Table 4: Main Menu (Continued)
Menu Description
Port Security
Switch Shows information about MAC address learning for each
port, including the software module requesting port security
services, the service state, the current number of learned
addresses, and the maximum number of secure addresses
allowed
Port Shows the entries authorized by port security services,
including MAC address, VLAN ID, the service state, time
added to table, age, and hold state
NAS Shows global and port settings for IEEE 802.1X
Switch Shows port status for authentication services, including
802.1X security state, last source address used for
authentication, and last ID
Port Displays authentication statistics for the selected port –
either for 802.1X protocol or for the remote authentication
server depending on the authentication method
ACL Status Shows the status for different security modules which use
ACL filtering, including ingress port, frame type, and
forwarding action
DHCP Dynamic Host Configuration Protocol
Snooping Shows statistics for various types of DHCP protocol packets
Statistics
Relay Displays server and client statistics for packets affected by
Statistics the relay information policy
ARP Inspection Displays entries in the ARP inspection table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
IP Source Guard Displays entries in the IP Source Guard table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
AAA Authentication, Authorization and Accounting
RADIUS Displays status of configured RADIUS authentication and
Overview accounting servers
RADIUS Details Displays the traffic and status associated with each
configured RADIUS server
LACP Link Aggregation Control Protocol
System Status Displays administration key and associated local ports for
each partner
Port Status Displays administration key, LAG ID, partner ID, and partner
ports for each local port
Port Statistics Displays statistics for LACP protocol messages
Spanning Tree
Bridge Status Displays global bridge and port settings for STA
Port Status Displays STA role, state, and uptime for each port
Port Statistics Displays statistics for RSTP, STP and TCN protocol packets
MVR Multicast VLAN Registration
Statistics Shows statistics for IGMP protocol messages used by MVR
Group Information Shows information about the interfaces associated with
multicast groups assigned to the MVR VLAN
– 37 –
| Using the Web Interface
C 3
HAPTER
Navigating the Web Browser Interface
