4.4.9.1

Burn-In Mode Submenu

To access this menu, select Advanced on the menu bar, then Chipset Configuration, and then
Burn-In Mode.
Maintenance
The submenu represented in Table 67 is for configuring Burn-In Mode options.
Table 67. Burn-In Mode Submenu
Feature
Do you wish to
continue?
Host and I/O Burn-In
Mode
AGP/PCI Burn-In Mode
CAUTION
These settings are intended for validation and test purposes only. Altering host and I/O clock
frequencies may reduce system stability and/or shorten the useful life of the processor. Operation
at settings beyond component specification is not covered by Intel component warranties. If any
problems occur during operation at non-default settings, return the board to default values.
Main
Advanced
PCI Configuration
Boot Configuration
Peripheral Configuration
Drive Configuration
Floppy Configuration
Event Log Configuration
Video Configuration
USB Configuration
Chipset Configuration
Burn-In Mode
Fan Control Configuration
Hardware Monitoring
Options
• No (default)
• Continue
• Default (default)
• –2.0%
• –1.0%
• +1.0%
• +2.0%
• +3.0%
• +4.0%
• Default (default)
• 63.88/31.94 MHz
• 68.05/34.02 MHz
• 69.44/34.72 MHz
• 70.83/35.41 MHz
• 72.22/36.11 MHz
• 73.60/36.80 MHz
Security Power
Description
Enables or disables setting of burn-in mode options.
Burn-in Mode is an unsupported capability for use by
system engineers and technicians for validation and
test purposes.
Alters the host clock (system bus) and I/O clocks
(AGP and PCI) by the percentage selected.
If this option is set to anything other than Default, the
AGP/PCI Burn-In Mode (shown below) is
automatically set to Default.
Enables the selection of specific AGP/PCI clock
frequencies. The host clock (system bus speed) is
not changed.
If this option is set to anything other than Default, the
Host and I/O Burn-In Mode (shown above) is
automatically set to Default.
BIOS Setup Program
Boot Exit
113
