2. Under Actions, select Transfer Previously Generated System Files.
3. Under Transfer Options, specify a Transfer Folder (source directory) that contains the system files
that will be transferred. Click the browse icon to navigate to the desired folder in the Browse for
Folder dialog.
4. Click Start.
The Progress bars indicate the status of the operation, and the program will alert you if there are any
problems or issues with the system files during the process.

VA Generated System Files

When you select to generate system files, via the options in the Generate and Transfer System Files
dialog, VA generates several files and folders.
The result of a Generate & Transfer System Files, or Generate System Files operation is the
following set of folders and system files:
Depending on the equipment included in your system, some of these files may not
appear (for example, if your system does not include any keypads, there would not
be a KPB file generated).

Folders

Files

There are several individual files generated that are not copied into any of the above directories. There
are only a few that are of interest:
VisualArchitect v1.1
CONFIDENTIAL AND PROPRIETARY. COPYRIGHT, AMX LLC, 2006
Include folder - contains any Include (*.AXI) files required by the system.
IR folder - contains all IR (*.IRL) files required by the devices in the system.
Module folder - contains all Duet module (*.JAR) files required by the devices in the system.
Other folder - this directory contains any system files other than the VA-generated files.
Source folder - contains the Master Source Code file (*.AXS) required by the Central
Controller.
User Interface folder - contains all touch panel (*.TP4) and keypad (*.KPB) user-interface
files. There is one UI file generated for each UI device in the system.
CodeGen.log - this is a detailed log file of the file generation process. This is a text file, and
can opened in any text editor (i.e. Notepad).
*-VA.APW - this is the project workspace file for the project. APW files can be opened in
NetLinx Studio. Workspace files allow you to edit any of the system files within NetLinx
Studio. Refer to the NetLinx Studio on-line help for information on Workspace files.
*-VA Report.HTML - this is the System Report for this project.
Finishing the Project
