EN

To enable bad block scan on reboot:

1. Click the Advanced Setup tab.
2. Click the Advanced HDD Setup subtab.
3. Click the Perform Bad Block Scan at Next Boot Up check box.
4. Click Submit.

To enable hard disk standby mode:

1. Click the Advanced Setup tab.
2. Click the Advanced HDD Setup subtab.
3. Click the Hard Disk Standby check box.
4. Click Submit.

Using the Network Menu

The Network menu allows administrators access to all network configuration options, such
as setting up a DHCP/static IP address, network services (i.e., protocol, FTP, NFS, Apple
network), and configuring membership in a domain or workgroup.
The Network menu provides access to the following configuration options:
•

LAN

• Service
• Workgroup
• Dynamic DNS
LAN
Use the LAN tab to configure your network connection settings. You can either use DHCP or
manually assign a new IP address. The SilverStore is set to automatically obtain IP addresses
from a DHCP server. To assign a static IP address to the SilverStore, disable DHCP. A jumbo
frame size support is also included for switch or routers that supports jumbo frame.
SilverStore supports jumbo Ethernet frames to enhance Ethernet networking performance.
Jumbo frames are frames that are bigger than the standard MTU (Maximum Transmission
Unit), which is 1500 bytes. When SilverStore gets a frame size larger than its MTU, the data
is broken into smaller frames or dropped. By default, the jumbo frame option is disabled
in SilverStore.
FREECOM SILVER STORE 2-DRIVE NAS
31
