KEY
1) Rear shock absorber
2) Passenger right footrest
(snaps closed/open)
3) Taillight
4) Glove/tool kit compartment
5) Passenger saddle
(glove/tool kit compartment
cover)
4 5 6 7 8
23 22
6) Passenger grab strap
7) Engine Control Unit
8) Right side panel
9) Fuel tank
10)Coolant expansion tank
cap
11)Fuel tank filler cap
12)Air cleaner
9 10 11 12 13
21 20 19 18
13)Right rearview mirror
14)Front brake fluid reservoir
15)Secondary fuse carrier (15A)
16)Right side fairing
17)Horn
18)Lower fairing
19)Expansion tank
20)Rear brake fluid reservoir
use and maintenance RSV 1000 R
14
15
16
17
21)Rear brake master cylinder
22)Rear brake lever
23)Rider right footrest
