Scaling Presentation Switcher, cont'd
Front Panel Controls
Input buttons and LEDs select and identify
inputs. The green input LED indicates the input
that is scaled and displayed in the main image
window. If the Picture-in-picture (PIP) feature is
turned on (the PIP On LED is lit), the red input
LED indicates the input that is displayed in the
PIP image window.
Output Rate button and LEDs select and identify
the switcher's output rate. The Output Rate
button cycles through the available output screen
resolutions. The Output Rate LEDs indicate the
selected resolution.
The Output Rate button selects the
resolution only; the refresh rate defaults
to 60 Hz for each resolution selection.
The available 1400 x 1050, 480p, and
576p rates can be selected only by using
the menu system or SIS commands.
There is a 1-second delay between
selecting an output resolution from the
front panel (the Output Rate LED lights)
and the selected change taking effect.
PIP On button and LED select and identify the
on status of the PIP feature.
PIP Swap button toggles the primary and
secondary pictures between the main image
and the PIP window.
With regard to the PIP function, there are
two groups of inputs: low resolution
(inputs 1 through 4 [and input 5 if it is
configured as interlaced component
video]) and high resolution (inputs 6
through 8 [and input 5 if it configured as
progressive component video/HDTV]).
The PIP function toggles between the
selected input in each group. The PIP
function cannot toggle between two
inputs in the same group.
If PIP mode is off, the Swap function
toggles between the most recently selected
low resolution input and the most recently
selected high resolution input.
Picture Control buttons select individual picture
control status bar indicators that you can use
to make adjustments to the centering, size, PIP
centering, PIP size, contrast, brightness, color,
and tint.
Menu button activates the menu system, or a
submenu, or backs up one level within the
menu system.
QS-2
IN1508 Scaling Presentation Switcher • Quick Start
Quick Start — IN1508
, , , and buttons maneuver through the
menu system, move the slider on status bar
indicators, and move the
box indicators.
Enter button selects a menu item, exits a status
bar indicator, or activates a selected .
Setup and Operation
Configure input 5
1. Press Menu > Enter >
the Input 5 selection box.
2. Press
marker next to the appropriate input video
type.
3. Press Enter to activate the selected input
video type.
4. Allow the on-screen timeout to expire.
Configure the output
1. Press Menu >
activate the output resolution selection box.
2. Press
marker next to the desired output resolution.
3. Press Enter to activate the selected resolution.
4. If necessary, press Menu to back up one level
from the resolution selection box.
5. Press
selection box.
6. Press
marker next to the desired output rate.
7. Press Enter to activate the selected rate.
8. If necessary, press Menu to back up one level
from the rate selection box.
9. Press
selection box.
10. Press
marker next to the desired output signal type.
11. Press Enter to activate the selected rate.
12. Allow the on-screen timeout to expire.
marker in check
> Enter to activate
or
as necessary to move the
>
> Enter > Enter to
or
as necessary to move the
The screen goes blank while the switcher
changes to the newly selected resolution.
> Enter to activate the output rate
or
as necessary to move the
The screen goes blank while the switcher
changes to the newly selected rate.
>
> Enter to activate the signal type
or
as necessary to move the
The screen goes blank while the switcher
changes to the newly selected signal type.
