Saddles .................................................................. 2
Vehicle max. load
(rider+passenger+luggage)....................................  414.5 lb (188 kg) -
GEAR RATIOS Ratio
1 st
2 nd
3 rd
4 th
5 th
6 th
DRIVE CHAIN Type ....................................................................... sealed, with no master link
Model ..................................................................... 525
Type ....................................................................... electronic injection (Multipoint)
FUEL SUPPLY
SYSTEM
Choke..................................................................... Ø 2.24 in (Ø 57 mm)
FUEL SUPPLY Fuel ........................................................................ unleaded gasoline minimum octane rating (M+R)/2 method 90
FRAME Type ....................................................................... Double beam frame, inclined, with light alloy cast elements
Rake....................................................................... 25°
Trail (with front tire 120/70) .................................... 4 in (101.7 mm)
SUSPENSIONS Front.......................................................................
Stroke..................................................................... 4.72 in (120 mm)
Rear .......................................................................
Wheel stroke .......................................................... 5.23 in (133 mm)
BRAKES Front.......................................................................
Rear .......................................................................
WHEEL RIMS Type ....................................................................... light alloy with withdrawable pin
Front....................................................................... 17" x MT 3.50
Rear ....................................................................... 17" x MT 6.00
Primary Secondary
31/60 = 1 : 1.935 15/34 = 1 : 2.267
19/31 = 1 : 1.632
20/26 = 1 : 1.300
22/24 = 1 : 1.091
25/24 = 1 : 0.960
26/23 = 1 : 0.885
427.3 lb (194 kg)
Final ratio
16/40 = 1 : 2.500
upside-down telescopic adjustable fork with hydraulic operation, fork leg Ø
1.69 in (Ø 43 mm)
double-sided aluminium alloy swinging arm with progressive linkage and
APS system. Hydro-pneumatic shock absorber with adjustable
compression/rebound/spring preload and length.
with double floating disc brake Ø 12.60 in (Ø 320 mm); calipers with four
pins Ø 1.34 in (Ø 34 mm)
disc brake Ø 8.66 in (Ø 220 mm); caliper with double pin Ø 1.26 in (Ø 32
mm)
use and maintenance RSV 1000 R
Total ratio
1:10.968
1:7.895
1:6.290
1:5.279
1:4.645
1:4.280
- RSV 1000 RFACT
