    Introduction GNX3000 Owner’ s Manual GNX3000 Owner’ s Manual...

  • Page 9: Introduction

    The GNX3000’s intuitive user interface makes programming as simple as turning a knob. However, your time would be well spent by reading through the Quick Start section on page 3 (as well as the rest of this Owner’s Manual) with your GNX3000 in front of you.

  • Page 10

    • DigiTech Warranty Card • USB Cable The utmost care was taken in the manufacturing and packaging of your GNX3000. Everything should be included and in perfect working condition. However, if you find anything missing, please contact the factory at once. Please take a moment to fill out the warranty card or register online at www.digitech.com.

  • Page 11: Quick Start, Make Connections, Apply Power, Setups, Single Amp

    1. Turn the OUTPUT LEVEL knobs (for both the 1/4” and XLR OUTPUTS), on the rear panel of the GNX3000, all the way down (fully counter clockwise). 2. Connect the PSS3 power supply to the Power jack on the GNX3000. 3. Connect the other end of the PSS3 power supply to an AC outlet.

  • Page 12: Headphones, Mixer

    To connect to a mixer, plug your guitar into the GUITAR INPUT, and connect the GNX3000’s LEFT and RIGHT XLR or 1/4” BALANCED OUTPUTS to your mixer’s left and right inputs. Turn Speaker Compensation on for the 1/4” and XLR OUTPUTS (see page 24).

  • Page 13: Selecting Presets And Amp Models, Presets, Amp And Cabinet Models

    GNX3000 Owner’ s Manual Selecting Presets and Amp Models Once you’re connected to the GNX3000, you can immediately transform the tone of your guitar with the 130 Factory presets. (There are also 65 User presets you can customize; learn how to create a custom preset on page 81.) Within each preset you can also select different amp models that will further alter your guitar’s tone.

  • Page 14: Recording - Computer

    See page 44 for more information about Amp/Cabinet modeling. Recording - Computer If you’re ready to start recording, here’s how to connect the GNX3000 to your computer. You’ll also need to install the included software; see page 101 for more information.

  • Page 15

    ATTENTION: Refer to the “Installing the GNX3000’s Software Suite” section on page 101 before connecting the GNX3000 to the USB port on your PC and using Pro Tracks Plus. 7. Connect a MIDI keyboard to the GNX3000’s MIDI IN and OUT/THRU JACKS using 5 Pin MIDI cables.

  • Page 16: The Programming Matrix, The Control Panel

    The Control Panel Control Panel These buttons control several “nuts and bolts” operations of the GNX3000. You can use them to change the footswitch mode you’re in (page 36), choose output options (page 20), audio setup for recording (page 31), control the drum machine (page 99 ), save preset settings (page 92 ), and perform many other functions.

  • Page 17: The Expression Pedal, Down/up Footswitches

    GNX3000 Owner’ s Manual The Expression Pedal Expression Pedal The EXPRESSION PEDAL can control up to three parameters at a time for any preset. For example, you could assign Chorus speed, Chorus depth, and volume to the EXPRESSION PEDAL so that they all increase when you rock it forward, and decrease when you rock it backward.

  • Page 18

    Highlights of the GNX3000 Footswitches 1-5 Footswitches 1-5 Depending on the mode, these five footswitches select presets, change amp channels, turn individual effects on and off, control drum machine operations, and give you Hands-Free recording operation when recording on your computer. You can also...

  • Page 19: Gnx3000 Special Features, Modes, Amp Channels 1 And 2, Amp Channel - Warped, Hypermodels

    Amp Channels 1 and 2 Not only does the GNX3000 let you choose from a garage full of simulated amp head and cabinet combinations (page 44), you can set up two different combinations within the same preset and quickly switch back and forth between them.

  • Page 20: Getting Familiar With The Gnx3000, The Front Panel

    Getting Familiar with the GNX3000 Getting Familiar with the GNX3000 The Front Panel 1. Footswitches 1-5 Depending on the selected mode, these five FOOTSWITCHES select presets, change amp channels, turn individual effects on and off, and control drum machine and recording operations.

  • Page 21

    GNX3000 Owner’ s Manual 3. Amp Control Buttons The four AMP CONTROL buttons are used to select one of the amp/cabinet model edit rows including: CHAN ONE EQ (Green), GENETX (Yellow), CHAN TWO EQ (Red), and TONE (Silver). 4. Status button The STATUS button has multiple functions that depend on the matrix row that is selected.

  • Page 22

    11. Control Panel Buttons The Control Panel buttons are used to select the GNX3000’s Footswitch Modes, Output Setups, and Utility functions, and to store Amp/Cabinet Model edits and Preset changes. They also access the GNX3000’s Drum Machine functions as well as mic/line routing and USB input source routing for recording.

  • Page 23

    LINE - Selects the Line Input Routing menu and how both LINE INPUTS are routed through the GNX3000’s effects processing for both recording and live performance. USB 1-2 LVL - A gain/attenuation control to optimize the level of sources being recorded up the USB 1-2 channels.

  • Page 24

    13. Expression Pedal The EXPRESSION PEDAL controls up to three effect parameters in real time. Most GNX3000 parameters can be assigned to the EXPRESSION PEDAL. Applying extra pressure to the toe of the EXPRESSION PEDAL changes the EXPRESSION PEDAL’s function to control the Wah.

  • Page 25: The Rear Panel

    Vocoder effect (see Talker on ™ page 57). The mic signal can remain dry or processed through the GNX3000’s effects for live and recording applications (see page 25 for more information). The Microphone Input is equipped with built-in phantom power (which is always on) for use with condenser or ribbon mics that require phantom power.

  • Page 26

    USB 2.0 bus will switch to a USB v1.1 full speed (up to 12 Mbps) data rate to work with the GNX3000. ATTENTION: Refer to the “Installing the GNX3000’s Software Suite” section on page 101 before connecting the GNX3000 to the USB port on your PC and using Pro Tracks Plus. 12. MIDI In The MIDI In jack receives all incoming MIDI data including MIDI preset changes.

  • Page 27

    GNX3000 Owner’ s Manual GNX3000 Owner’ s Manual 14. Power Switch Turns the power on and off. 15. Power Input Connect only the provided DigiTech PSS3 power supply to this jack. GNX3000 Owner’ s Manual GNX3000 Owner’ s Manual...

  • Page 28: Audio Routing Setups, Setups Introduction, Output Setups

    Output Setups The GNX3000 features both 1/4" and XLR OUTPUTS on the rear panel. These jacks let you simultaneously connect the GNX3000 to an amplifier/speaker system on stage via the 1/4"...

  • Page 29

    GNX3000 Owner’ s Manual GNX3000 Owner’ s Manual The six OUTPUT SETUPS are as follows: Stereo All ( steroall All input sources (guitar, mic, line inputs, drums, and USB playback) are routed to both output pairs in stereo. Speaker Compensation can be turned on and off independently for either the 1/4”...

  • Page 30

    (except Cabinet Cabinet XLR Right Output (Talker) Tone Tone Talker) 1/4" Left Output CH 2 Amp CH 2 Modeling/ Cabinet 1/4" Right Output Tone Comp Gate Detector Detector = Speaker Compensation Module GNX3000 Owner’ s Manual GNX3000 Owner’ s Manual...

  • Page 31

    Split 1 ( split1 Stereo guitar processing and any inputs routed through the GNX3000’s guitar processing are routed to the 1/4" OUTPUTS. Audio playback from the computer, mic dry, line dry and drums is routed to the XLR OUTPUTS. Speaker Compensation can be turned on and off independently for either the 1/4”...

  • Page 32: Speaker Compensation

    Depending on which application you are using them for, you can enable or disable Speaker Compensation on either output pair independently. Speaker Compensation is to be used when the outputs of the GNX3000 will be played through a full range speaker system and emulates the rolled off response that a guitar cabinet normally provides without having to use one.

  • Page 33: Mic And Line Setups

    You can configure the MIC and LINE INPUTS routing for live performance and recording applications. The GNX3000 acts as a mixing device for MIC and LINE INPUTS, and can eliminate the need for a mixer when the outputs are to be plugged directly into a full-range powered speaker system.

  • Page 34: Optimizing The Mic And Line Input Levels

    While singing or during an acoustic performance, adjust the MIC INPUT level on the back panel of the GNX3000 until the CLIP LED next to the CONTROL PANEL lights only occasionally during the loudest parts of the performance.

  • Page 35: Hooking It Up, Live Performance Setups, Small Club Setup (mono Amp Rig)

    4. Turn OFF Speaker Compensation for the 1/4" BALANCED OUTPUTS in the 1/4” Speaker Compensation menu (described on page 24). NOTE: When connecting the GNX3000 to a guitar amp(s), it may be best to connect the GNX3000’s Output to your amp’s effects return to avoid coloration of the tone due to the amplifier’s tone controls.

  • Page 36: Medium Stage Setup (stereo Amp Rig)

    1. Connect your guitar to the GUITAR INPUT. 2. Connect mono instrument cables from the LEFT and RIGHT 1/4” BALANCED OUTPUTS of the GNX3000 to the instrument inputs or the effect returns on your amplifiers. 3. Press the OUTPUT SETUP button and select “...

  • Page 37

    A large stage rig lets you really pull out all the stops since space isn’t necessarily an issue, but volume usually is. For this application, plug your guitar into the GNX3000 and connect mono instrument cables from the 1/4" OUTPUTS into a stereo power amp feeding two cabinets.

  • Page 38

    Performance Setup The built-in Talker effect creates a talk box effect. To use this effect you must plug a microphone into the GNX3000’s MIC INPUT and select one of the five Talker types in the Whammy /IPS/Talk module of a preset. Then as you play your guitar talk into the ™...

  • Page 39: Computer Recording Setup

    Even your MIDI keyboard performance can be recorded so you can try the part with different synth voices later. Since the GNX3000 has professional BALANCED OUTPUTS, you can plug directly into your favorite powered monitors and get the bonus of latency free recording to boot.

  • Page 40

    9. Connect the GNX3000 to your computer’s USB jack using the included USB cable. ATTENTION: Refer to the “Installing the GNX3000’s Software Suite” section on page 101 before connecting the GNX3000 to the USB port on your PC and using Pro Tracks Plus. GNX3000 Owner’ s Manual...

  • Page 41: Applying Power, Gnx3000 Owner' S Manual

    3. Turn the GNX3000’s OUTPUT LEVEL KNOBS all the way down (fully counter- clockwise). 4. Connect the plug of the PSS3 power supply to the GNX3000’s POWER JACK. Connect the other end of the PSS3 power supply to an AC outlet.

  • Page 42: About The Gnx3000, Presets, Using Learn-a-lick

    GNX3000. Presets can be recalled with the FOOTSWITCHES or the DATA WHEEL. The GNX3000 comes with 65 Factory 1, 65 Factory 2, and 65 User presets. The Factory Presets do not let you store changes to them. The User presets let you store changes.

  • Page 43: Bypass, Tuner

    GNX3000’s presets while Preset Bounceback is enabled you must press FOOTSWITCHES 2 and 3 simultaneously. Tuner The Tuner in the GNX3000 lets you quickly tune or check the tuning on your guitar. Press FOOTSWITCHES 3 and 4 simultaneously to access the TUNER. The display briefly flashes tuner .

  • Page 44: Footswitch Modes, Preset Mode

    REF G(A=Gb). The display window briefly flashes the selected tuning preference. Footswitch Modes When you first apply power to the GNX3000, it powers up in one of three Footswitch Modes: Preset, Stompbox, or Record/Drum. The Footswitch Modes are selected in two...

  • Page 45: Stompbox Mode, Record/drum Mode, Expression Pedal

    2. Rotate the DATA WHEEL to turn the BounceBack feature on. 3. When finished press the EXIT button. NOTE: The Preset Bounceback feature only works when the GNX3000 is in Preset Mode. When Preset Bounceback is enabled, a preset cannot be bypassed by pressing its footswitch repeatedly.

  • Page 46: Gnx3000 Matrix Functions, The Gnx3000 Matrix

    EFFECTS SECTION The main panel of the GNX3000 is the Matrix. The Matrix is comprised of two main sections, AMP/CABINET and EFFECTS. It is used to navigate through the GNX3000’s amp/cabinet modeling and effects parameters. Upon power up, the GNX3000 defaults to the TONE row in the AMP/CABINET section and any effects that are enabled within a preset will have their corresponding LEDs lit in the EFFECTS section of the Matrix.

  • Page 47: Amp Parameter Values, Viewing/editing Effect Parameter Values

    GNX3000 Owner’ s Manual NAME 64 Amp Control Buttons AMP/CABINET SECTION Status Button Knobs Data Wheel Effect Select Buttons EFFECTS Viewing/Editing GeNetX and Amp Parameter Values SECTION To view or edit an amp parameter’s current value, you must first select the row in which the parameter resides using the AMP CONTROL buttons located to the left of the amp parameter rows.

  • Page 48: Genetx Row

    LED will be lit yellow. Knob 4 Selects the Channel 2 (Red) amp model and its LED is lit red. Knob 5 Selects the Channel 2 (Red) cabinet model and its LED is lit red. GNX3000 Owner’ s Manual...

  • Page 49: Chan Two Eq Rows

    GNX3000 Owner’ s Manual CHAN ONE EQ and CHAN TWO EQ Rows CHAN ONE EQ & CHAN TWO EQ ROWS KNOB KNOB KNOB KNOB KNOB STATUS BUTTON The CHAN ONE EQ and CHAN TWO EQ rows are used for modifying the center frequencies of the Bass, Midrange, and Treble controls of that reside within the TONE Row.

  • Page 50

    The STATUS button will also turn green at this time and can be used to turn the CHAN ONE EQ on or off as will be indicated by the button’s LED turning on and off. GNX3000 Owner’ s Manual...

  • Page 51: Tone Row

    GNX3000 Owner’ s Manual TONE Row TONE ROW KNOB KNOB KNOB KNOB KNOB STATUS BUTTON The TONE row is where the amp tone controls are located for Channel 1 or Channel 2. The sound that you hear while adjusting these parameters will depend on the channel status (see chart below).

  • Page 52: Amp/cabinet Modeling, Amp Models

    Amp/Cabinet Modeling Amp/Cabinet Modeling The GNX3000 was designed to make sound processing easy and intuitive. Because the GNX3000 provides both Amp Modeling and Effects Processing, the editing functions are divided into two sections: the AMP/CABINET MODELING section and the EFFECTS section.

  • Page 53

    GNX3000 Owner’ s Manual Marshall, Vox, Fender, Matchless, HiWatt, Ashdown, Ampeg, Trace-Elliot, Sunn, Hartke and Mesa Boogie, are trademarks of their respective companies and are in no way associated with DigiTech ® GNX3000 Owner’ s Manual...

  • Page 54: Cabinet Types, Editing Amps And Cabinets

    ® Editing Amps and Cabinets Each GNX3000 preset has three channels, Channel 1 (green), Channel 2 (red), and Warp (yellow). Amp channels 1 and 2 have selectable amps and cabinets. Each channel has independent controls for gain, level, EQ, and cabinet tuning. The Warp channel is effectively a mixture of the Channel 1 and 2 amps and cabinets using the Warp knob in the AMP CONTROLS section of the matrix.

  • Page 55: Selecting Amps And Cabinets, Adjusting Amp Parameters

    GNX3000 Owner’ s Manual Selecting Amps and Cabinets The first step to editing an Amp/Cabinet model, or creating your own HyperModel is to select the Amp and Cabinet model for Channel 1 and Channel 2 in your preset. The procedure for selecting Amps or Cabinets is as follows: 1.

  • Page 56: Storing Amp Parameter Edits

    See page 92 for more information on storing changes to a preset. Creating HyperModels Creating new, unique HyperModels is what Digitech’s GeNetX technology is all about. Once both channels Amps and Cabinets are selected and the Amp Parameters and Cabinet Tunings have been adjusted, GeNetX technology lets you do something amazing.

  • Page 57

    HyperModel. If one or more HyperModels have already been stored, the number displayed will be the first empty HyperModel location. If all 9 HyperModel locations are full, the GNX3000 defaults to the first HyperModel location and displays and the name of the HyperModel stored in the first location.

  • Page 58: Effects And Parameters, Editing A Preset' S Effects

    Effects and Parameters Effects and Parameters The GNX3000 features a comprehensive set of effects for creating just the sound you need for any musical application. These effects are connected in a standard effects chain with pickup simulator, wah, compressor, Whammy /IPS, and distortion stompbox effects placed before the amps.

  • Page 59: Effect Definitions, Wah-pickup

    GNX3000 Owner’ s Manual Effect Definitions Each Effect within the GNX3000 is fully programmable. Understanding how these effects modify the sound, and how each parameter alters the effect will help you achieve the sound you are looking for. The following overview outlines how each effect and parameter in the GNX3000 works.

  • Page 60: Compressor

    Compressor to reach unity gain. Other effects can clip if the Compressor Gain too high. Ranges from (dB). Knob 5 No function when the Compressor is selected. GNX3000 Owner’ s Manual...

  • Page 61

    GNX3000 Owner’ s Manual Whammy /IPS/Talk This module includes four types of pitch altering effects: Whammy, IPS, Detune, Pitch Shift, and the Talker effect. Only one of the effects in this row can be used at a time. After selecting the type of effect in this module, the Knobs 2-5 can then be used to adjust the individual parameters associated with the selected effect.

  • Page 62: Whammy

    Ranges from 0 to 99. Knob 4 No function when the Whammy is selected. Level KNOB 5 adjusts the Whammy Mix ( ) of all of the pitch-altering effects Wham mix in this module. Ranges from 0 to 99. GNX3000 Owner’ s Manual...

  • Page 63: Intelligent Pitch Shifting (ips)

    GNX3000 Owner’ s Manual Intelligent Pitch Shifting (IPS) Intelligent Pitch Shifting makes a copy of the incoming signal, and then changes the pitch of the copied note to a diatonically correct interval specified by the Amount parameter. An Intelligent Pitch Shifter sharpens or flattens the shifted pitch in order to keep the specified interval within the selected key and scale creating a true harmony.

  • Page 64: Detune, Pitch Shift

    No function when Pitch Shift is selected. Knob 4 No function when Pitch Shift is selected. Level KNOB 5 adjusts the Pitch Level ( ) of all pitch-altering effects in this pch LeVL module. Ranges from 0 to 99. GNX3000 Owner’ s Manual...

  • Page 65: Talker Tm

    Talker will clip making the words unintelligible. Adjust the mic level on the GNX3000’s rear panel so that the LEDs light, but stay below the clip level. (See Mic Level Optimization on page 26 for more information regarding mic level adjustment.) The mic level sensitivity ranges are from...

  • Page 66: Stompbox Modeling

    Effects and Parameters Stompbox Modeling The GNX3000 Modeling emulates the tones of the most popular distortion boxes ever used including the DOD® OD250 , Boss® DS-1 , Arbiter® Fuzz Face , Electro Harmonix® Big Muff , ProCo® RAT , DOD® Grunge , Boss®...

  • Page 67

    GNX3000 Owner’ s Manual Gain KNOB 2 controls the amount of Gain or Distortion in the Stompbox model. Range is from 0 to 99. Parameter 1 KNOB 3 acts as a Tone control for each Stompbox (no function on DOD 250...

  • Page 68: Noise Gate

    A Noise Gate can also be used to create an automatic swell in volume. The GNX3000 includes two different types of Noise Gates: Silencer and Pluck. The Silencer operates as a standard Noise Gate. The Pluck feature is designed to close after every note (depending on the Pluck Sensitivity).

  • Page 69: Chorus/mod Effects

    GNX3000 Owner’ s Manual Chorus/Mod Effects The Modulation Effects group is a multi-function module allowing you to select effects such as: Chorus, Flanger, Phaser, Triggered Flanger, Triggered Phaser, Univibe Tremolo, Panner, Vibrato, Rotary Speaker, AutoYa , YaYa , SynthTalk , Envelope Filter (auto wah), Detune, and Pitch Shift.

  • Page 70: Chorus

    Adjusts the left to right balance of the wet signal, Ranges from mod left 99 mod rght 99 Mod Level KNOB 5 controls the level ( ) of the Chorus. Ranges from mod levl *These Parameters are only available using the X-Edit Editor/Librarian software. GNX3000 Owner’ s Manual...

  • Page 71: Flanger

    GNX3000 Owner’ s Manual Flanger A Flanger uses the same principle as a Chorus but has a shorter delay time and adds regeneration (or repeats) to the modulating delay. This results in an exaggerated up and down sweeping motion to the effect.

  • Page 72: Phaser

    99 Mod Level KNOB 5 controls the level ( ) of wet and dry signal. Ranges from (all mod levl dry) to (all wet). *These Parameters are only available using the X-Edit Editor/Librarian software. GNX3000 Owner’ s Manual...

  • Page 73: Triggered Flanger, Triggered Phaser

    GNX3000 Owner’ s Manual Triggered Flanger A Triggered Flanger is the same sound as a regular Flanger but it lets you choose the starting point of the Flanger sweep. With a regular Flanger, the low frequency oscillator (LFO) is continually sweeping up and down. Therefore, when you begin to play, the flanger may be at the top, bottom, or any random point of the sweep.

  • Page 74: Unovibe, Tremolo

    ) of the modulating volume. Ranges from 0 Depth to 99. Parameter 3 KNOB 4 selects the type of wave form the modulation uses. Choices include: , and Triangle Sine Square Knob 5 No function when the Tremolo is selected. GNX3000 Owner’ s Manual...

  • Page 75: Panner, Vibrato

    GNX3000 Owner’ s Manual Panner An Auto Panner modulates the sound from left to right at an even rate. Parameter 1 KNOB 2 adjusts the rate ( ) at which the signal pans from side to side. Speed Ranges from 0 to 99.

  • Page 76: Rotary Speaker

    Selects the crossover frequency between the horn and rotor. Ranges from 200Hz 1500Hz Mod Mix KNOB 5 controls the mix (mod mix) of wet and dry signal. Ranges from (all dry) (all wet). *This Parameter is only available using the X-Edit Editor/Librarian software. GNX3000 Owner’ s Manual...

  • Page 77: Autoya Tm

    GNX3000 Owner’ s Manual AutoYa An AutoYa combines the characteristics of a Wah and a Flanger together creating an almost human vowel sound as if the guitar were saying “Yah.” The AutoYa automatically provides this animation by modulating the sound at an even rate.

  • Page 78

    Effects and Parameters YaYa The YaYa is an effect exclusive to DigiTech® products. The YaYa is controlled by the EXPRESSION PEDAL and combines the characteristics of a wah and a flanger together providing a unique talk box type of effect. As the EXPRESSION PEDAL is rocked back and forth, the guitar appears to say “Yah.”...

  • Page 79: Synthtalk Tm, Envelope Filter

    GNX3000 Owner’ s Manual SynthTalk SynthTalk is another effect exclusive to DigiTech®. It makes your guitar appear to speak based upon the dynamics of your playing style. Parameter 1 KNOB 2 adjusts the Attack ( ) of the synthesized voice. Ranges from 0 to...

  • Page 80: Pitch Shift, Detune

    ) to right 99 ( mod left 99 mod rght 99 Knob 4 No function when Pitch Shift is selected. Mod Level KNOB 5 controls the level ( ) of the shifted pitch. Ranges from 0 to 99. mod levl GNX3000 Owner’ s Manual...

  • Page 81: Delay

    Delay and lets you play over the top of a passage in the Delay loop). The Delay in the GNX3000 also includes a Ducker Threshold that lets you set the signal strength required before the Delay records. This feature lets you control the Delay with your playing.

  • Page 82: Reverb, Predelay

    The STATUS button turns the Reverb ( ) on and off. reverb Reverb Type KNOB 1 selects the type of Reverb or acoustic environment. The GNX3000 provides ten different environments to choose from including: = Studio studio = Wood Room...

  • Page 83: Expression Pedal Assignment, Expression Pedal Links 1-3, Wah Pedal

    Expression Pedal The EXPRESSION PEDAL on the GNX3000 can control up to 3 parameters in real time. Each parameter assigned to the EXPRESSION PEDAL can have specific ranges of how much the parameter is controlled by using the minimum and maximum controls.

  • Page 84: Amp Channel Footswitch, Lfos

    For instance: if the Amp Gain was assigned to LFO1, and the minimum value was set at 1 and the maximum value was set at 99, the GNX3000 would automatically sweep the amount of distortion from clean to distorted and back to clean.

  • Page 85: Expression Parameter Assignment List

    GNX3000 Owner’ s Manual LFO Links 1-2 Each preset has two LFOs that can each be assigned to a single parameter. Each LFO has the following assignment options: 1. Parameter Type (see attached parameter list) 2. Min Value 3. Max Value 4.

  • Page 86: Parameters

    WHAM PDL WHAM MIX SHIFTAMT SCALE KEY IPS LEVL DETUNE sHIFTAMT DTN LEVL PITCH SHIFTAMT PCH LEVL TALKER 1 MIC LEVL TALKER 2 MIC LEVL TALKER 3 MIC LEVL TALKER 4 MIC LEVL TALKER 5 MIC LEVL GNX3000 Owner’ s Manual...

  • Page 87: Stompbox Parameters, Noise Gate Parameters, Modulation Parameters

    GNX3000 Owner’ s Manual (Stompbox On/Off) Turns the Stompbox module on and off sboxonof Stompbox Parameters Active Stompbox Screamer drive tone level rodent dist filter volume ds dist dist tone level dod 250 gain level Big mp sustain tone volume...

  • Page 88

    (LFO 2 Speed) Controls the modulation speed of Expression LFO 2 LFo2 SPD * This Parameter is only available using the X-Edit Editor/Librarian software. **Delay Balance is replaced by Delay Spread when Spread Delay is selected. GNX3000 Owner’ s Manual...

  • Page 89: Creating A Preset, Select Channel 1 Amp And Cabinet

    The first step to create a custom preset of your own is to select a starting point. You can start with any existing preset, but for this example let’s start with Factory 1 Preset 40. Use the DATA WHEEL or FOOTSWITCHES (when the GNX3000 is in either Preset or Stompbox Mode) to select Factory 1 Preset Create a HyperModel For this example, we are going to use a vintage Tweed amp with an British 1x12 Cabinet, and warp it with a Rectified Amp using a British 4x12 cabinet.

  • Page 90: Select Channel 2 Amp And Cabinet, Adjust Channel 1 Tone Controls

    6. Rotate KNOB 4 to adjust the Tweed Amp’s Treble EQ Level(boost/cut). The range is from -12 dB ( ) to +12 dB ( 7. Rotate KNOB 5 to adjust the Tweed Amp’s Level. The range is from 0 to 99. GNX3000 Owner’ s Manual...

  • Page 91: Adjust Channel 2 Tone Controls, Gnx3000 Owner' S Manual

    GNX3000 Owner’ s Manual Adjust Channel 2 Tone Controls Like the Tweed amp in Channel 1, the Rectified amp in Channel 2 may need to be adjusted to suit your personal taste. To access the tone controls for Channel 2, do the following: 1.

  • Page 92: Adjust Eq/tune The Cabinets

    1. Press either the Chan One EQ or 2. Press the Status button to Chan Two EQ Amp Control button turn the EQ on and off 3.-7. Rotate Parameter knobs to adjust cabinet Tuning, EQ Center Frequencies, and Presence Level GNX3000 Owner’ s Manual...

  • Page 93: Warping Amp Channels Together

    GNX3000 Owner’ s Manual Warping Amp Channels Together When the Amps and Cabinets in Channel 1 and Channel 2 are dialed in to suit your taste, we can Warp their characteristics together to create a new HyperModel. To warp the amps do the following: 1.

  • Page 94: Select Models For The Preset' S Channels

    DATA WHEEL to select a an empty user location. The display should read (Empty) and the red numeric display should read if this is the first EMPTY HyperModel stored to your GNX3000. 6. Press the AMP SAVE button again to save to this Amp location. The display briefly reads AMP SaVeD (Amp Saved) and then returns to the name of the selected preset.

  • Page 95: Edit The Preset Effects, Select The Pickup Type

    GNX3000 Owner’ s Manual Edit the Preset Effects The next step to creating our example preset involves editing the effects. To edit the preset, do the following: 1. Press the EFFECT SELECT DOWN button. The display will briefly read EDIT the Matrix LED in the Wah-Pickup row will light.

  • Page 96: Turn The Compressor Off, Adjust The Noise Gate

    SILeNCeR 5. Rotate KNOB 2 to set the Threshold to (this may need to be adjusted depending upon your guitar). 6. Rotate KNOB 3 to set the Attack Time to (fast attack). GNX3000 Owner’ s Manual...

  • Page 97: Select And Adjust The Chorus, Turn The Delay Off

    GNX3000 Owner’ s Manual Select and Adjust the Chorus Next we want to thicken up the sound, by adding a subtle Chorus effect, in the following manner: 1. Press the EFFECT SELECT DOWN button again and the LED in the Chorus/Mod row lights.

  • Page 98: Select And Adjust The Reverb

    Damping to 40 3. Rotate Knob 1 4. Rotate Knob 2 5. Rotate Knob 3 to select Hall as to set the Reverb to set the Reverb the Reverb type PreDelay to 2 Decay to 15 GNX3000 Owner’ s Manual...

  • Page 99: Store The Preset

    The last step is to store our changes to a User Preset. If we changed presets or turned the GNX3000 off without storing these settings, it would forget what we had done and revert back to the original preset. To store the preset, do the following: 1.

  • Page 100: Storing/copying A Preset, Storing A Preset

    6. Select the User Preset location using the DATA WHEEL. 7. Press the STORE button again to finish. 5. Press Store again number 6. Select a User 7. Press Store again preset using the Data Wheel GNX3000 Owner’ s Manual...

  • Page 101: Copying A Preset, Preset Levels

    Modes. Preset Levels The GNX3000 presets each have an independent level control for quick balancing of the levels between presets. Preset Level is accessed by selecting the WAH – PICKUP row of the Matrix using the EFFECT SELECT buttons and then adjusting KNOB 5. The Preset Level adjusts the overall output level of the active Preset and the range is from 0 to 99.

  • Page 102: Footswitch Functions For Modes, Preset Mode - Green

    Footswitch 1 - Selects the first preset in the active bank. A second press puts the GNX3000 into Bypass or selects the previous preset if Preset Bounceback is enabled (see page 36 for more instructions on the Preset Bounceback function). Pressing and holding FOOTSWITCHES 1 and 2 together will activate the Learn-A-Lick feature (see page 34).

  • Page 103

    GNX3000 Owner’ s Manual Footswitch 3 - Selects the third preset in the active bank. A second press puts the GNX3000 into Bypass or selects the previous preset if Preset Bounceback is enabled (see page 36 for more instructions on the Preset Bounceback function). Pressing and holding FOOTSWITCHES 2 and 3 together will bypass the preset.

  • Page 104: Stompbox Mode - Yellow

    (see page 34 ). Stompbox Footswitch turns the Stompbox Modeling on and off. Pressing and holding FOOTSWITCHES 1 and 2 together will activate the Learn-A-Lick feature. Pressing and holding FOOTSWITCHES 2 and 3 together will bypass the preset. GNX3000 Owner’ s Manual...

  • Page 105

    GNX3000 Owner’ s Manual Chorus/Mod Footswitch turns the Chorus/Mod Effects on and off. Pressing and holding FOOTSWITCHES 2 and 3 together will bypass the preset. Pressing and holding FOOTSWITCHES 3 and 4 together accesses the Tuner. Delay Footswitch turns the Delay on and off. Pressing and holding FOOTSWITCHES 3 and 4 together accesses the Tuner.

  • Page 106: Record/drum Mode - Red

    Playback Footswitch - Starts playback of the included ProTracks Plus software. Pressing and holding FOOTSWITCHES 3 and 4 together accesses the Tuner. Pressing and holding FOOTSWITCHES 4 and 5 together will change the Footswitch Modes. GNX3000 Owner’ s Manual...

  • Page 107: Drum Machine, Control Panel - Drum Machine, Stop/play, Pattern, Level, Tempo

    PATTERN Press this button to select the Pattern library. Use the DATA WHEEL or PREV and NEXT buttons to select one of the GNX3000’s internal drum patterns. There are 79 different drum patterns and 5 metronome settings available including: Internal Drum Pattern List...

  • Page 108: Footswitch Operation

    Footswitch Functions for Modes Footswitch Operation When the GNX3000 is in Record/Drum Mode, four footswitches control drum machine operations. Drums Stop/Play Footswitch - Starts and stops playback of drum patterns. Drum Tempo Footswitch - Tapping this footswitch while the drum machine is on or off sets the playback tempo.

  • Page 109: Computer Recording Via Usb, Asio/mac Mode Vs. Wdm Mode, Suite

    When the GNX3000 ships from the factory, it is configured to record in ASIO/Mac mode. In ASIO/Mac mode, Windows® sees the GNX3000 as a 4-in, 2-out audio device. In WDM mode, Windows sees the GNX3000 as a 2-in, 2-out device and an additional 2-in 0-out device.

  • Page 110: Computer, Audio Routing For Usb Recording, Input Sources

    Pro Tracks Plus and its recording functions. Connecting the GNX3000 to the Computer The GNX3000 comes equipped with a USB cable that is to be connected to your computer whenever you will be recording or using the X-Edit Editor/Librarian. We recommend that you only use the USB cable that is shipped with the GNX3000 since it has been tested and approved for this specific use.

  • Page 111: Usb 1-2 Source

    The Input Sources signal combinations are as follows: USB 1-2 Source stereofx All input sources that are routed through the GNX3000’s effects are sent as a stereo pair up USB 1 and 2 channels. Drums, Dry Mic, and Dry Line are not recorded. steroall All input sources that are routed through the GNX3000’s effects, Drums, Dry...

  • Page 112: Usb 3-4 Source

    Dry Mic signal is sent up the USB 1 channel. Nothing is sent up the USB 2 channel. drums st The GNX3000 drums playback is sent in stereo up the USB 1 and 2 channels. drums mn The GNX3000 drums playback (summed to mono) is sent up the USB 1 channel.

  • Page 113: Guitar Signal Routing

    USB port. Path C taps the guitar signal at the output of the GNX3000 and includes any effects processing that may be used. Signals recorded from USB Send Path A can be played back later through the GNX3000 for re-amping.

  • Page 114: Mic Signal Routing

    MIC INPUT and sends unprocessed signal up to the USB port. Path C taps the signal at the output of the GNX3000 and can include any effects processing that may be used. Below is a matrix to show where the signal is tapped based on how the Mic, USB 1-2 Source, and USB 3-4 Source settings are configured.

  • Page 115: Line Input Signal Routing

    • E • • E • • mic dry mic dry the USB port. Path C taps these signals at the output of the GNX3000 and can C, E C, E C C, E E • • E • •...

  • Page 116: Setting Up The Gnx3000 Midi Device

    GNX3000’s inputs and to enable the Hands-Free recording capabilities the GNX3000 offers. NOTE: Refer to the “Installing the GNX3000’s Software Suite” section on page 101 before connecting the GNX3000 to the USB port on your PC and using Pro Tracks Plus. Hands-Free Recording Capabilities Pro Tracks Plus software must be installed on your computer in order to use the recording capabilities of the GNX3000.

  • Page 117

    4. Click the OK button. DigiTech Hands-Free should now be displayed as the Connected Surface in the Control Surfaces Window. 5. Click the Close button. 6. Pro Tracks Plus can now respond to the GNX3000 for automated recording functions. Configuring Pro Tracks Plus for Recording in ASIO Mode 1.

  • Page 118: Control Panel And Recording Setup

    GNX3000’s audio inputs, are handled for both processing and recording. Here is where you can route audio from the MIC and LINE INPUTS through the GNX3000 effects as well as specify what signals are sent up USB to be recorded. SHIFT When this button is lit, the secondary functions labeled below specific buttons are now active when these buttons are pressed.

  • Page 119: Computer Recording With A Mac

    An installer is provided for X-Edit, the Editor/Librarian application. Just insert the disc and follow the on-screen prompts. If you’re using a Mac, use the GNX3000 in ASIO/MAC USB mode (this is the default USB mode from the factory). To verify Audio MIDI connection, use Apple’s Audio MIDI Setup application found in the Applications/Utilities folder.

  • Page 120: Recording A Track Or Tracks, Playing Back A Recorded Track

    The GNX3000’s FOOTSWITCHES are capable of controlling the Pro Tracks Plus recording software, creating a Hands-Free recording interface. To do this, the GNX3000 must be connected to the computer via the included USB cable and the Pro Tracks Plus application must be installed and open.

  • Page 121: Recording Multiple Tracks, Using The Gnxfc For Hands-free Computer Recording Functions

    Using the GNXFC for Hands-Free Computer Recording Functions The GNX3000 is equipped with a footswitch jack that lets you connect an optional GNXFC for controlling the GNX3000’s record functions This 3-button footswitch features functions for STOP/UNDO, RECORD, and PLAY.

  • Page 122: Re-amping A Guitar Track

    Using one of the Dry Guitar configurations for recording gives you the opportunity of playing a dry take back into the GNX3000 for re-processing. The advantages of having this feature are you can experiment playing the dry guitar take back through different amp models, effects, or entirely new presets once you have your other tracks recorded.

  • Page 123: Recording The Gnx3000 Drums As Audio

    2. Select one of the templates and click the OK button. This will open up a new recording session. 3. On the GNX3000, use the either the USB 1-2 SRC or USB 3-4 SRC buttons to select drums stereo drums Mono 4.

  • Page 124: Recording The Gnx3000 Drums And Midi, Midi And Recording, Usb Playback Mix

    Computer Recording Functions Recording the GNX3000 Drums and MIDI You can use MIDI drum files for playing the GNX3000 drum samples as long as the events are mapped to the MIDI notes shown on page 128. The drum samples of the GNX3000 only respond to MIDI messages transmitted on MIDI channel 10, which is the default channel for General MIDI drums.

  • Page 125: Usb 1-2 Level/usb 3-4 Level

    6dB going up USB 1. To increase or decrease the level of audio going up to the computer, follow these steps. 1. Play/sing through the GNX3000 and check the level of signal reaching the recording software (consult the Pro Tracks Plus User’s Guide for information...

  • Page 126: Utilities, Volume Pedal Update, Preset Bounceback

    Utilities The Utility section contains all of the menus for assigning global functions to the GNX3000. Global functions affect the GNX3000 in its entirety rather than on a per preset basis. The Utility menus include: Volume Pedal Update, Expression Pedal Calibration, Bounce-Back, Bank Naming, MIDI Channel, MIDI Sysex Dumps, Amp Dumps, MIDI Mapping, MIDI Merge, and Factory Reset.

  • Page 127: Expression Pedal Calibration, Bank Names

    6. When finished, press EXIT. Bank Names The GNX3000 lets you customize the names of the 13 User Banks where the 65 User Presets reside. Customized Bank names aids in quickly identifying the User Bank containing the presets you may need for a particular song or set. The procedure for naming the User Banks is as follows: 1.

  • Page 128: Midi Channel, Bulk Dump, Preset Dump

    This operation performs a System Exclusive (SysEx) MIDI Bulk Dump that uploads all the GNX3000 presets and utility data to a SysEx librarian. This is useful for making a backup copy of all your customized settings. The procedure for performing a Bulk Dump is as follows: 1.

  • Page 129

    GNX3000 Owner’ s Manual 1. Connect a MIDI cable from the GNX3000 MIDI Out to the MIDI In of a MIDI recording device. 2. Press the UTILITY button. The Utility button’s LED will light. 3. Use the PREV or NEXT buttons to select (Preset Dump).

  • Page 130: Midi Merge, Factory Reset

    GNX3000 receives the MIDI program number shown to the right of the the alpha-numeric display. 5. Rotate the DATA WHEEL to select the preset number the GNX3000 will use when it receives the selected MIDI program change. 6. When finished, press EXIT.

  • Page 131

    TOE DowN down) and then press the flashing FOOTSWITCH 3. 6. When the display reads , rock the EXPRESSION PEDAL back (toe up) TOE UP and press the flashing FOOTSWITCH 4. 7. The GNX3000 will then restart. GNX3000 Owner’ s Manual...

  • Page 132: Troubleshooting Guide

    • Check the Utility menu handfree is set to US for recording to Pro Tracks. I can’t hear audio playback from Pro Tracks Plus. • If the ‘Reamp’ mode in the GNX3000 is active try switching to a different mode like ’...

  • Page 133

    GNX3000 Owner’ s Manual USB 1-2 Source menu. • Make sure the track that you are recording on has the correct input assignment and that it is armed. I can’t get Re-Amping to work. • See the Re-Amping a Guitar Track section of this Owner’s Manual.

  • Page 134

    • Verify the driver setup on the driver tab. • Make sure the GNX3000 is set as the timing master for recording and playback. • Make sure Service Pack 1A or later (Windows XP®) has been installed. Click on the Advanced Tab and set the Buffer Size to 256.

  • Page 135

    • Make sure when you export the audio that you choose 16 bit not 24. Using a Mac to receive audio stream from the GNX3000, the Mac USB input and output is visible, but so is the PC selection. Can these be removed? •...

  • Page 136: Appendix, Midi Implementation Chart, General Midi Drum Sample List

    Short Guiro High Tom Long Guiro Ride Cymbal 1 Claves Chinese Cymbal Hi Wood Block Ride Bell Low Wood Block Tambourine Mute Cuica Splash Cymbal Open Cuica Cowbell Mute Triangle Crash Cymbal 2 Open Triangle Vibraslap GNX3000 Owner’ s Manual...

  • Page 137: Midi Cc List

    GNX3000 Owner’ s Manual MIDI CC List Parameter Parameter Pickup Type/On/Off Ch 2 Cabinet Tuning CC49 Pickup Type/Type Ch 2 EQ On/Off CC50 Expression Pedal Ch 2 Bass Frequency CC51 Volume Post Ch 2 Bass CC52 Volume Pre Ch 2 Midrange Frequency...

  • Page 138: Specifications

    100 mW per channel at 50 Ohms Digital Connections: Footswitch: 1/4” jack (compatible with optional GNXFC) MIDI In: 5-pin Din MIDI Out/Thru: 5-pin Din Universal Serial Bus (USB): Type B, supports USB1.1 Full Speed (12 Mbps Bandwidth USB 2.0 compatible) GNX3000 Owner’ s Manual...

  • Page 139

    GNX3000 Owner’ s Manual Analog Inputs to Analog Outputs: Guitar Input to 1/4” Outputs S/N ratio: > 108 dB A-weighted; ref = max signal @ 1kHz, 22kHz measurement bandwidth Frequency Response: 20 Hz - 17 kHz (+0 / - 3 dB) THD+N: <...

  • Page 140

    500 MHz processor speed (1.2 GHz recommended) 128 MB RAM (512MB recommended) 100 MB hard disk space for full install EIDE/Ultra DMA 7200 RPM hard disk or better Minimum Mac Computer System Requirements OS 10.3 or higher GNX3000 Owner’ s Manual...

  • Page 141: Bank And Preset Names

    GNX3000 Owner’ s Manual Bank and Preset Names GNX3000 Owner’ s Manual...

  • Page 142

    PH (801) 566-8800 FAX (801) 566-7005 International Distribution 8760 S. Sandy Parkway Sandy, Utah 84070 USA PH (801) 566-8800 FAX (801) 566-7005 DigiTech, GeNetX, Audio DNA, Guitar Workstation, and GNX3000 are trademarks of Harman Music Group Inc. GNX3000 Owner’s Manual 18-6288-B www.digitech.com...

Comments to this Manuals

Symbols: 0
Latest comments:
