Chapter 2 — Installation
Print Mechanism
Pressure
arm
Thermal printhead
Upper label stop sensor
guide (removable)
Lower label stop sensor guide
(removable)
10
EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
The print mechanism features a high-performance thermal
printhead with quick-mount fittings to facilitate replacement.
Tear bar
Label stop sensor
position adjustment
screw
Print Mechanism
Pressure arm
locking knob
Printhead
pressure
adjustment
knob
Edge
guide
Printhead lift
lever
