By default, Serial devices are always added to the system with RS-232 set as the
Connection Type. Change the Connection Type to match the device's requirements
via the Connection Type field in the Device Properties window.

Device Properties - Media

The following parameters are required for MAX by AMX devices, and are set via fields in the Device
Properties window.
These fields are only displayed if a (MAX) Media device is selected in the System
diagram.
VisualArchitect v1.1
CONFIDENTIAL AND PROPRIETARY. COPYRIGHT, AMX LLC, 2006
Category - This is the category of devices that the selected device belongs to (read-only).
Manufacturer - This field indicates the name of this device's manufacturer (read-only).
Model Number - This is the manufacturer's model name/number for the device (read-only).
Connection Type - Click inside this row to enable the Connection Type sub-menu, where you
can select any of the connection types supported by this device. The Connection Type
selection determines which rows are displayed immediately beneath this one (based on that
type's required parameters).
Duet Module - This field indicates the full path and filename of the duet Module (*.JAR) file
associated with this device (Module-Supported Devices only).
IP Address/Host Name - Enter an IP Address (or host name if applicable) for this device.
This field is only displayed for Ethernet devices.
Media Library File Path - Click inside this row to enable the Browse button (...). Click this
button to specify a file path for the Media Library (*.MXD) file. The Media Library represents
a listing of all media (including CDs and DVDs) identified in the ContentDatabaseEditor
program - accessible via the File menu. This field is only displayed for devices that can
playback audio/video media.
Name - This is the (default) system name for the selected device. Click inside this row to edit
the element name; note that the device Name cannot contain any Unicode characters.
Comments - Click inside this row to add any developer's comments regarding this device.
Category - This is the category of devices that the selected device belongs to (read-only).
Model Number - This is the manufacturer's model name/number for the device (read-only).
FG Number - This the AMX "Finished Goods" number associated with this device (read-
only).
MSRP - This is the MSRP (manufacturer's suggested retail price) for this device (read-only).
Setting Device Properties
