2.8.2.3

Power and Hardware Control Connectors

CAUTION
The processor fan must be connected to the processor fan connector, not to a chassis fan
connector. Connecting the processor fan to a chassis fan connector may result in onboard
component damage that will halt fan operation.
Figure 21 shows the location of the power and hardware control connectors.
Item
A
B
C
D
E
F
G
1 3
1
G F
Description
Rear chassis fan
+12 V power connector (ATX12V)
Voltage regulator fan
Processor fan
Main power
Front chassis fan
Chassis intrusion
Figure 21. Power and Hardware Control Connectors
A
1
1 2
3
3 4
20
E
For more information see:
Table 29
Table 30
Table 31
Table 32
Table 33
Table 34
Table 35
Technical Reference
B
1
C
3
1
D
3
11
1
OM15908
65
