Table 26.

Auxiliary Line Input Connector

Pin Signal Name
1 Left auxiliary line in
2 Ground
3 Ground
4 Right auxiliary line in
Table 27.

ATAPI CD-ROM Connector

Pin Signal Name
1 Left audio input from CD-ROM
2 CD audio differential ground
3 CD audio differential ground
4 Right audio input from CD-ROM
Table 28.

Front Panel Audio Connector

Pin Signal Name
1 Mono Mic in (Stereo Mic 1)
3 Mono Mic Bias (Stereo Mic 2)
5 RIGHT_OUT
7 Not connected
9 LEFT_OUT
✏
NOTE
The front panel audio connector is alternately used as a jumper block for routing audio signals.
For more information, see Section 2.9.1 on page 74.
64
Pin Signal Name
2 Ground
4 +5 V
6 Right channel return
8 Key
10 Left channel return
