Supported Software Features for the Cisco uBR7200 Series
Table 10
Table 10
Field
Cable
Downstream is up
Frequency
Channel Width
QAM
Symbol Rate
FEC ITU-T
R/S Interleave I/J
The following example illustrates the information from the show controllers cable command on a Cisco
uBR7246VXR router on which Cisco IOS Release 12.3(9a)BC is installed.
Router# show controllers cable x/y
For additional information about this and other commands, refer to the following document on
Cisco.com:
•
show tech-support
Cisco IOS Release 12.3(9a)BC shortens the output of the show tech-support command on the Cisco
uBR10012 and the Cisco uBR7246VXR routers. This change allows users with large numbers of online
cable modems to collect information without consuming the console session for a long period of time.
To display general information about the Cisco CMTS router when reporting a problem to Cisco
technical support, use the show tech-support command in privileged EXEC mode.
The show tech-support command automatically displays the output of a number of different show
Note
commands. The exact output depends on the platform, configuration, and type of protocols being used.
Note The show tech-support includes most of the information shown in the
command.
Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide
1-44
describes the fields displayed by the show controllers cable downstream command.
show controllers cable downstream Field Descriptions
Cisco IOS CMTS Cable Command Reference Guide
http://www.cisco.com/en/US/docs/ios/cable/command/reference/cbl_book.html
show tech-support [page] [password] [cef | ipc | ipmulticast | isis | mpls | ospf | rsvp]
Chapter 1
Description
Slot number/port number indicating the location of the Cisco cable
interface line card.
Indicates that the RF downstream interface is enabled.
Transmission frequency of the RF downstream. (This information
may not match the current transmission frequency, which is
external on CMTS platforms that use an external upconverter.)
Indicates the width of the RF downstream channel.
Indicates the modulation scheme.
Indicates the transmission rate (in number of symbols per second).
Indicates the Motion Picture Experts Group (MPEG) framing
standard.
Indicates Reed Solomon framing based on ITU S.83-B.
Overview of Cisco uBR7200 Series Software
show cable tech-support
OL-2239-05
