Prestige 304
Broadband Sharing Gateway
with 4-Port Switch

Quick Start Guide

Version 3.50
October 2001

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications ZyXEL Prestige 304

Summary of Contents for ZyXEL Communications ZyXEL Prestige 304

  • Page 1: Quick Start Guide

    Prestige 304 Broadband Sharing Gateway with 4-Port Switch Quick Start Guide Version 3.50 October 2001...

  • Page 2: Hardware Installation

    Prestige 304 Broadband Sharing Gateway with 4-Port Switch About Your Prestige 304 Broadband Sharing Gateway with 4-Port Switch The Prestige 304 is a dual Ethernet Broadband Sharing Gateway with 4-Port Switch with integrated network management features designed for multi- computer homes and home offices to access the Internet via cable or xDSL modem.
  • Page 3 Prestige 304 Broadband Sharing Gateway with 4-Port Switch Description of LEDs COLOR STATUS Green Flashing Green Flashing Green Flashing 1,2,3,4 Orange Flashing Rear Panel and Connections DESCRIPTION The Prestige is receiving power. The Prestige is performing a self-test. The Prestige is not receiving power. The WAN link is connected.
  • Page 4 Prestige 304 Broadband Sharing Gateway with 4-Port Switch WAN 10M Port Connect the WAN port on the Prestige to the Ethernet port on the cable or xDSL modem using the Ethernet cable that came with your modem. The Ethernet port on a cable modem is sometimes labeled "PC"...
  • Page 5 Prestige 304 Broadband Sharing Gateway with 4-Port Switch Turning on Your Prestige Plug the male end of the power adapter into a power outlet. The SYS LED turns on. The WAN and the LAN LED(s) turn on after the system tests are complete, if the WAN and LAN ports are properly connected.

  • Page 6: Preparing Your Network

    Prestige 304 Broadband Sharing Gateway with 4-Port Switch Preparing Your Network Since most Internet/network-related protocols are dependent on TCP/IP, you need to install and configure TCP/IP on your computer before you can access the Internet. Windows 95/98/Me/NT/2000, Macintosh OS 7 and later operating systems and all versions of UNIX/LINUX include the software components you need to install and use TCP/IP on your computer.
  • Page 7 Prestige 304 Broadband Sharing Gateway with 4-Port Switch If you need TCP/IP: In the Network window, click Add. Select Protocol and then click Add. Select Microsoft from the list of manufacturers. Select TCP/IP from the list of network protocols and then click OK. If you need Client for Microsoft Networks: Click Add.
  • Page 8 Prestige 304 Broadband Sharing Gateway with 4-Port Switch In the TCP/IP Properties window, select Specify an IP address. Type your information into the IP Address and Subnet Mask fields. Click the Gateway tab. Highlight any installed gateways and click the Remove button until there are none listed.
  • Page 9 Prestige 304 Broadband Sharing Gateway with 4-Port Switch Select the Internet Protocol (TCP/IP) entry and click the Properties button. Select Obtain an IP address automatically and click the Advanced button. Select any installed gateways and click Remove until there are none listed. Click the WINS tab and select any WINS addresses.
  • Page 10 Prestige 304 Broadband Sharing Gateway with 4-Port Switch Macintosh Installing TCP/IP Components TCP/IP should already be installed on Macintosh OS 7 and later systems. Configuring TCP/IP Properties Click the Apple icon (located in the upper left corner of your screen), select Control Panels and then TCP/IP.

  • Page 11: Your Internet Account

    Prestige 304 Broadband Sharing Gateway with 4-Port Switch Your Internet Account Contact an ISP (Internet Service Provider) for an Internet access account. For a single user account, the ISP supplies you with TCP/IP configuration information. Typically this information is dynamically (automatically) assigned via DHCP, but depending on your ISP and your network configuration, you may need to enter some of the following information manually.

  • Page 12: Using The Web Configurator

    Prestige 304 Broadband Sharing Gateway with 4-Port Switch Using the Web Configurator Web Configurator Login The web configurator provides user-friendly setup for your Prestige. Step 1. Launch your web browser and enter 192.168.1.1 as the URL. Step 2. Enter "1234" (default) as the password and click Login. In some versions, the default password appears automatically - if this is the case, just click Login.

  • Page 13: Troubleshooting

    Prestige 304 Broadband Sharing Gateway with 4-Port Switch PROBLEM None of the Make sure that you have the correct 5 VDC power adapter connected LEDs turn on to the Prestige and plugged in to an appropriate power source. when you turn If the error persists, you may have a hardware problem.
