To configure the iSCSI Target

Once the Target is set up, you can make the following changes:
1. Change the iSCSI Target Settings. See "To create an iSCSI target".
2. Change the logical unit number (LUN) and permissions. By default, the LUN ID for a
target is set to 0 and full access is granted. Follow these steps to make changes.
(a) Click the iSCSI Target subtab.
(b) Click the iSCSI device mapping icon next to the target that you want to modify and
then click the Add icon.
(c) In the LUN ID box, specify the LUN ID number. You can have as many as 256 LUN IDs.
(d) Specify the access permission — Read Only or Full Access, for the iSCSI initiators that
attempt to access the target.
(e) In the iSCSI Device list, select an additional device to map to.
(f) Click Submit.
3. Create an iSCSI initiator mask. You can set up initiator masking to restrict target access
only to the initiator name entered. An iSCSI target must exist before entering an initiator
name.
(a) Click the iSCSI Target subtab.
(b) Click the iSCSI initiator mapping icon next to the target that you want to modify
and then click the Add icon.
(c) In the Initiator Name box, enter the full initiator IQN from the iSCSI Initiator tool (for
example, iqn.1992-09.com.seagate:initiatorname).
(d) Click Submit.
