Intel BLKD865PERL Technical Product Specification page 112

Intel Desktop Board D865PERL Technical Product Specification
Table 66. Chipset Configuration Submenu (continued)
Feature
Extended Configuration
SDRAM Frequency
(Note 1)
CPC Override
SDRAM Timing Control
(Note 1)
SDRAM RAS Active to
(Note 4)
Precharge
SDRAM CAS# Latency
(Note 4)
SDRAM RAS# to CAS#
(Note 4)
Delay
SDRAM RAS#
(Note 4)
Precharge
Notes:
1. This feature is displayed only if Extended Configuration is set to User Defined.
2. This option is displayed only if the installed processor has a 533 MHz system bus.
3. This option is displayed only if the installed processor has an 800 MHz system bus.
4. This feature is displayed only if SDRAM Timing Control is set to Manual – User Defined.
112
Options
• Default (default)
• User Defined
• Auto (default)
• 266 MHz
• 333 MHz
(Note 2)
• 400 MHz (Note 3)
• Auto (default)
• Enabled
• Disabled
• Auto (default)
• Manual – Aggressive
• Manual – User Defined
• 8
• 7
• 6 (default)
• 5
• 2.0
• 2.5 (default)
• 3.0
• 4
• 3 (default)
• 2
• 4
• 3 (default)
• 2
Description
Allows the setting of extended configuration options.
Allows override of the detected memory frequency.
NOTE: If SDRAM Frequency is changed, you must
reboot for the change to take effect. After changing
this setting and rebooting, the System Memory
Speed parameter in the Main menu will reflect the
new value.
Controls the CPC/1n rule mode.
Enabled allows the DRAM controller to attempt chip
select assertions in two consecutive common clocks.
Auto = Timings will be programmed according to the
memory detected.
Manual – Aggressive = Selects most aggressive
user-defined timings.
Manual – User Defined = Allows manual override of
detected SDRAM settings.
Corresponds to tRAS.
Selects the number of clock cycles required to
address a column in memory.
Selects the number of clock cycles between
addressing a row and addressing a column.
Selects the length of time required before accessing
a new row.
