SmartBase MPC600F/MPC400 Chapter 2: Technical Reference

3. PRINTER SECTION

NOTE

3.1 Overview of the Printer's Mechanical Parts

The printer's mechanical parts consist of the BJ cartridge, carriage, purge section, and paper feed section.
Each part is explained below.
The printer section mechanism in this model is taken from the S600 BJ printer.
Some illustrations are used in common with S600.
Paper Feed Section
Purge
Figure 2-5 Printer's Mechanical Parts
2-6
Carriage
