IP address...

  • Page 91: What Nat Does

    Prestige 316 Broadband Sharing Gateway/Wireless LAN NAT never changes the IP address (either local or global) of an outside host. 6.1.2 What NAT Does In the simplest form, NAT changes the source IP address in a packet received from a subscriber (the inside local address) to another (the inside global address) before forwarding the packet to the WAN side.

  • Page 92: Nat Application

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Figure 6-1 How NAT Works 6.1.4 NAT Application The following figure illustrates a possible NAT application, where three inside LANs (logical LANs using IP Alias) behind the Prestige can communicate with three distinct WAN networks. More examples follow at the...

  • Page 93: Nat Mapping Types

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Figure 6-2 NAT Application With IP Alias 6.1.5 NAT Mapping Types NAT supports five types of IP/port mapping. They are: One to One: In One-to-One mode, the Prestige maps one local IP address to one global IP address.

  • Page 94: Using Nat

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Server: This type allows you to specify inside servers of different services behind the NAT to be accessible to the outside world. Port numbers do not change for One-to-One and Many-to-Many-No Overload NAT mapping types.

  • Page 95: Applying Nat

    Prestige 316 Broadband Sharing Gateway/Wireless LAN The Prestige also supports Full Feature NAT to map multiple global IP addresses to multiple private LAN IP addresses of clients or servers using mapping types as outlined in Table 6-2. 1. Choose SUA Only if you have just one public WAN IP address for your Prestige.

  • Page 96: Nat Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 11.3 - Remote Node Network Layer Options IP Address Assignment= Dynamic IP Address= N/A IP Subnet Mask= N/A Gateway IP Addr= N/A Network Address Translation= Full Feature Metric= N/A Private= N/A RIP Direction= None...

  • Page 97: Address Mapping Sets

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 15 — NAT Setup Address Mapping Sets Server Set Enter Menu Selection Number: Figure 6-5 Menu 15 — NAT Setup 6.3.1 Address Mapping Sets Enter 1 to bring up Menu 15.1 — Address Mapping Sets.

  • Page 98: Figure 6-7 Menu 15.1.255 - Sua Address Mapping Rules

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 15.1.255 - Address Mapping Rules Set Name= SUA Local Start IP Local End IP Global Start IP Global End IP Type --------------- --------------- --------------- --------------- ------ 0.0.0.0 255.255.255.255 0.0.0.0 0.0.0.0 Server Press ENTER to Confirm or ESC to Cancel: Figure 6-7 Menu 15.1.255 —...
  • Page 99 Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION EXAMPLE Type These are the mapping types discussed above Server (see Table 6-2). Server allows us to specify multiple servers of different types behind NAT to this machine. See later for some examples.

  • Page 100: Table 6-5 Fields In Menu 15.1.1

    Prestige 316 Broadband Sharing Gateway/Wireless LAN ignored. If there are any empty rules before your new configured rule, your configured rule will be pushed up by that number of empty rules. For example, if you have already configured rules 1 to 6 in your current set and now you configure rule number 9.

  • Page 101: Figure 6-9 Menu 15.1.1.1 - Editing/Configuring An Individual Rule In A Set

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 15.1.1.1 Address Mapping Rule Type= One-to-One Local IP: Start= = N/A Global IP: Start= = N/A Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle. Figure 6-9 Menu 15.1.1.1 — Editing/Configuring an Individual Rule in a Set Table 6-6 Menu 15.1.1.1 —...

  • Page 102: Nat Server Sets - Port Forwarding

    Prestige 316 Broadband Sharing Gateway/Wireless LAN NAT Server Sets – Port Forwarding A NAT server set is a list of inside (behind NAT on the LAN) servers, for example, web or FTP, that you can make visible to the outside world even though NAT makes your whole inside network appear as a single machine to the outside world.

  • Page 103: Configuring A Server Behind Nat

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Table 6-7 Services & Port Numbers SERVICES PORT NUMBER ECHO FTP (File Transfer Protocol) Telnet SMTP (Simple Mail Transfer Protocol) DNS (Domain Name System) Finger HTTP (Hyper Text Transfer protocol or WWW, Web) POP3 (Post Office Protocol)

  • Page 104: Figure 6-10 Menu 15.2 - Nat Server Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 15.2 - NAT Server Setup Rule Start Port No. End Port No. IP Address --------------------------------------------------- Default Default 0.0.0.0 192.168.1.33 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 1026 1026 RR Reserved Press ENTER to Confirm or ESC to Cancel: Figure 6-10 Menu 15.2 —...

  • Page 105: Figure 6-12 Nat Example 1

    Prestige 316 Broadband Sharing Gateway/Wireless LAN General NAT Examples 6.5.1 Internet Access Only In the following Internet access example, you only need one rule where all your ILAs (Inside Local addresses) map to one dynamic IGA (Inside Global Address) assigned by your ISP.

  • Page 106: Figure 6-14 Nat Example 2

    Prestige 316 Broadband Sharing Gateway/Wireless LAN From menu 4 shown above, simply choose the SUA Only option from the Network Address Translation field. This is the Many-to-One mapping discussed in section 6.1.5. The SUA Only read-only option from the Network Address Translation field in menus 4 and 11.3 is specifically pre-configured to handle this case.

  • Page 107: Example 3: Multiple Public Ip Addresses With Inside Servers

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 15.2 - NAT Server Setup Rule Start Port No. End Port No. IP Address --------------------------------------------------- Default Default 192.168.1.10 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 1026 1026 RR Reserved Press ENTER to Confirm or ESC to Cancel: Figure 6-15 Menu 15.2 —...

  • Page 108: Figure 6-16 Nat Example 3

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Figure 6-16 NAT Example 3 Step 1. In this case you need to configure Address Mapping Set 1 from Menu 15.1 - Address Mapping Sets. Therefore you must choose the Full Feature option from the Network Address Translation field (in menu 4 or menu 11.3) in Figure 6-17.

  • Page 109: Figure 6-17 Example 3: Menu 11.3

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 11.3 - Remote Node Network Layer Options IP Address Assignment= Dynamic IP Address= N/A IP Subnet Mask= N/A Gateway IP Addr= N/A Network Address Translation= Full Feature Metric= N/A Private= N/A RIP Direction= None...

  • Page 110: Figure 6-19 Example 3: Final Menu 15.1.1

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 15.1.1 - Address Mapping Rules Set Name= Example3 Local Start IP Local End IP Global Start IP Global End IP Type --------------- --------------- --------------- --------------- ------ 1. 192.168.1.10 10.132.50.1 192.168.1.11 10.132.50.2 3. 0.0.0.0 255.255.255.255...

  • Page 111: Figure 6-21 Nat Example 4

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 6.5.4 Example 4: NAT Unfriendly Application Programs Some applications do not support NAT Mapping using TCP or UDP port address translation. In this case it is better to use Many-to-Many No Overload mapping as port numbers do not change for Many-to-Many No Overload (and One-to-One) NAT mapping types.

  • Page 112: Figure 6-22 Example 4: Menu 15.1.1.1 - Address Mapping Rule

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 15.1.1.1 Address Mapping Rule Type= Many-to-Many No Overload Local IP: Start= 192.168.1.10 = 192.168.1.12 Global IP: Start= 10.132.50.1 = 10.132.50.3 Press ENTER to Confirm or ESC to Cancel: Figure 6-22 Example 4: Menu 15.1.1.1 — Address Mapping Rule After you’ve configured your rule, you should be able to check the settings in menu 15.1.1 as shown next.

  • Page 113: Advanced Management

    Advanced Management ADVANCED MANAGEMENT Advanced Management provides information on Prestige Filtering, SNMP, System Information and Diagnosis, Firmware and Configuration Maintenance, System Maintenance and Management, Call Scheduling and Telnet.

  • Page 115: Chapter 7 Filter Configuration

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 7 Filter Configuration This chapter shows you how to create and apply filter(s). About Filtering Your Prestige uses filters to decide whether to allow passage of a data packet and/or to make a call. There are two types of filter applications: data filtering and call filtering.

  • Page 116: The Filter Structure Of The Prestige

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Call Filtering Active Data Built-in User-defined match match match Outgoing Initiate call default Call Filters Data Packet if line not up Call Filters (if applicable) Send packet and reset Idle Timer Match Match Match...

  • Page 117: Figure 7-2 Filter Rule Process

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Start Packet into filter Fetch First Filter Set Filter Set Fetch Next Fetch First Filter Set Filter Rule Fetch Next Filter Rule Next filter Next Filter Set Rule Active? Available? Available? Execute Filter Rule...

  • Page 118: Configuring A Filter Set

    Prestige 316 Broadband Sharing Gateway/Wireless LAN You can apply up to four filter sets to a particular port to block multiple types of packets. With each filter set having up to six rules, you can have a maximum of 24 rules active for a single port.

  • Page 119: Figure 7-4 Netbios_Wan Filter Rules Summary

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 21.1 - Filter Rules Summary # A Type Filter Rules M m n - - ---- -------------------------------------------- --------- - - - 1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=137 N D N 2 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=138...

  • Page 120: Filter Rules Summary Menu

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 7.2.1 Filter Rules Summary Menu This screen shows the summary of the existing rules in the filter set. The following table contains a brief description of the abbreviations used in the previous menus. Table 7-1 Abbreviations Used in the Filter Rules Summary Menu...

  • Page 121: Configuring A Filter Rule

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Source Port number Destination Address Destination Port number If the filter type is Gen (generic), the following abbreviations listed in the next table will be used. Table 7-3 Abbreviations Used if Filter Type is Gen...

  • Page 122: Figure 7-7 Menu 21.1.1 - Tcp/Ip Filter Rule

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 21.1.1 - TCP/IP Filter Rule Filter #: 1,1 Filter Type= TCP/IP Filter Rule Active= Yes IP Protocol= 6 IP Source Route= No Destination: IP Addr= 0.0.0.0 IP Mask= 0.0.0.0 Port #= 137 Port # Comp= Equal Source: IP Addr= 0.0.0.0...
  • Page 123 Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION OPTIONS Destination: Port Enter the destination port of the packets that you wish to 0 to 65535 filter. The range of this field is 0 to 65535. This field is disregarded if it is 0.
  • Page 124 Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION OPTIONS Once you have completed filling in Menu 21.1.1 – TCP/IP Filter Rule, press [ENTER] at the message “Press Enter to Confirm...” to save your configuration, or press [ESC] to cancel. This data will now be displayed on Menu 21.1 –...

  • Page 125: Figure 7-8 Executing An Ip Filter

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Packet into IP Filter Filter Active? Apply SrcAddrMask to Src Addr Check Src Not Matched IP Addr Matched Apply DestAddrMask to Dest Addr Check Dest Not Matched IP Addr Matched Check Not Matched IP Protocol Matched Check Src &...

  • Page 126: Generic Filter Rule

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 7.2.4 Generic Filter Rule This section shows you how to configure a generic filter rule. The purpose of generic rules is to allow you to filter non-IP packets. For IP, it is generally easier to use the IP rules directly.

  • Page 127: Table 7-5 Generic Filter Rule Menu Fields

    Prestige 316 Broadband Sharing Gateway/Wireless LAN The following table describes the fields in the Generic Filter Rule menu. Table 7-5 Generic Filter Rule Menu Fields FIELD DESCRIPTION OPTIONS Filter # This is the filter set, filter rule coordinates, i.e., 2,3 refers to the second filter set and the third rule of that set.

  • Page 128: Example Filter

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Once you have completed filling in Menu 21.x.1 – Generic Filter Rule, press [ENTER] at the message “Press Enter to Confirm...” to save your configuration, or press [ESC] to cancel. This data will now be displayed on Menu 21.1 –...

  • Page 129: Figure 7-11 Sample Filter - Menu 21.1.1

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Step 5. Enter 1 to configure the first filter rule (the only filter rule of this set). Make the entries in this menu as shown in the following figure. Press [SPACE BAR] to choose this filter rule type.

  • Page 130: Figure 7-12 Sample Filter Rules Summary – Menu 21.1.3

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 21.1.3 - Filter Rules Summary # A Type Filter Rules M m n - - ---- --------------------------------------------------------------- - - - 1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=23 N D F Enter Filter Rule Number (1-6) to Configure: 1 This shows you that you have M = N means an action can be taken immediately.

  • Page 131: Filter Types And Nat

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Filter Types and NAT There are two classes of filter rules, Generic Filter (Device) rules and Protocol Filter (TCP/IP) rules. Generic Filter rules act on the raw data from/to LAN and WAN. Protocol Filter rules act on the IP packets.

  • Page 132: Lan Traffic

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 7.5.1 LAN Traffic LAN traffic filter sets may be useful to block certain packets, reduce traffic and prevent security breaches. Go to Menu 3.1 (shown next) and enter the number(s) of the filter set(s) that you want to apply as appropriate.

  • Page 133: Figure 7-15 Filtering Remote Node Traffic (Pptp/Pppoe Encapsulation)

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 11.5 - Remote Node Filter Apply default filters 1, 3 Input Filter Sets: here. Enter 1 in protocol protocol filters= 3 device filters= filters under Output Filter Output Filter Sets: Sets when using Ethernet...

  • Page 135: Chapter 8 Snmp Configuration

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 8 SNMP Configuration This chapter discusses SNMP (Simple Network Management Protocol) for network management and monitoring. About SNMP SNMP (Simple Network Management Protocol) is a protocol used for exchanging management information between network devices. SNMP is a member of TCP/IP protocol suite. Your Prestige supports SNMP agent functionality, which allows a manager station to manage and monitor the Prestige through the network.

  • Page 136: Figure 8-1 Snmp Management Model

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Figure 8-1 SNMP Management Model An SNMP managed network consists of two main components: agents and a manager. An agent is a management software module that resides in a managed device (the Prestige). An agent translates the local management information from the managed device into a form compatible with SNMP.

  • Page 137: Supported Mibs

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Table 8-1 General SNMP Commands COMMAND DESCRIPTION Allows the manager to retrieve an object variable from the agent. GetNext Allows the manager to retrieve the next object variable from a table or list within an agent. In SNMPv1, when a manager wants to retrieve all elements of a table from an agent, it initiates a Get operation, followed by a series of GetNext operations.

  • Page 138: Figure 8-2 Menu 22 - Snmp Configuration

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 22 - SNMP Configuration SNMP: Get Community= public Set Community= public Trusted Host= 0.0.0.0 Trap: Community= public Destination= 0.0.0.0 Press ENTER to Confirm or ESC to Cancel: Figure 8-2 Menu 22 — SNMP Configuration The following table describes the SNMP configuration parameters.

  • Page 139: Snmp Traps

    Prestige 316 Broadband Sharing Gateway/Wireless LAN SNMP Traps The Prestige will send traps to the SNMP manager when any one of the following events occurs: Table 8-3 SNMP Traps TRAP # TRAP NAME DESCRIPTION coldStart (defined in RFC-1215) A trap is sent after booting (power on).

  • Page 141: Chapter 9 System Information And Diagnosis

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 9 System Information and Diagnosis This chapter talks you through SMT Menus 24.1 to 24.4. This chapter covers the diagnostic tools that help you to maintain your Prestige. These tools include updates on system status, port status, log and trace capabilities and upgrades for the system software. This chapter describes how to use these tools in detail.

  • Page 142: To Get To The System Status

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 9.1.1 To get to the System Status: • Enter 24 to go to Menu 24 – System Maintenance. • In this menu, enter number 1 to open System Maintenance – Status. • There are three commands in Menu 24.1 – System Maintenance – Status. Entering 1 drops the PPTP/PPPoE connection, 9 resets the counters and [ESC] takes you back to the previous screen.
  • Page 143 Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION Status Shows the port speed and duplex setting if you are using Ethernet Encapsulation and down (line is down), idle (line (PPP) idle), dial (starting to trigger a call) and drop (dropping a call) if you are using PPTP/PPPoE Encapsulation.

  • Page 144: System Information And Console Port Speed

    Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION Version You may enter 1 to drop the PPPoE/PPTP connection, 9 to reset the counters or [ESC] to return to menu System Information and Console Port Speed This section describes your system and allows you to choose different console port speeds. To get to Menu 24.2 - System Information and Console Port Speed:...

  • Page 145: Console Port Speed

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.2.1 - System Maintenance – Information Name: xxx.baboo.mickey.co Routing: IP ZyNOS F/W Version: V3.25(CB.0)b3 | 7/20/2001 Ethernet Address: 00:a0:c5:f5:f5:f5 IP Address: 192.168.1.1 IP Mask: 255.255.255.0 DHCP: Server Press ESC or ENTER to Exit Figure 9-4 Menu 24.2.1 System Maintenance –...

  • Page 146: Log And Trace

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.2.2 – System Maintenance – Change Console Port Speed Console Port Speed: 115200 Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle. Figure 9-5 Menu 24.2.2 – System Maintenance – Change Console Port Speed Log and Trace There are two logging facilities in the Prestige.

  • Page 147: Unix Syslog

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.3 - System Maintenance - Log and Trace 1. View Error Log 2. UNIX Syslog 4. Call-Triggering Packet Please enter selection Figure 9-6 Log and Trace Examples of typical error and information messages are presented in the next figure.

  • Page 148: Figure 9-8 Menu 24.3.2 - System Maintenance - Unix Syslog

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.3.2 -- System Maintenance - UNIX Syslog Syslog: Active= No Syslog IP Address= ? Log Facility= Local 1 Types: CDR= No Packet triggered= N/A Filter log= No PPP log= No Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle.
  • Page 149 Prestige 316 Broadband Sharing Gateway/Wireless LAN Your Prestige sends four types of syslog messages. Some examples (not Prestige 316 specific) of these syslog messages with their message formats are shown next: CDR Message Format SdcmdSyslogSend ( SYSLOG_CDR, SYSLOG_INFO, String );...
  • Page 150 Prestige 316 Broadband Sharing Gateway/Wireless LAN Packet Triggered Packet Triggered Message Format SdcmdSyslogSend ( SYSLOG_PKTTRI, SYSLOG_NOTICE, String ); String = Packet trigger: Protocol=xx Data=xxxxxxxxxx…..x Protocol: (1:IP 2:IPX 3:IPXHC 4:BPDU 5:ATALK 6:IPNG) Data: We will send forty-eight Hex characters to the server Jul 19 11:28:39 192.168.102.2 ZyXEL: Packet Trigger: Protocol=1,...

  • Page 151: Call-Triggering Packet

    Prestige 316 Broadband Sharing Gateway/Wireless LAN PPP Log PPP Log Message Format SdcmdSyslogSend ( SYSLOG_PPPLOG, SYSLOG_NOTICE, String ); String = ppp:Proto Starting / ppp:Proto Opening / ppp:Proto Closing / ppp:Proto Shutdown Proto = LCP / ATCP / BACP / BCP / CBCP / CCP / CHAP/ PAP / IPCP / IPXCP Jul 19 11:42:44 192.168.102.2 ZyXEL: ppp:LCP Closing...

  • Page 152: Diagnostic

    Prestige 316 Broadband Sharing Gateway/Wireless LAN IP Frame: ENET0-RECV Size: Time: 17:02:44.262 Frame Type: IP Header: IP Version Header Length = 20 Type of Service = 0x00 (0) Total Length = 0x002C (44) Identification = 0x0002 (2) Flags = 0x00...

  • Page 153: Wan Dhcp

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.4 - System Maintenance - Diagnostic TCP/IP 1. Ping Host 2. WAN DHCP Release 3. WAN DHCP Renewal 4. Internet Setup Test System 11. Reboot System Enter Menu Selection Number: Host IP Address= N/A Figure 9-10 Menu 24.4 –...

  • Page 154: Figure 9-11 Wan And Lan Dhcp

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Figure 9-11 WAN and LAN DHCP The following table describes the diagnostic tests available in menu 24.4 for your Prestige and the connections. Table 9-4 System Maintenance Menu Diagnostic NUMBER FIELD DESCRIPTION Ping Host Enter 1 to ping any machine (with an IP address) on your LAN or WAN.

  • Page 155: Chapter 10 Firmware And Configuration Maintenance

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 10 Firmware and Configuration Maintenance This chapter tells you how to back up and restore your configuration file as well as upload new firmware and a new configuration file. 10.1 Filename Conventions The configuration file (often called the romfile or rom-0) contains the factory default settings in the menus such as password, DHCP Setup, TCP/IP Setup, etc.

  • Page 156: Backup Configuration

    Prestige 316 Broadband Sharing Gateway/Wireless LAN have uploaded the correct firmware version. The AT command is the command you enter after you press “y” when prompted in the SMT menu to go into debug mode. Table 10-1 Filename Conventions FILE TYPE...

  • Page 157: Figure 10-1 Telnet Into Menu 24.5

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.5 - System Maintenance - Backup Configuration To transfer the configuration file to your workstation, follow the procedure below: 1. Launch the FTP client on your workstation. 2. Type "open" and the IP address of your router. Then type "root" and SMT password as requested.

  • Page 158: Example Of Ftp Commands From The Dos Prompt

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 10.2.3 Example of FTP Commands from the DOS Prompt 331 Enter PASS command Password: 230 Logged in ftp> bin 200 Type I OK ftp> get rom-0 zyxel.rom 200 Port command okay 150 Opening data connection for STOR ras 226 File received OK ftp: 16384 bytes sent in 1.10Seconds 297.89Kbytes/sec.

  • Page 159: Backup Configuration Using Tftp

    Prestige 316 Broadband Sharing Gateway/Wireless LAN • The IP address in the Secured Client IP field (menu 24.11) does not match the client IP address. If it does not match, the Prestige will disconnect the Telnet session immediately. • There is an SMT console session running.

  • Page 160: Third Party Tftp Clients

    Prestige 316 Broadband Sharing Gateway/Wireless LAN where “i” specifies binary image transfer mode (use this mode when transferring binary files), “host” is the Prestige IP address, “get” transfers the file source on the Prestige (rom-0 name of the configuration file on the Prestige) to the file destination on the computer and renames it config.rom.

  • Page 161: Restore Configuration

    Prestige 316 Broadband Sharing Gateway/Wireless LAN You can enter ctrl-x to terminate operation any time. Starting XMODEM download... Figure 10-4 System Maintenance — Starting Xmodem Download Screen Step 3. Run the HyperTerminal program by clicking Transfer, then Receive File as shown in the following screen.

  • Page 162: Figure 10-7Telnet Into Menu 24.6

    Prestige 316 Broadband Sharing Gateway/Wireless LAN FTP and TFTP are the preferred methods for restoring your current computer configuration to your Prestige since FTP and TFTP are faster. Please note that you must restart the system after the file transfer is complete.

  • Page 163: Restore Using Ftp Or Tftp Session Example

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Step 3. Press [ENTER] when prompted for a username. Step 4. Enter your password as requested (the default is “1234”). Step 5. Enter “bin” to set transfer mode to binary. Step 6. Find the “rom” file (on your computer) that you want to restore to your Prestige.

  • Page 164: Figure 10-10 System Maintenance - Starting Xmodem Download Screen

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Step 2. The following screen indicates that the Xmodem download has started. Starting XMODEM download (CRC mode) ... CCCCCCCCC Figure 10-10 System Maintenance — Starting Xmodem Download Screen Step 3. Run the HyperTerminal program by clicking Transfer, then Receive File as shown in the following screen.

  • Page 165: Uploading Firmware And Configuration Files

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 10.4 Uploading Firmware and Configuration Files This section shows you how to upload firmware and configuration files. You can upload configuration files by following the procedure in the previous Restore Configuration section or by following the instructions in Menu 24.7.2 - System Maintenance - Upload Router Configuration File (for console port).

  • Page 166: Configuration File Upload

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 10.4.2 Configuration File Upload You see the following screen when you telnet into menu 24.7.2. Menu 24.7.2 - System Maintenance - Upload System Configuration File To upload the system configuration file, follow the procedure below: 1.

  • Page 167: Ftp Session Example Of Firmware File Upload

    Prestige 316 Broadband Sharing Gateway/Wireless LAN file on the Prestige to your computer and renames it “config.rom.” See earlier in this chapter for more information on filename conventions. Step 7. Enter “quit” to exit the ftp prompt. 10.4.4 FTP Session Example of Firmware File Upload...

  • Page 168: Tftp Upload Command Example

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Step 3. Enter the command “sys stdio 0” to disable the console timeout, so the TFTP transfer will not be interrupted. Enter “command sys stdio 5” to restore the five-minute console timeout (default) when the file transfer is complete.

  • Page 169: Uploading A Firmware File Via Console Port

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 10.4.8 Uploading a Firmware File Via Console Port Step 1. Select 1 from Menu 24.7 – System Maintenance – Upload Firmware to display Menu 24.7.1 - System Maintenance - Upload Router Firmware, then follow the instructions as shown in the following screen.

  • Page 170: Uploading A Configuration File Via Console Port

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Type the firmware file’s location, or click Browse to look for it. Choose the Xmodem protocol. Then click Send. Figure 10-17 Example Xmodem Upload After the firmware upload process has completed, the Prestige will automatically restart.

  • Page 171: Example Xmodem Configuration Upload Using Hyperterminal

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.7.2 - System Maintenance - Upload Router Configuration File To upload router configuration file: 1. Enter "y" at the prompt below to go into debug mode. 2. Enter "atlc" after "Enter Debug Mode" message.

  • Page 172: Figure 10-19 Example Xmodem Upload

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Type the configuration file’s location, or click Browse to search for it. Choose the Xmodem protocol. Then click Send. Figure 10-19 Example Xmodem Upload After the configuration upload process has completed, restart the Prestige by entering “atgo”.

  • Page 173: Chapter 11 System Maintenance And Management

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 11 System Maintenance and Management This chapter leads you through SMT Menus 24.8 to 24.11. 11.1 Command Interpreter Mode This option allows you to enter command interpreter mode, a “DOS prompt” type command interface, which allows more advanced system diagnosis and troubleshooting (beyond the scope of this guide).

  • Page 174: Call Control Support

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Copyright (c) 1994 - 2001 ZyXEL Communications Corp. ras> ? Valid commands are: exit ether wlan bridge ras> Figure 11-2 Valid CI Commands 11.2 Call Control Support The Prestige provides two call control functions: budget management and call history. Please note that this menu is only applicable when Encapsulation is set to PPTP/PPPoE in menu 4 or menu 11.1.

  • Page 175: Call History

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.9.1 - Budget Management Remote Node Connection Time/Total Budget Elapsed Time/Total Period 1. Hinet No Budget No Budget Reset Node (0 to update screen): Figure 11-4 Budget Management The total budget is the time limit on the accumulated time for outgoing calls to a remote node. When this limit is reached, the call will be dropped and further outgoing calls to that remote node will be blocked.

  • Page 176: Time And Date Setting

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.9.2 - Call History Phone Number Rate #call Total Enter Entry to Delete (0 to exit): Figure 11-5 Call History Table 11-2 Call History Fields FIELD DESCRIPTION Phone Number The PPTP/PPPoE service names are shown here.

  • Page 177: How Often Does The Prestige Update The Time

    Prestige 316 Broadband Sharing Gateway/Wireless LAN How Often Does the Prestige Update the Time? 11.3.1 The Prestige updates the time in three instances: On leaving menu 24.10 after making changes. When the Prestige boots up and there is a time server configured in Menu 24.10.

  • Page 178: Remote Management Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION Use Time Server when Enter the time service protocol that your time server will send when the Bootup Prestige powers up. Choices are Daytime (RFC-867), Time (RFC-868), NTP (RFC-1305) and None. The main differences between them are the format, e.g., the Daytime (RFC-867) format is day/month/date/year/time zone of the...

  • Page 179: Figure 11-7 Menu 24.11 - Remote Management Control

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 24.11 - Remote Management Control TELNET Server: Server Port = 23 Server Access = WAN only Secured Client IP = 0.0.0.0 FTP Server: Server Port = 21 Server Access = LAN only Secured Client IP = 0.0.0.0...

  • Page 180: Remote Management Limitations

    Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION EXAMPLE Once you have filled in this menu, press [ENTER] at the message "Press ENTER to Confirm or ESC to Cancel" to save your configuration, or press [ESC] to cancel. 11.4.1 Remote Management Limitations Remote management over LAN or WAN will not work when: •...

  • Page 181: Figure 11-9 Boot Module Commands

    Prestige 316 Broadband Sharing Gateway/Wireless LAN ======= Debug Command Listing ======= just answer OK ATHE print help ATBAx change baudrate. 1:38.4k, 2:19.2k, 3:9.6k 4:57.6k 5:115.2k ATENx,(y) set BootExtension Debug Flag (y=password) ATSE show the seed of password generator ATTI(h,m,s) change system time to hour:min:sec or show current time...

  • Page 183: Chapter 12 Call Scheduling

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 12 Call Scheduling This chapter shows you how to set up call time periods for remote nodes. 12.1 Introduction The call scheduling feature allows the Prestige to manage a remote node and dictate when a remote node should be called and for how long.

  • Page 184: Schedule Set Setup

    Prestige 316 Broadband Sharing Gateway/Wireless LAN To delete a schedule set, choose the set number and either delete the name or press [SPACE BAR] once in Edit Name field and then press [ENTER] in the DELETE PROFILE field. 12.3 Schedule Set Setup To setup a schedule set, select the schedule set you want to setup from menu 26 (1-12), press [ENTER] and then type in a name for the set.

  • Page 185: Applying Schedule Sets To Remote Nodes

    Prestige 316 Broadband Sharing Gateway/Wireless LAN FIELD DESCRIPTION EXAMPLE How Often Choose Once or Weekly. Both these options are mutually Once exclusive. If Once is selected, then fill in the date it will occur. If (default) Weekly is selected, then fill in the weekdays when call should occur.

  • Page 186: Figure 12-3 Applying Schedule Sets To A Remote Node Example (Pppoe Encapsulation)

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Menu 11.1 - Remote Node Profile Rem Node Name= ChangeMe Route= IP Active= Yes Encapsulation= PPPoE Edit IP= No Service Type= Standard Telco Option: Service Name= Allocated Budget(min)= 0 Outgoing: Period(hr)= 0 My Login=...

  • Page 187: Chapter 13 Telnet Configuration And Capabilities

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 13 Telnet Configuration and Capabilities This chapter covers the Telnet Configuration and Capabilities of the Prestige. 13.1 About Telnet Configuration Before the Prestige is properly setup for TCP/IP, the only option for configuring it is through the console port.

  • Page 188: Telnet Capabilities

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 13.3 Telnet Capabilities 13.3.1 Single Administrator To prevent confusion and discrepancy on the configuration, your Prestige only allows one administrator to log in at any time. Your Prestige also gives priority to the console port over telnet. If you have already connected to your Prestige via telnet, you will be logged out if another user logs in to the Prestige via the console port.

  • Page 189: Troubleshooting, Appendices, Glossary And Index

    Prestige 316 Broadband Sharing Gateway / Wireless LAN TROUBLESHOOTING, APPENDICES, GLOSSARY AND INDEX Part 4 provides information about solving common problems, followed by some Appendices, a Glossary of Terms and an Index.

  • Page 190: Chapter 14 Troubleshooting

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Chapter 14 Troubleshooting This chapter covers the potential problems you may run into and the possible remedies. After each problem description, some instructions are provided to help you to diagnose and to solve the problem. Please see our supporting disk for further information.

  • Page 191: Problems With The Lan Interface

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 14.2 Problems With the LAN Interface Table 14-2 Troubleshooting the LAN Interface PROBLEM CORRECTIVE ACTION Cannot ping any computer Check the 10M/100M LEDs on the front panel. One of these LEDs should on the LAN.

  • Page 192: Problems With The Wan Interface

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 14.3 Problems With the WAN Interface Table 14-3 Troubleshooting the WAN Interface PROBLEM CORRECTIVE ACTION Cannot get WAN IP address The WAN IP address is provided when the ISP recognizes the user as an from the ISP.

  • Page 193: General Instructions

    Prestige 316 Broadband Sharing Gateway/Wireless LAN 14.5 General Instructions If you have other problems you can try the following options: • Check Menu 24.1 – System Maintenance – Status, Menu 24.2.1 – System Maintenance – Information and Menu 24.3 – System Maintenance – Log and Trace in order to locate the problem.
  • Page 194 Prestige 316 Broadband Sharing Gateway/Wireless LAN Appendix A Wireless LAN and IEEE 802.11 A wireless LAN (WLAN) provides a flexible data communications system that you can use to access various services (navigating the Internet, email, printer services, etc.) without the use of wires. In effect a wireless LAN environment provides you the freedom to stay connected to the network while in the coverage area.
  • Page 195 Prestige 316 Broadband Sharing Gateway/Wireless LAN Ad-hoc Wireless LAN Configuration The simplest WLAN configuration is an independent (Ad-hoc) WLAN that connects a set of computers with wireless nodes or stations (STA), which is called a Basic Service Set (BSS). In the most basic form, a wireless LAN connects a set of computers with wireless adapters.

  • Page 196: Appendix A Wireless Lan And Ieee 802.11

    Prestige 316 Broadband Sharing Gateway/Wireless LAN The Extended Service Set (ESS) shown in the next figure consists of a series of overlapping BSSs (each containing an Access Point) connected together by means of a Distribution System (DS). Although the DS could be any type of network, it is almost invariably an Ethernet LAN.

  • Page 197: Appendix Bpppoe

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Appendix B PPPoE PPPoE in Action An ADSL modem bridges a PPP session over Ethernet (PPP over Ethernet, RFC-2516) from your computer to an ATM PVC (Permanent Virtual Circuit) which connects to a xDSL Access Concentrator where the PPP session terminates (see the next figure).
  • Page 198 Prestige 316 Broadband Sharing Gateway/Wireless LAN How PPPoE Works The PPPoE driver makes the Ethernet appear as a serial link to the COMPUTER and the COMPUTER runs PPP over it, while the modem bridges the Ethernet frames to the Access Concentrator (AC). Between the AC and an ISP, the AC is acting as a L2TP (Layer 2 Tunneling Protocol) LAC (L2TP Access Concentrator) and tunnels the PPP frames to the ISP.

  • Page 199: Appendix C Hardware Specifications

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Appendix C Hardware Specifications Power Specification I/P AC 120V / 60Hz; O/P DC 12V 1200 mA MTBF (Mean Time Between Failure) 100000 hrs Operating Temperature 0º C ~ 40º C Ethernet Specification for WAN...

  • Page 200: Appendix D Important Safety Instructions

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Appendix D Important Safety Instructions The following safety instructions apply to the Prestige: Be sure to read and follow all warning notices and instructions. The maximum recommended ambient temperature for the Prestige is 40ºC (104ºF). Care must be taken to allow sufficient air circulation or space between units when the Prestige is installed inside a closed rack assembly.
  • Page 201 Prestige 316 Broadband Sharing Gateway/Wireless LAN • Never install telephone jacks in a wet location unless the jack is specially designed for wet locations. • Never touch non-insulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.

  • Page 202: Appendix E Pptp

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Appendix E PPTP PPTP Basics PPTP (Point-to-Point Tunneling Protocol) is a Microsoft™ proprietary protocol (RFC-2637 for PPTP is informational only) to tunnel PPP frames. Transporting PPP Frames From a COMPUTER to a Broadband Modem Over Ethernet A solution is to build PPTP into the ANT (ADSL Network Termination) where PPTP is used only over the short haul between the COMPUTER and the modem over Ethernet.
  • Page 203 Microsoft™ includes PPTP as a part of the Windows® O/S. In Microsoft™’s implementation, the COMPUTER and hence the Prestige 316 is the PNS that requests the PAC (the ANT) to place an outgoing call over AAL5 to an RFC-2364 server.
  • Page 204 Prestige 316 Broadband Sharing Gateway/Wireless LAN Control Connection The control connection runs over TCP. Similar to L2TP, a tunnel control connection is first established before call control messages can be exchanged. Please note that a tunnel control connection supports multiple call sessions.

  • Page 205: Appendix F Power Adapter Specifications

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Appendix F Power Adapter Specifications NORTH AMERICAN PLUG STANDARDS AC Power Adapter Model MW48-1201200 AD48-1201200DUY Input Power AC120Volts/60Hz/22W AC120Volts/60Hz/0.25A Output Power DC12Volts/1.2A DC12Volts/1.2A Power Consumption Safety Standards UL, CUL (UL1310, CSA C22.2 No. 233-M91)

  • Page 206: Glossary

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Glossary 100Base-T Uses two pairs of twisted-pair wire with a maximum distance of 100 meters between the hub and the workstation. 10Base-T The 10-Mbps baseband Ethernet specification that uses two pairs of twisted- pair cabling (Category 3 or 5), one pair for transmitting data and the other for receiving data.
  • Page 207 Prestige 316 Broadband Sharing Gateway / Wireless LAN Bandwidth This is the capacity on a link usually measured in bits-per-second (bps). (Binary Digit) – A single digit number in base-2, in other words, either a one or a zero. The smallest unit of computerized data.
  • Page 208 Prestige 316 Broadband Sharing Gateway/Wireless LAN which you enter commands. Customer Premise Equipment. CPE is privately-owned telecommunication equipment at an organization’s site that is attached to the telecommunication network. CPE includes routers, modems, PBXs, telephones, key systems, facsimile products, voice processing equipment and video communication equipment.
  • Page 209 Prestige 316 Broadband Sharing Gateway / Wireless LAN the Internet you can type the IP address of the site or the DNS name. When you type a domain name in a Web browser a query is sent to the primary DNS server defined in your Web browser’s configuration dialog box.
  • Page 210 Prestige 316 Broadband Sharing Gateway/Wireless LAN (Frequently Asked Questions) – FAQs are documents that list and answer the most common questions on a particular subject. The FCC (Federal Communications Commission) is in charge of allocating the electromagnetic spectrum and thus the bandwidth of various communication systems.
  • Page 211 Prestige 316 Broadband Sharing Gateway / Wireless LAN between a host server and a gateway to the Internet ICMP uses Internet Protocol (IP) datagrams, but the messages are processed by the TCP/IP software and are not directly apparent to the application user.
  • Page 212 Prestige 316 Broadband Sharing Gateway/Wireless LAN businesses. There are local, regional, national, and global ISPs. You can think of local ISPs as the gatekeepers into the Internet. Jack Type Different types of jacks (RJ-11, RJ45 or RJ-48) can be used for an ISDN line. The RJ- 11 is the most common in the world and is most often used for analog phones, modems and fax machines.
  • Page 213 Prestige 316 Broadband Sharing Gateway / Wireless LAN NDIS Network Driver Interface Specification is a Windows® specification on how communication protocol programs (such as TCP/IP) and network device drivers should communicate with each other. NetBIOS Network Basic Input/Output System. NetBIOS is an extension of the DOS BIOS that enables a computer to connect to and communicate with a LAN.
  • Page 214 Prestige 316 Broadband Sharing Gateway/Wireless LAN Demarcation the phone line. Post Office Protocol. This is a common protocol used for sending, receiving, and delivering mail messages. Port An Internet port refers to a number that is part of a URL, appearing after a colon (:), directly following the domain name.
  • Page 215 Prestige 316 Broadband Sharing Gateway / Wireless LAN firewall. Proxy Server A server that performs network operations in lieu of other systems on the network. Proxy Servers are most often used as part of a firewall to mask the identity of users inside a corporate network yet still provide access to the Internet.
  • Page 216 Prestige 316 Broadband Sharing Gateway/Wireless LAN Router A device that connects two networks together. Routers monitor, direct and filter information that passes between these networks. Because of their location, routers are a good place to install traffic or mail filters. Routers are also prone to attacks because they contain a great deal of information about a network.
  • Page 217 Prestige 316 Broadband Sharing Gateway / Wireless LAN Straight-through A cable that wires a pin to its equivalent pin. This cable connects two dissimilar Ethernet cable devices, for example, a data terminal equipment (DTE) device and a data communications equipment (DCE) device. A straight through Ethernet cable is the most commonly used Ethernet cable.
  • Page 218 Prestige 316 Broadband Sharing Gateway/Wireless LAN servers. Uniform Resource Locator. URL is an object on the Internet or an intranet that resides on a host system. Objects include directories and an assortment of file types, including text files, graphics, video and audio. A URL is the address of an object that is normally typed in the Address field of a Web browser.

  • Page 220: Index

    Prestige 316 Broadband Sharing Gateway/Wireless LAN Index CDR..............9-8 ........... CDR Message Format Channel ID............3-10 Command Interpreter Mode......11-1 10 Mbps half duplex.......... 1-1 Conditions that prevent TFTP and FTP from 10/100 Mbps Ethernet........1-2 working over WAN ......10-4, 11-8 11 Mbps wireless LAN ........
  • Page 221 Prestige 316 Broadband Sharing Gateway / Wireless LAN PPP over Ethernet ........... D Gen ...............7-7 IP 7-6 encapsulation method Ethernet............3-14, 4-2 Filtering Process PPPoE ..............3-17 Outgoing...............7-2 PPTP/PPPoE............4-4 Filters Error Log............9-6 Executing a Filter Rule .........7-2 ESS ......See Extended Service Set Logic Flow of an IP Filter ........7-10...
  • Page 222 Prestige 316 Broadband Sharing Gateway/Wireless LAN Installation Requirements ......... 2-5 Log Facility ............9-8 internal tests............2-6 Logging............. 1-3 Internet access..........3-1 logging option ..........7-13 Internet Access ..........1-3 Internet Access Setup.. 2-11, 3-13, 3-14, 6-6, 14-3 Internet Access Sharing........1-1 Internet Assigned Numbers Authority ..
  • Page 223 Prestige 316 Broadband Sharing Gateway / Wireless LAN Rear Panel ..........2-2, 2-3 Related Documentation........xxv Remote Management Setup......11-6 PAC (PPTP Access Concentrator) .......J packet remote node ............. 4-1 received..............9-3 Remote Node ..........2-11 Remote Node Filter .......... 4-9 transmitted ............9-3...
  • Page 224 Prestige 316 Broadband Sharing Gateway/Wireless LAN Single Administrator........13-2 terminal emulation ..........2-5 SMT ..............2-10 TFTP and FTP over WAN Will Not Work When…. SNMP ............2-11, 8-1 ............10-4, 11-8 Configuring ............8-3 TFTP File Transfer........10-13 Community..........8-3 TFTP Restrictions........10-4, 11-8 TFTP Servers ...........
  • Page 225 Prestige 316 Broadband Sharing Gateway / Wireless LAN Wired Equivalent Privacy........ 3-11 Wireless LAN..........1-1, A Benefits..............A ZyNOS ......2-18, 9-3, 9-5, 10-1, 10-2 Wireless LAN Setup.......... 3-9 ZyNOS F/W Version......9-4, 9-5, 10-1 WLAN ........See Wireless LAN ZyXEL Limited Warranty www.zyxel.com..........

Table of Contents
