Turnover Jam - DataCard RP90 User Manual

Turnover jam

Tips – Turnover jam
• Some internal parts may
be hot. Wear a glove
when rotating the
turnover table.
RP90 Plus E and RL90 User Guide
If a card jams in the card turnover section, "Jam (Turnover)" is displayed on
the LCD panel. To remove the jammed card:
Slide the door latch to the right and open the printer door.
1
Press the ink ribbon cartridge eject button and remove the ink ribbon
2
cartridge.
Remove the jammed card.
3
— If you can reach the jammed card, pull it out.
— If the jammed card is sticking out of the turnover table, push it back
into the table, and rotate the table slowly until the card can be
removed.
Replace the ink ribbon cartridge and initialize the ink ribbon as
4
described in "Initialize the ink ribbon" on page 16
Printer error recovery
.
53
