Important Please read PRECAUTIONS, this User’s Manual, and Setup Manual (separate volume) carefully to familiarize yourself with safe and effective usage. • Please refer to the Setup Manual for basic information ranging from connection of the monitor to a PC to using the monitor. • The latest User’s Manual is available for download from our web site: http://www.radiforce.com...
Page 2
EIZO NANAO CORPORATION. EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO NANAO CORPORATION’s receipt of said information.
Notice for this monitor This product is suited to clinical review. It does not support the display of mammography images for diagnosis. This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications.
Cleaning Attention • Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage the cabinet or panel. Note • Optional ScreenCleaner is recommended for cleaning the panel surface. ● Panel • Clean the panel with a soft cloth such as cotton cloth or lens cleaning paper. •...
Time<MenuOffTimer> ..22 ● ChangingTransparencyofAdjustment MenuDisplay<Translucent> ..23 3-4. Locking Buttons ... 23 3-5. Setting the EIZO Logo Display <Logo> ... 23 3-6. Setting Orientation <Orientation> ... 24 3-7. Setting Language <Language> ... 24 3-8. Enabling/Disabling DDC/CI communication ...
Page 6
Appendix ... 45 Trademark ... 45 ENERGY STAR ... 45 FCC Declaration of Conformity ... 46 Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor ...47 Hinweis zur Ergonomie : ...47 LIMITED WARRANTY ... 48 China Measures for RoHS Compliance in ChinaRoHS ...
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 23″ wide format LCD • Applicable to the resolution of 1920 × 1080. • Uses high-contrast panel (3000:1). Enables the display of sharp images.
1-2. Basic Operations and Functions ● Basic Adjustment menu operations Displaying Adjustment Menu 1. Press . The adjustment menu appears. Adjusting/Setting 1. Choose a menu to adjust/set with 2. Choose an item to adjust/set with 3. Adjust/set the selected item with Exiting 1.
Chapter 2 Adjusting Screens 2-1. Setting Screen Resolution ● Compatible Resolutions/Frequencies For details on compatible resolutions, refer to “Compatible Resolutions/Frequencies” in the Setup Manual. ● Setting the Resolution When you connect the monitor to the PC and find that the resolution is improper, or when you want to change the resolution, follow the procedure below.
2-2. Displaying Screen Correctly ● Digital Signal Input When digital signals are input, images are displayed correctly based on the preset data of the monitor, but if characters and/or lines appear blurred, go to When performing more advanced adjustment, see ●...
Page 12
Prepare to use analog screen adjustment patterns. Download the “Screen adjustment pattern files” from our site: http://www.radiforce.com. Note • For details and instructions on opening the “Screen adjustment pattern files”, refer to the Readme.txt file. Perform the auto adjustment again with the analog screen adjustment pattern displayed.
Page 13
● To remove flickering or blurring <Phase> Procedure 1. Choose <Phase> from the <Screen> menu, and press The <Phase> menu appears. 2. Adjust the phase with 3. Press to exit the adjustment. When vertical bars appear on the screen after adjustment, go back to “To eliminate vertical bars <Clock>”. (Clock →...
Adjusting color gradation. ● To adjust color gradation automatically <Range> Every color gradation (0 to 255) can be displayed by adjusting the signal output level. Procedure 1. Display Pattern 2 in full screen on the monitor using the “Screen adjustment pattern files”. 2.
2-3. Adjusting Color ● To select the display mode (CAL Switch mode) This function allows easy selection of a desired mode according to monitor application. Display Modes Mode Custom Availableformakingdesiredsetting. sRGB SuitableforcolormatchingwithsRGBcompatibleperipherals. Text Suitablefordisplayingtextsforwordprocessingorspreadsheets. DICOM AvailabletodisplayinDICOMmode. Movie Suitableforplayingbackanimatedimages. Displaysthecurrentmode. Procedure 1.
● Adjustable settings in each mode The adjustable settings depend on the mode. (You cannot select any non-adjustable or non-settable function.) √: Adjustable -: Not adjustable Icon Function Brightness Contrast Temperature Gamma Saturation Gain Overdrive Reset ● To adjust brightness <Brightness> The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel).
● To adjust contrast <Contrast> The brightness of the screen is adjusted by varying the video signal level. Adjustable range 0 to 100% Procedure 1. Choose <Color> from the Adjustment menu, and press 2. Choose <Contrast> from the <Color> menu, and press The <Contrast>...
● To adjust gamma <Gamma> Gamma can be adjusted. The brightness of the monitor varies depending on the input signal, however, the variation rate is not proportional to the input signal. To keep the balance between the input signal and the brightness of the monitor is called as “Gamma correction”.
● To adjust gain <Gain> The brightness of each color component red, green, and blue is called “Gain”. You can change the hue of “white” by adjusting gain. Adjustable range 0 to 100% Procedure 1. Choose <Color> from the Adjustment menu, and press 2.
2-4. Changing the Screen Size ● To change screen size <Screen Size> If a resolution other than recommended is used, the image displayed in full screen automatically. You can change the screen size by using <Screen Size> from <Others> menu. Setting FullScreen Displaysanimageinfullscreen.Imagesaredistortedinsomecasesbecausethe...
Chapter 3 Setting Monitor 3-1. Adjusting Volume <Volume> This function allows you to adjust the volume. Adjustable range 0 to 30 Procedure 1. Choose <Sound> from the Adjustment menu, and press 2. Choose <Volume> from the <Sound> menu, and press The volume adjustment menu appears.
3-3. Setting Adjustment Menu Display ● Changing Adjustment Menu Display Size <Menu Size> Change the Adjustment menu size using the following procedure. Procedure 1. Choose <Others> from the Adjustment menu, and press 2. Choose <Menu Settings> from the <Others> menu, and press 3.
You can toggle between Lock and Unlock by performing steps 1 and 2. 3-5. Setting the EIZO Logo Display <Logo> When the monitor is turned on, the EIZO logo appears on the screen. You can choose to display or not to display the EIZO logo.
3-6. Setting Orientation <Orientation> This function allows you to change the orientation of the Adjustment menu when using the monitor screen in vertical display position. Procedure 1. Choose <Others> from the Adjustment menu, and press 2. Choose <Orientation> from the <Others> menu, and press The <Orientation>...
3-8. Enabling/Disabling DDC/CI communication This function allows you to enable/disable the DDC/CI communication (see Procedure 1. Press to turn off the monitor. 2. Press holding down to turn on the monitor. You can toggle between Enable and Disable by performing steps 1 and 2. Note •...
Chapter 4 Power Saving Functions 4-1. Setting Power Saving <Power Save> ● Monitor This function allows you to set the monitor into the power saving mode according to the PC status. When the monitor has shifted to the power saving mode, the images on the screen are not displayed. Attention •...
● Audio Output This monitor allows you to turn off the audio output from the speakers/headphone at the power saving mode. Procedure 1. Choose <Sound> from the Adjustment menu, and press 2. Choose <Power Save> from the <Sound> menu, and press The <Power Save>...
4-4. Setting Indicator “EcoView Index” By using the EcoView Index function, the indicator that shows the level of power saving appears at the time of turning on the monitor, adjusting the brightness or switching the mode. The power saving ratio comes to high as the indicator level meter lights towards right.
4-5. Shifting to the power saving mode when a person leaves the monitor “EcoView Sense” The sensor on the front side of the monitor detects the movement of a person by using the EcoView Sense function. When a person moves away from the monitor, it shifts to the power saving mode automatically and does not display the images on the screen to reduce the power consumption.
4-6. Enabling/Disabling Auto Power-OFF <Off Timer> This function allows you to specify whether to turn on/off the monitor automatically after a specified time has elapsed in the power saving mode. Adjustable range Disable, Enable (0, 1, 2, 3, 5, 10, 15, 20, 25, 30, 45 min, 1-5 h) Procedure 1.
Chapter 5 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. No picture Problem 1. No picture • Powerindicatordoesnotlight. • Powerindicatorislightingblue. • Powerindicatorislightingorange. • Powerindicatorflashesorange. 2. The message below appears. • Thismessageappearswhennosignalis input. Example: •...
Page 32
Imaging problems (for both digital and analog) Problem 3. The screen is too bright or too dark. 4. Characters are blurred. 5. Afterimages appear. 6. Green/red/blue/white dots or defective dots remain on the screen. 7. Interference patterns or pressure marks remain on the screen.
Other problems Problem 12. The <Smoothing> icon on the Adjustment menu <Screen> cannot be selected. 13. The adjustment menu does not appear. 14. No mode name is displayed. 15. The auto adjustment function does not work. 16. No audio output. 17.
Chapter 6 Reference 6-1. How to Attach the Optional Arm An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the corresponding optional arm (or optional stand). Attention •...
Page 35
Remove the stand. Remove the stand from the monitor while releasing the lock. Attach the arm or stand to the monitor. Secure the monitor to the arm or stand using the screws specified in the user’s manual of the arm or stand. Chapter6Reference...
6-2. Attaching the FlexStand The once removed the FlexStand can be attached to the monitor again with the following procedures. Put the insertion part of the stand in the slot of the monitor. At the time, use as a guide that the marks (1) on the stand match to the screw holes (2) of the monitor. Attach the stand moving the monitor toward the stand.
6-3. Connecting Multiple PCs The product has multiple connections to PCs and allows you to switch to one of the connections for display. Connection examples DisplayPortconnector DisplayPortconnector ToPC1 ● To switch among input signals The input signal switches each time When the signal is switched, the active input port name appears at the top right corner of the screen.
● To set input signal selection <Input Signal> Setting Auto Manual Procedure 1. Choose <Others> from the Adjustment menu, and press 2. Choose <Input Signal> from the <Others> menu, and press The <Input Signal> menu appears. 3. Select “Auto” or “Manual” with 4.
6-6. Glossary Clock The analog signal input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog signal is converted to a digital signal for image display. This is called clock adjustment.
HDCP (High-bandwidth Digital Content Protection) Digital signal coding system developed to copy-protect the digital contents, such as video, music, etc. This helps to transmit the digital contents safely by coding the digital contents sent via DVI terminal on the output side and decoding them on the input side. Any digital contents cannot be reproduced if both of the equipments on the output and input sides are not applicable to HDCP system.
VESA DPM (Video Electronics Standards Association - Display Power Management) VESA specifications achieve increased energy efficiency for computer monitors. This involves standardization of signals sent from the computer (graphics board). DPM defines the status of signals transmitted between the computer and monitor. 6-7.
