Configuration Tasks

Configure a T3 interface by entering Global Configuration mode and performing the
following tasks:
1.
2.
3.
4.
5.
6.
E3 interface configuration tasks are identical to T3 interface configuration tasks,
except that the CLI commands contain e3 instead of t3.
For example, you configure an E3 controller with the controller e3 command instead
of the controller t3 command.

Configuring a T3 or an E3 Controller

To configure a T3 or an E3 controller:
1.
2.
3.
channelized
controller e3
Configure a T3 controller.
(Optional) Configure MDL settings.
(Optional) Configure other settings for the interface.
Configure HDLC channels for T3 frame and E3 frame controllers.
(Optional) Configure fractional T3 for T3 frame controllers.
Use the appropriate show commands to verify your configuration.
Select the T3 or E3 controller from Global Configuration mode.
host1(config)#controller t3 3/2
Enable the T3 or E3 controller.
host1(config-controll)#no shutdown
(CT3/T3-F0 line module only) Enable unchannelized operation for this controller.
host1(config-controll)#no channelized
Use to enable channelized T3 operation on an interface of a CT3/T3-F0 line
module.
Example
host1(config-controll)#channelized
Use the no version to enable unchannelized T3 operation on an interface for a
CT3/T3-F0 line module.
See channelized.
Use to specify an E3 controller in slot/port format.
Chapter 2: Configuring T3 and E3 Interfaces
Configuration Tasks
51
