SmartBase MPC600F/MPC400 Chapter 3: Assembly and Disassembly
2.3 Disassembly Procedure
Disassembly 1. Pressure plate, Rear cover
(1) Lift the pressure plate to remove.
(2) Remove the 5 screws (a), and detach the rear cover.
a
Rear cover
Pressure plate
Figure 3-8 Disassembly 1
3-9
