1.8.3 Diskette Drive Controller

The I/O controller supports one diskette drive. Use the BIOS Setup program to configure the
diskette drive interface.
For information about
The location of the diskette drive connector
The supported diskette drive capacities and sizes

1.8.4 Keyboard and Mouse Interface

The PS/2 keyboard and mouse connectors are located on the back panel.
✏
NOTE
The keyboard is supported in the bottom PS/2 connector and the mouse is supported in the top
PS/2 connector. Power to the computer should be turned off before a keyboard or mouse is
connected or disconnected.
For information about
The location of the keyboard and mouse connectors

1.9 IEEE 1394a-2000 Controller (Optional)

The Agere Systems FW323 PCI bus-based controller provides IEEE 1394a-2000 OHCI link and
PHY core functionality. The controller supports:
•
IEEE 1394a-2000-compliant or IEEE 1394-1995-compliant peripheral devices
•
Isochronous and asynchronous data transfer
•
Data transfer up to 400 Mbits/sec
•
Peripheral hot swapping
•
Plug and play
The Desktop Board D865PERL has one back panel and two front panel IEEE 1394a-2000
connectors.
✏
NOTE
IEEE 1394a-2000 support has been tested with Windows 2000 and Windows XP drivers and is not
currently supported by any other operating system.
For information about
The location of the back panel IEEE 1394a-2000 connector
The location of the front panel IEEE 1394a-2000 connectors
The signal names of the front panel IEEE 1394a-2000 connectors
Obtaining IEEE standards:
• 1394-1995, IEEE Standard for a High Performance Serial Bus
• 1394a-2000, IEEE Standard for a High Performance Serial Bus – Amendment 1
Product Description
Refer to
Figure 22, page 68
Table 62, page 107
Refer to
Figure 19, page 60
Refer to
Figure 19, page 60
Figure 23, page 70
Figure 26, page 73
Table 3, page 17
