R5-56 [179] and R5-58 [181] for information about bit ordering and meaning for the
K1 byte; see R5-67 [190v2] for information about the K2 byte.

Table 7: Explanation of K1 Byte

Table 8: Explanation of K2 Byte

76
Overview
Bit Value (12345678)
Bits 1–4 represent a request.
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011
1100
1101
1110
1111
Bits 5–8 represent the channel number.
0
0001–1110
Bit Value (12345678)
Bits 1–4 represent the channel number.
0
Meaning
No request
Do not revert
Reverse request
Not used
Exercise
Not used
Wait-to-restore
Not used
Manual switch
Not used
Low-priority signal degradation
High-priority signal degradation
Low-priority signal failure
High-priority signal failure
Forced switch
Lockout of protection
Channel number of protect interface
Channel number of working interface
Meaning
Channel number of protect interface
