Pitch Shifting; Delay; Reverb - DigiTech GNX1 User Manual

S T
ECTION HREE
Pitch Shift (PitCH)
A Pitch Shifter copies the incoming signal, then shifts the pitch of the copied note to a different note.The shifted
note is then mixed back with the original signal sounding as if two guitars were playing parallel notes.
Parameter 1 - The Number 2 Knob adjusts the Amount of Pitch Shift (SHIFT) in intervals of one semi-tone.
Ranges from -12 (12 semitones below) to +24 (24 semitones above).
Parameter 2 - The Number 3 Knob adjusts the left/right balance (BAL) of the shifted pitch.Ranges from L99
(left 99) to R99 (right 99).
Mod Level - The Number 5 Knob controls the volume of the shifted pitch. Ranges from 0 to 99.
The Number 4 knob has no function when the Pitch Shifter is selected.

Delay

Delay is an effect that will record a portion of the incoming signal, and then play it back a short time later.The
recorded segment can repeat just once, several times, or infinitely (which turns the input to the Delay off and allows
you to play over the top of a passage in the Delay loop). The Delay in the GNX1 also includes a Ducker Threshold
which allows you to set the signal strength required before the Delay will record.This feature allows you to control the
Delay through the dynamics of your playing.
Delay On/Off - The Status button turns the Delay on (DLY ON) and off (DLYOFF).
Delay Type - The Number 1 Knob selects one of the 4 different types of Delay. Delay choices include:
MONO (Mono Digital Delay - clear concise repeats)
PPONG (Ping Pong Delay - bounces from side to side)
Time - The Number 2 Knob adjusts the length of time between repeats. Ranges from 10 MS through 2000MS (10
through 2000 ms in 10 ms increments). Using the Data Up/Down buttons while the Delay Time is showing in
the Display will adjust the Delay Time in 1 ms increments.
Feedback - The Number 3 Knob adjusts the number of times the delayed signal will repeat (FEEDBK). Ranges from
1 to 99 and RPHOLD (infinite repeat).
Ducker Threshold - The Number 4 Knob adjusts the level (THRESH) the input signal must reach before the Delay
signal is attenuated. Ranges from 0 to 99 and oF (off).
Delay Level - The Number 5 Knob adjusts the volume (DLYLVL) of the Delay signal. Ranges from 0 to 99.
* Ducker Attenuation - The Ducker Level selects the amount of attenuation applied to the Delay signal when the
* Delay Balance - The Delay Balance adjusts the left/right balance of the Delay signal. Ranges from L 99 to R 99.

Reverb

Reverb can give the listener a sense that the material is being performed in various acoustical environments. It can
provide the tight acoustics of a small room, or the ambience of huge arena.
Reverb On/Off - The Status button turns the Reverb on (RVB ON) and off (RVBOFF).
Reverb Type - The Number 1 Knob selects the Type of Reverb or acoustic environment.The GNX1 provides ten
different environments to choose from including:
STUDIO = Studio
ROOM = Wood Room
CLUB = Club
PLATE = Plate
HALL = Hall
PreDelay - The Number 2 Knob adjusts the amount of time (PREDLY) it takes for the initial sound to reach the
first reflective surface in the simulated environment. Ranges from 0 to 15.
Decay - The Number 3 Knob adjusts the length of time the Reverb is audible (DECAY). Ranges from 1 to 99.
Damping - The Number 4 Knob controls the amount of sound which is absorbed (DAMPNG) in the simulated
environment. Ranges from 0 to 99.
Reverb Level - The Number 5 Knob adjusts the volume (RVBLVL) of the Reverb. Ranges from 0 to 99.
* Reverb Balance - The Reverb Balance adjusts the left/right balance of the Reverb signal. Ranges from L 99 to R 99.
* These Parameters are only available using the G
24
- E P
FFECTS AND ARAMETERS
Ducker Threshold has been exceeded. Ranges from 0 to 99.
ANALOG (Analog Delay - deteriorates with each repeat)
ALGPNG (Analog Ping Pong - side to side with
deterioration)
AMPTHE = Amphitheater
CHURCH = Church
GARAGE = Parking Garage
ARENA = Arena
SPRING = Spring
N ™ computer editor software.
E EDIT
