Chapter 4 — Loading Media

Peel-Off (Self-Strip)

34 EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
13 Press Feed to advance the media and adjust the media feed.
Feed
The EasyCoder PX4i printer can print on labels, tickets, tags, and
continuous stock in various forms.
This section describes the case when self-adhesive labels are
separated from the liner immediately after printing, which
requires an optional internal liner/batch takeup unit. For more
information, see "Liner/Batch Takeup Kit" on page
also known as "Self-strip" operation.
Press Feed when loading the same type of media as before. When
switching to a new type of media, or if the printer does not feed
out the media properly, simultaneously press Shift and Feed to
perform a "testfeed."
Peel-off can only be used for self-adhesive labels with liner.
An optional label-taken sensor can hold the printing of the next
label in a batch until the present label has been removed. See
"Label Taken Sensor" on page
Note: Peel-off operation sets high demands on the media for
proper label stiffness, release characteristics of the adhesive and
liner, resistance against electrostatic charge, and so on. If these
specific requirements are not met, the labels will not dispense
properly. Consult your media supplier or test the media to make
sure it is suitable for your application.
105.
103. This is
