NX-8-EUR Control Panel
Installation manual

Advertisement

Table of Contents
loading

Related Manuals for GE NetworX NX-8-EUR

Summary of Contents for GE NetworX NX-8-EUR

  • Page 1 Security NetworX Series NX-8-EUR Control Panel Installation manual imagination at work...
  • Page 2 NX-8-EUR Installation manual Page 2 02/07/06...

  • Page 3: Table Of Contents

    ONTENTS CONTENTS ....................................3 GENERAL INFORMATION................................5 ORDERING INFORMATION ................................. 5 FEATURE DEFINITIONS ................................6 PROGRAMMING THE NX-8 KEYPADS ............................14 ....................................14 ROGRAMMING THE KEYPADS NX-148 LCD ................................18 ROGRAMMING THE KEYPADS NX-148 LCD ............................... 21 EYPAD FUNCTIONS FOR THE KEYPAD PROGRAMMING THE NX-8 CONTROL PANEL........................26 NX-8...
  • Page 4 ......................... 60 ETUP FOR AUTO TEST AUTO ARM AND OPENING CLOSING TIMES ............................62 OMMUNICATOR CODES FOR SLOW SPEED FORMATS ONLY ..................................70 ROGRAMMING PARTITION PARAMETERS ................................ 75 ROGRAMMING ZONE CONFIGURATION GROUPS NX-8-EUR PROGRAMMING WORKSHEETS..........................86 BOARD INSTALLATION ................................102 NX-8-EUR WIRING DIAGRAM..............................103 TERMINAL DESCRIPTION................................104 TECHNICAL SPECIFICATIONS..............................105 NX-8 ....................................

  • Page 5: General Information

    ENERAL INFORMATION The NX-8-EUR (from now on called NX-8) NetworX from Caddx represents a new approach to the design of security systems. The NX-8 is probably the most flexible, durable, and user- friendly control panel ever seen in our industry. Its features include sophisticated software enabling as many as 99 users to interface up to 48 zones, 8 partitions, with access, audio verification, and input/output modules, all reported with SIA and Contact ID formats which are extremely fast and very comprehensive.

  • Page 6: Feature Definitions

    EATURE DEFINITIONS Abort If this option is enabled, the NX-8 will wait the programmed number of seconds (0-255) in location 40 prior to sending an alarm. During this delay time, the “Cancel” LED will flash. To abort the report, type in a code and press the [Cancel] key. The LED will go out. If the report is not aborted within the allotted time, the LED will go out when the report is sent.
  • Page 7 Auto-test This feature will cause the panel to call the central station, in order to report a communicator test at a specified interval (see location 51). Also, the auto-test report may be enabled ONLY when the control panel is armed see location 37 segment 4). Auxiliary outputs The NX-8 has two programmable relay outputs and four open collectors which can be used to activate LED’s, sirens, flashes, etc.
  • Page 8 Code required options The NX-8 can be programmed to require a code in order to bypass zones and/or to initiate a download using the [*]-[9]-[8] or [*]-[9]-[9] function (see locations 23 segment 2 and 41). Communication formats The NX-8 can report in multiple formats. You are recommended to use Contact ID or SIA formats if possible.
  • Page 9 End of line resistor defeat The NX-8 can be programmed to make zones 1-8 for normally closed operation only, eliminating the need of the end of line resistors on these zones. When a zone is programmed for normally closed operation, a short on that zone will not change the loop condition, and an open on that zone will produce a faulted condition.
  • Page 10 Fire alarm verification When this feature is enabled, the NX-8 will verify a fire alarm by requiring more than one trip on a smoke detector (the same or another one) within a specified time (120-255 seconds) before it generates an alarm (see location 40 segment 9). First opening/last closing report for multiple partitions If this feature is enabled, the NX-8 will only transmit a closing report after ALL partitions have been armed.
  • Page 11 Keypad tamper If this option is enabled, the NX-8 will disable the keypad for 60 seconds, and will communicate a tamper signal to the central station whenever 30 keypresses are entered without producing a valid code (see location 23 segment 1). Keyswitch arm/disarm Any zone on the NX-8 can be programmed as a momentary or maintained keyswitch zone.
  • Page 12 Program code The factory default for the “Go To Program” code is [9]-[7]-[1]-[3] when using a 4-digit code; or, if the 6-digit option is used, the default is [9]-[7]-[1]-[3]-[0]-[0]. The program code can also be used as an arm/disarm code. If it is used as an arm/disarm code, and if open/close reports are sent, the user code will be 255 (see location 43).
  • Page 13 Two call answering machine defeat If this option is enabled, two telephone calls must be made to the premises in order to defeat an answering machine. On the first call, let the phone ring one or two times. The control panel will detect these rings and start a 45-second timer;...

  • Page 14: Programming The Nx-8 Keypads

    NX-8 ROGRAMMING THE KEYPADS Programming the LED keypads This section describes how to program the address and partition for each keypad, and it also explains the options that are available. The address of the keypad is important because the panel uses it to supervise the keypads. The factory default for the master code is [1]-[2]-[3]-[4] when using a 4-digit code, or [1]-[2]- [3]-[4]-[5]-[6] for a 6-digit code.
  • Page 15 [*]-[9]-[4] SET KEYPAD NUMBER AND PARTITION Enter [*]-[9]-[4]-[program code]- the “Service” LED and the “Instant” LED will flash. Enter the keypad number (1-8). Press [*]- the “Instant” LED will illuminate steadily, and the “Service” LED will carry on flashing. Enter the partition number for the keypad. The keypad will automatically exit this mode now).
  • Page 16 [*]-[5] CHANGING USER CODES Enter [*]-[5]-[master code]- the “Ready” LED will flash. Enter the 3 digit user number (always 3 digits, such as “003” for user 3)- the “Ready” LED will illuminate steadily. Enter the new user code designated for the person in question - the “Ready” LED will flash, indicating that the code has been accepted.
  • Page 17 NOTE: ANY MASTER ARM/DISARM CODE CAN ADD OR CHANGE A USER CODE IF THE MASTER CODE HAS ACCESS TO THE SAME PARTITIONS AS THE CODE BEING ADDED/CHANGED. CONSEQUENTLY, WHEN PROGRAMMING THE USER CODES FOR A PARTITIONED SYSTEM, LEAVE AT LEAST ONE CODE WITH ACCESS TO ALL PARTITIONS. UNLESS YOU DO THIS, YOU WILL NOT BE ABLE TO ADD NEW USERS.

  • Page 18: Programming The Nx-148 Lcd Keypads

    Programming the NX-148 LCD keypads This section describes how to program the address and partition for each keypad, and it also explains the options that are available. The address of the keypad is important because the panel uses it to supervise the keypads. The factory default for the Master code is [1]-[2]-[3]-[4] when using a 4-digit code, or [1]-[2]- [3]-[4]-[5]-[6] for a 6-digit code.
  • Page 19 [*]-[9]-[3] SET KEYPAD OPTIONS Enter [*]-[9]-[3] The LCD screen will prompt for a code. Enter [program code] The LCD will now prompt you through the options listed in the following chart. The current state of the option will be shown in the lower right corner of the display.
  • Page 20 Remark : In the menu “Select an option” 8 additional options can be selected. The options 5 until 8 are not used for the moment and may therefore not be selected. The options 1 and 4 are described below: Option 1 : On the LCD screen “press * for help”.

  • Page 21: Keypad Functions For The Nx-148 Lcd Keypad

    Keypad functions for the NX-148 LCD keypad The LCD keypads have a bilingual user’s interface. As a result, you can simply select a user’s function on the menu. You can consult the menu by entering the [*] key. The user of the system can easily switch from one user’s interface to another and the other way around.
  • Page 22 [*]-[9]-[0] READING THE EVENT LOG The NX-8 has a 512-event log which can be retrieved using a master code. This log contains a listing of the last 512 events along with the date, time, and partition where each event occurred. Press [*]-[9]-[0] The LCD screen will prompt you for a code.
  • Page 23 [*]-[▲] VIEW ZONE STATUS Enter [*]-[▲] The LCD screen will display the zone status. Use the ‘up’ and ‘down’ scroll The LCD screen will display the list of ALL zones, in keys to browse through the sequential order by zone number. descriptions.
  • Page 24 [*]-[6] ASSIGNING AUTHORITY LEVEL Note: You must be authorized to access the partition that you wish to add to, or remove from, another person’s authority. Enter [*]-[6] The LCD screen will prompt for a code. Enter [master code] The LCD screen will prompt for a user number. Enter the 3 digit user number The LCD screen will prompt for a new code.
  • Page 25 [*]-[CHIME] ACTIVATING WALKTEST Enter [*]-[CHIME] The LCD screen will prompt you for a “master code”. Enter [mastercode] The LCD screen will display the “walktest mode” Activate all sensors to test Each activation of a sensor is confirmed with a “ding dong”...

  • Page 26: Programming The Nx-8 Control Panel

    NX-8 C ROGRAMMING THE ONTROL ANEL Programming the NX-8 control panel via the LED keypad ENTERING THE PROGRAM MODE To enter the program mode, press [*]-[8]. When you do this, the five function LED’s (Stay, Chime, Exit, Bypass, and Cancel) will begin to flash. Next, enter the “Go To Program Code” (FACTORY DEFAULT IS [9]-[7]-[1]-[3]).

  • Page 27: Exiting The Program Mode

    EXITING THE PROGRAM MODE When all the desired changes in programming have been made, it is time to exit the program mode. Press the [Exit] key to exit this programming level, and go to the “Select a Module To Program” level. If no additional modules are to be programmed, press the [Exit] key again to exit the program mode.

  • Page 28: Loading Factory Defaults

    LOADING FACTORY DEFAULTS To load the factory defaults, enter the program mode using the procedure on page 24, then type [9]-[1]-[0]-[#]. The keypad will beep 3 times to indicate that loading is in progress. The loading takes about 6 seconds. ENROLLING MODULES AND KEYPADS For supervision purposes, the presence of all keypads, zone expanders, wireless receivers, and any other modules connected to the data terminal can automatically be found and stored in...
  • Page 29 PROGRAMMING EXAMPLE (Feature selection data) Location 23, segment 1 1 = Quick arm 2 = Re-exit 3 = Auto bypass 4 = Silent keypad panic 5 = Audible keypad panic 6 = Keypad auxiliary 1 7 = Keypad auxiliary 2 8 = Multi-keypad tamper Press the key on the num eric keypad that corresponds to the feature you wish to enable/disable.

  • Page 30: Programming The Nx-8 Control Panel Via Lcd Keypad

    Programming the NX-8 control panel via LCD keypad ENTERING THE PROGRAM MODE To enter the program mode, press [*]-[8]. The LCD screen will now prompt you for the programming code. Next, enter the “Go To Program Code” (FACTORY DEFAULT IS 9713). If the “Go To Program Code”...
  • Page 31 CHARACTER DATA: Character data is used to enter LCD text when programming (see [*]-[9]- [2] feature for custom messages). Custom zone descriptions and messages are stored using character or ASCII data types. This information is programmed using the bottom line of the display as a text editor.

  • Page 32: Exiting The Program Mode

    ALPHANUMERIC CHARACTER TABEL ä ä ô & ö ç é è ê û ü î < > à ” ° EXITING THE PROGRAM MODE When you have made all the desired changes in programming, it is time to exit the program mode.

  • Page 33: Important Remarks

    MPORTANT REMARKS Tamper memorization If location 37 segment 6 option 8 is set, tamper alarm indications (zone tampers and box tampers) can be erased by entering a valid user code. If location 37 segment 6 option 8 is not set, tamper alarm indications (zone tampers and box tampers) can only be erased by entering the program mode.

  • Page 34: Clc/Ts 50131-3 Compliancy

    CLC/TS 50131-3 Compliancy In order to be compliant with the technical specification CLC/TS 50131-3 (Alarm systems – Control and indicating equipment), the following guidelines must be taken into account : • Zone configuration types reporting a Hold-up alarm (event code 0) should : not be bypassable not have swinger shutdown enabled •...

  • Page 35: Control Panel Programming Locations

    ONTROL ANEL PROGRAMMING LOCATIONS For most routine installations, the “Quick Start” option will allow for enabling a majority of the options available with the NX-8, when communicating in Contact ID or SIA formats and without partitioning. The “Quick Start” locations can be identified by the symbol.

  • Page 36: Format Selections

    Segment 2- Phone N° 1 backup control: Programming a “0” in segment 2 of this location will cause the NX-8 to make the designated number of attempts to phone N°2 before setting the “Fail To Communicate” condition and stop reporting. Programming a “1” in this segment will cause the NX-8 to stop trying to communicate after the designated number of attempts have been made to phone N°1.

  • Page 37: Reporting Events To Phone Number 1

    Reporting events to phone number 1 Phone N°1 has two programming locations that are used to select the events which are reported to this phone number. Location 4 is used to select which events are reported to phone N°1. Location 5 is used to select which partitions are reported to phone N°1.

  • Page 38: Telephone Number 2

    LOCATION 5 - PARTITIONS REPORTED TO PHONE N° 1 (1 segment, feature selection data) Location 5 is used when the events to be reported to a phone number are based on the partition, regardless of the event. If you use this location, you should program location 4 as “0”. Segment 1 Partition 1 Partition 2...

  • Page 39: Reporting Events To Phone Number 2

    LOCATION 9 - DIAL ATTEMPTS/BACKUP CONTROL FOR PHONE N° 2 (2 segments, numerical data) Segment 1, dial attempts: segment 1 of location 9 is used to enter the number of dial attempts (1 to 15 attempts) that the communicator will make to phone N°2 before it ends the notification process.

  • Page 40: Telephone Number 3

    Segment 2 Zone and box tamper Auxiliary power overcurrent, and restore Wireless sensor missing and restore Wireless sensor low battery and restore Expander trouble and restore (keypads are considered as expanders) Fail to communicate Alarm restore Tamper restore LOCATION 11 - PARTITIONS REPORTED TO PHONE N° 2 (1 segment, feature selection data) Location 11 is used when events to be reported to a phone number are based on the partition, regardless of the event.

  • Page 41: Reporting Events To Phone Number 3

    LOCATION 14 - COMMUNICATOR FORMAT FOR PHONE N° 3 (1 segment, numerical data) Location 14 contains the communicator format used to transmit to the receiver that is connected to phone N°3. Consult the instruction manual for your central station receiver in order to determine which format is compatible, and select from the 15 formats listed on page 33.
  • Page 42 LOCATION 16 - EVENTS REPORTED TO PHONE N° 3 (2 segments, feature selection data) Segment 1 Alarms Opening and closings Zone bypass and bypass restores Zone trouble and trouble restores Power fail (AC failure), low battery, power restore (AC restore), and low battery restore Bell cut, bell cut restore, telephone line restore Test reports...

  • Page 43: Special Formats

    Special formats LOCATION 18 - CUSTOM COMMUNICATOR FORMAT (see locations 2, 8, and 14) Segment 1 On for 1800hz transmit; Off for 1900hz On for 2300hz handshake; Off for 1400hz On for checksum parity; Off for double round parity On for 2 digit event code; Off for 1 digit event code On for extended reporting;...

  • Page 44: Download Parameters

    Download parameters LOCATION 19 - DOWNLOAD ACCESS CODE (8 segments, numerical data) Location 19 contains the eight-digit access code that the NX-8 must receive from the downloading software before the panel will allow downloading. The factory default code is 84800000. LOCATION 20 - NUMBER OF RINGS TO ANSWER (1 segment, numerical data) Location 20 contains the number of rings to answer for a download.

  • Page 45: Feature And Report Selections (For Partition 1)

    Feature and report selections (for partition 1) LOCATION 23 - PARTITION 1, FEATURE AND REPORT SELECTIONS (5 segments, feature selection data) Location 23 is used to enable certain features that the user can access or see from the keypad of the system. In addition, certain communicator reports are enabled in location 23. Each of these features can be enabled by partition.

  • Page 46: Entry/Exit Timers

    Segment 5 On: Disables auto-bypassing of force armable zones at the end of the exit delay Reserved Reserved Reserved Reserved Reserved Reserved Reserved Entry/Exit timers LOCATION 24 - ENTRY / EXIT TIMERS (6 segments, numerical data) Location 24 is used to program the entry/exit times. There are 2 separate entry/exit times. Segment 1 Entry time 1 This is the entry time that will be used when a delay 1...

  • Page 47: Zone Configurations And Partition Selection

    Zone configurations and partition selection DEFAULT ZONE CONFIGURATIONS Zones can be programmed to be one of thirty different zone configurations (zone types). The default zone configurations are listed below. Programming locations 110-169 can customise all zone configurations. DATA R conf. DESCRIPTION OF DEFAULT CONFIGURATION DAY ZONE Instant when system is armed;...
  • Page 48 INTERIOR FOLLOWER WITH “CROSS ZONE” ENABLED This zone will be instant when the system is armed and no entry or exit delay is being timed. It is delayed during entry and exit delay times. If a “Cross Zone” is not being timed, it will start a “Cross Zone”...
  • Page 49 INSTANT ZONE WITH CHIME ENABLED A trip will create an alarm when the system is armed. When the control panel is disarmed and the chime mode has been set, this zone will act as a chime zone. FOLLOWER ZONE WITH CHIME ACTIVATED This zone will be instant when the system is armed and no entry or exit delays are being timed.
  • Page 50 LOCATION 25 - ZONES 1-8 CONFIGURATION GROUP (8 segments, numerical data) Location 25 contains the configuration group (zone type) for zones 1-8. Segment 1 is for zone 1, and segment 8 is for zone 8. You will find the default configurations in the table above. LOCATION 26 - PARTITION SELECT, ZONES 1-8 (8 segments, feature selection data) Location 26 is used to select the partition(s) in which zones 1 - 8 reside.
  • Page 51 LOCATION 29 - ZONES 17-24 CONFIGURATION GROUP (8 segments, numerical data) Location 29 contains the configuration group (zone type) for zones 17-24. Segment 1 is for zone 17, segment 8 is for zone 24. You will find the default configurations in the table above. LOCATION 30 - PARTITION SELECT, ZONES 17-24 (8 segments, feature selection data) Location 30 is used to select the partition(s) in which zones 17-24 reside.
  • Page 52 LOCATION 33 - ZONES 33-40 CONFIGURATION GROUP (8 segments, numerical data) Location 33 contains the configuration group (zone type) for zones 33-40. Segment 1 is for zone 33, and segment 8 is for zone 40. You will find the default configurations in the table above.

  • Page 53: General Options

    General options LOCATION 37 - SIREN AND SYSTEM SUPERVISION (7 segments, feature selection data) Location 37 is used to enable various system feature and reporting options. Segment 1 On: if siren sounds for “Telephone Line Cut” when armed On: if siren sounds for “Telephone Line Cut” when disarmed On: if siren blast at arming (pulse) On: if siren blast at exit expiration (pulse) On: if siren blast at closing kiss-off (pulse)
  • Page 54 Segment 5 On: enable lost clock service light On: enables Zone Doubling (requires NX-200 Zone Doubling Kit). On: disables on-board 8 zones On: will allow two trips on same cross-zone to activate an alarm On: will not allow zones that are force armed to report bypass On: enables silent exit option On: activate “first disarm reporting”...
  • Page 55 LOCATION 40 - SYSTEM TIMERS (14 segments, numerical data) Location 40 contains the duration of various system timing functions. Example: If you want the duration of the dynamic battery test to be 30 minutes, you should program [3]- [0]-[*] in segment 1 of this location.
  • Page 56 LOCATION 43 - GO TO PROGRAM CODE PARTITION AND AUTHORIZATION (2 segments, feature selection data) The “Go To Program Code” can be used as a standard arm/disarm code. When using the code to arm or disarm, the user ID is 255. (It is not possible to change this code in the run mode). Segment 1 Reserved On: enables “Go To Program Code”...

  • Page 57: Programming The Outputs

    Programming the outputs LOCATION 45 - AUXILIARY OUTPUT 1-4 PARTITION SELECTION (4 segments, feature selection data) Location 45 is used to select the partition(s) in which the events must occur before the output (relay) will activate. Location 45 has 4 segments. Segment 1 corresponds to output 1, and segment 2 corresponds to output 2, segments 3 and 4 correspond to outputs 3 and 4.
  • Page 58 LOCATION 48 - AUXILIARY OUTPUT 2 (relay 2 and open collector 2), EVENT AND TIME (2 segments, numerical data) Segment 1 Use the chart below to select the event that will activate auxiliary output 2 (relay 2) Segment 2 Program the timing from 0-255 (minutes or seconds, depending on the data programmed in segment 2, location 46).
  • Page 59 AUXILIARY OUTPUT EVENT SELECTION DATA EVENT DATA EVENT Burglary alarm Open period Fire alarm Closed period 24 hour alarm Listen-in Trouble alarm Line seizure Tamper alarm Reserved Yelping siren Fail to communicate Steady siren Telephone line fault Any siren Program mode Any bypass Download in process AC fail...

  • Page 60: Setup For Auto-Test, Auto-Arm And Opening/Closing Times

    Setup for auto-test, auto-arm and opening/closing times LOCATION 51 - AUTOTEST CONTROL (4 segments, numerical data) Segment 1 Program a “1” if the interval is to be in hours; program a “0” for days. Add a “2” to suppress the daily test or a “3” to suppress the hourly test if any report has been sent Segment 2 Program the autotest interval from 1-255 hours/days...
  • Page 61 LOCATION 54 - DAYS OF THE WEEK “ARM ONLY AFTER CLOSE WINDOW” CODES FUNCTION IN PARTITIONS 1 THRU 8 (8 Segments, feature selection data) Location 54 selects the days of the week on which each partition is open. On these days, “arm only after close window”...

  • Page 62: Communicator Codes For Slow Speed Formats Only

    Communicator codes for slow speed formats only LOCATIONS 56-83 ARE ONLY USED WHEN REPORTING EVENTS TO A PAGER, OR WHEN USING A SLOW FORMAT SUCH AS 4+2. WHEN USING CONTACT ID OR SIA, THERE IS NO NEED TO PROGRAM THESE LOCATIONS. LOCATION 56 - RESTORE COMMUNICATOR CODE, SLOW SPEED FORMATS ONLY (8 segments, numerical data) Location 56 contains the event code for a zone “Restore”...
  • Page 63 LOCATION 58 - TAMPER COMMUNICATOR CODE, SLOW SPEED FORMATS (8 segments, numerical data) Location 58 contains the event code for a zone “Tamper” with a 4+2 and 3+1 format. For a 4+2 format, the digit programmed in this location will be sent as the tens digit of the tamper event code.
  • Page 64 Segment 1 Partition 1 “Sensor Low battery Code” Segment 2 Partition 2 “Sensor Low battery Code” Segment 3 Partition 3 “Sensor Low battery Code” Segment 4 Partition 4 “Sensor Low battery Code” Segment 5 Partition 5 “Sensor Low battery Code” Segment 6 Partition 6 “Sensor Low battery Code”...
  • Page 65 LOCATION 64 - KEYPAD AUXILIARY 2 COMMUNICATOR CODE, SLOW SPEED FORMATS ONLY (2 segments, numerical data) Location 64 contains the tens and ones digits that will be sent for a 4+2 and 3+1 format if the keypad “Auxiliary 2” (MEDICAL) is enabled in the partition feature selection. Segment 1 contains the tens digit;...
  • Page 66 LOCATION 69 - LOW BATTERY / LOW BATTERY RESTORE COMMUNICATOR CODES, SLOW SPEED FORMATS ONLY (4 segments, numerical data) Location 69 contains the tens and ones digits for a 4+2 and 3+1 format that will be sent if “Low Battery Reporting” is enabled. Segment 1 contains the tens digit of the “Low Battery Reporting”.
  • Page 67 LOCATION 74 - EXPANDER TROUBLE AND EXPANDER TROUBLE RESTORE COMMUNICATOR CODES, SLOW SPEED FORMATS ONLY (4 segments, numerical data) Location 74 contains the tens and ones digits for a 4+2 and 3+1 format that will be sent if “Expander Trouble Reporting” is enabled. Segment 1 contains the tens digit of the “Expander Trouble Reporting”.
  • Page 68 LOCATION 78 - CLOSING COMMUNICATOR CODE, SLOW SPEED FORMATS ONLY (8 segments, numerical data) Location 78 contains the tens digit for a 4+2 and 3+1 format if “Closing Reporting” is enabled. The ones digit is the ones digit of the user number that did the opening. If the user is greater than 9, the numbers will begin repeating (e.g.
  • Page 69 LOCATION 82 - END DOWNLOAD COMMUNICATOR CODE, SLOW SPEED FORMATS ONLY (4 segments, numerical data) Location 82 contains the tens and ones digits for a 4+2 and 3+1 format that will be sent if “End Downloading Reporting” is enabled. Segment 1 and 2 are reserved. Segment 3 contains the tens digit of the “End Download Reporting”.

  • Page 70: Programming Partition Parameters

    Programming partition parameters LOCATIONS 88-109 ARE FOR PROGRAMMING DIFFERENT ACCOUNT CODES AND/OR FEATURES FOR EACH PARTITION. IF A LOCATION IS LEFT UNPROGRAMMED, THE FEATURE FOR PARTITION 1 AND THE ACCOUNT CODE FOR THE PHONE NUMBER WILL BE USED LOCATION 88 - ACCOUNT CODE FOR PARTITION 1 (6 segments, numerical data) Location 88 contains the account code that is sent when partition 1 is reported.
  • Page 71 LOCATION 92 - ACCOUNT CODE FOR PARTITION 3 (6 segments, numerical data) The account code that is sent when reporting partition 3 is programmed in location 92. If location 92 is left unprogrammed (all “10”), then the account code corresponding to the phone number that is dialled will be used.
  • Page 72 LOCATION 97 - PARTITION 4 ENTRY EXIT TIMERS (6 segments, numerical data) Location 97 is used to enter the entry and exit times in seconds. There are 2 separate entry and exit times. Valid entries are 10-255 seconds. If all the segments are “0”, the entry and exit times for partition 1 will be used.
  • Page 73 LOCATION 101 - ACCOUNT CODE FOR PARTITION 6 (6 segments, numerical data) The account code that is sent when reporting partition 6 is programmed in location 101. If location 101 is left unprogrammed (all “10”) then the account code corresponding to the phone number that is dialled will be used.
  • Page 74 LOCATION 106 - PARTITION 7 ENTRY EXIT TIMERS (6 segments, numerical data) Location 106 is used to enter the entry and exit times in seconds. There are 2 separate entry and exit times. Valid entries are 10-255 seconds. If all the segments are “0”, the entry and exit times for partition 1 will be used.

  • Page 75: Programming Zone Configuration Groups

    Programming zone configuration groups LOCATIONS 110-169 ARE USED TO CHANGE THE ZONE CONFIGURATIONS AS LISTED IN THE TABLE ON PAGES 44-46. THESE LOCATIONS ARE CONSIDERED AS ADVANCED PROGRAMMING, AND THEY SHOULD ONLY BE CHANGED IF YOU HAVE A THOROUGH UNDERSTANDING OF THE OPERATION OF EACH BIT. LOCATION 110 - CONFIGURATION GROUP 1 ALARM EVENT CODE (1 segment, numerical data) Location 110 contains the event code that is sent for a Contact ID or SIA report.
  • Page 76 Segment 4 On: enables zone activity monitor On: enables end of line resistor defeat on non-fire/non-keyswitch zones On : enables zone to act as request to exit input / disables for alarm activation On : enables zone to act as access entry point (Door Shunt)(*) Reserved Reserved Reserved...
  • Page 77 LOCATION 117 - CONFIGURATION GROUP 4 CHARACTERISTIC SELECT (5 segments, feature selection data) Use the “Configuration Group Characteristic Selections” described in Location 111. LOCATION 118 - CONFIGURATION GROUP 5 ALARM EVENT CODE (1 segment, numerical data) Location 118 contains the event code that is sent for a Contact ID or SIA report. The desired event code should be chosen from the list on pages 121-122.
  • Page 78 LOCATION 124 - CONFIGURATION GROUP 8 ALARM EVENT CODE (1 segment, numerical data) Location 124 contains the event code that is sent for a Contact ID or SIA report. The desired event code should be chosen from the list on pages 121-122. The zone ID will be the zone that is in alarm.
  • Page 79 LOCATION 131 - CONFIGURATION GROUP 11 CHARACTERISTIC SELECT (5 segments, feature selection data) Use the “Configuration Group Characteristic Selections” described in Location 111. LOCATION 132 - CONFIGURATION GROUP 12 ALARM EVENT CODE (1 segment, numerical data) Location 132 contains the event code that is sent for a Contact ID or SIA report. The desired event code should be chosen from the list on pages 121-122.
  • Page 80 LOCATION 138 - CONFIGURATION GROUP 15 ALARM EVENT CODE (1 segment, numerical data) Location 138 contains the event code that is sent for a Contact ID or SIA report. The desired event code should be chosen from the list on pages 121-122. The zone ID will be the zone that is in alarm.
  • Page 81 LOCATION 145 - CONFIGURATION GROUP 18 CHARACTERISTIC SELECT (5 segments, feature selection data) Use the “Configuration Group Characteristic Selections” described in Location 111. LOCATION 146 - CONFIGURATION GROUP 19 ALARM EVENT CODE (1 segment, numerical data) Location 146 contains the event code that is sent for a Contact ID or SIA report. The desired event code should be chosen from the list on pages 121-122.
  • Page 82 LOCATION 152 - CONFIGURATION GROUP 22 ALARM EVENT CODE (1 segment, numerical data) Location 152 contains the event code that is sent for a Contact ID or SIA report. The desired event code should be chosen from the list on pages 121-122. The zone ID will be the zone that is in alarm.
  • Page 83 LOCATION 160 - CONFIGURATION GROUP 26 ALARM EVENT CODE (1 segment, numerical data) Location 160 contains the event code that is sent for a Contact ID or SIA report. The desired event code should be chosen from the list on pages 121-122. The zone ID will be the zone that is in alarm.
  • Page 84 LOCATION 166 - CONFIGURATION GROUP 29 ALARM EVENT CODE (1 segment, numerical data) Location 166 contains the event code that is sent for a Contact ID or SIA report. The desired event code should be chosen from the list on pages 121-122. The zone ID will be the zone that is in alarm.
  • Page 85 LOCATIONS 207-211 - RESERVED LOCATION 212 – PROGRAMMING THE LCD KEYPAD ADDRESS (1 segment, numerical data) When using the XSIA dialler format, the system requires at least 1 LCD keypad. The panel will get the zone descriptions from the first language from that LCD keypad which has the address defined in location 212.

  • Page 86: Nx-8-Eur Programming Worksheets

    NX-8-EUR P ROGRAMMING WORKSHEETS (Factory defaults for NX-8-EUR (BEL/POL) are in bold italic text) DESCRIPTION DEFAULT PROGRAMMING DATA PHONE 1 14-14-14-14-14-14-14-14-14-14-14- 14-14-14-14-14-14-14-14-14 PHONE 1, ACCOUNT CODE 10 – 10 – 10 – 10 – 10 – 10 PHONE 1, REPORTING FORMAT PHONE 1, DIAL ATTEMPTS BACKUP CONTROL PHONE 1, SELECTING EVENTS TO REPORT TO PHONE 1...
  • Page 87 PHONE 2, SELECTING WHICH PARTITIONS REPORT TO PHONE 2 Segment 1 (Circle Numbers To Program) Partition 1 Partition 2 Partition 3 Partition 4 Partition 5 Partition 6 Partition 7 Partition 8 PHONE 3 14-14-14-14-14-14-14-14-14-14-14- 14-14-14-14-14-14-14-14-14 10 – 10 – 10 – 10 – 10 – 10 PHONE 3, ACCOUNT CODE PHONE 3, REPORTING FORMAT PHONE 3, DIAL ATTEMPTS...
  • Page 88 DOWNLOAD CONTROL Segment 1 (Circle Numbers To Program) Enables two-call answering machine defeat Reserved Requires callback before downloading Shutdown control panel Lock out local programming Lock out communicator programming Lock out download section Enables callback at autotest interval CALLBACK PHONE NUMBER 14-14-14-14-14-14-14-14-14-14-14- 14-14-14-14-14-14-14-14-14 PARTITION 1, FEATURE SELECTION...
  • Page 89 ZONES 9-16, CONFIGURATION GROUPS 6-6-6-6-6-6-6-6 ZONES 9-16, PARTITION SELECTION (Segment 1=Zone 9 thru Segment 8=Zone 16) Segments Partition 1 Partition 2 Partition 3 Partition 4 Partition 5 Partition 6 Partition 7 Partition 8 6-6-6-6-6-6-6-6 ZONES 17-24, CONFIGURATION GROUPS ZONES 17-24, PARTITION SELECTION (Segment 1=Zone 17 thru Segment 8=Zone 24) Segments Partition 1 Partition 2...
  • Page 90 SIREN AND SYSTEM SUPERVISION Segment 1 (Circle Numbers To Program) Siren sounds for telephone line cut while armed Siren sounds for telephone line cut while disarmed Siren blast at arming (pulse) Siren blast at exit delay expiration (pulse) Siren blast at closing kissoff (pulse) Siren sounds during a cross zone verification time Siren sounds for a tamper Siren blast once for keyswitch arming, twice for disarming...
  • Page 91 Segment 7 (Circle Numbers To Program) dial via GSM when phone line trouble (only when NX-7002 is used) Exit Error limited to Entry/Exit delay 1 Reserved SWINGER COUNTDOWN COUNT KEYPAD SOUNDER CONTROL Segment 1 (Circle Numbers To Program) Keypad sounds for Telephone Line Cut when in the Armed state Keypad sounds for Telephone Line Cut when in the Disarmed state Keypad sounds upon AC Power Failure Keypad sounds upon Low Battery Detection...
  • Page 92 GO TO PROGRAM CODE 9-7-1-3-0-0 GO TO PROGRAM CODE PARTITION AND AUTHORIZATION Segment 1 (Circle Numbers To Program) Reserved Enables “Go To Program Code” as an arm only code Enables “Go To Program Code” as an arm only code after closing Enables “Go To Program Code”...
  • Page 93 AUTOTEST CONTROL Segment 1 Program a “1” if the interval is hours, or a “0” for days. Add a “2” to suppress the daily test or a “3” to suppress the hourly test Segment 2 Program the autotest interval from 1-255 days or hours Segment 3 Program the autotest report in 24 hour time format Segment 4...
  • Page 94 RESTORE COMMUNICATOR CODE, SLOW SPEED FORMATS ONLY Segment 1 Partition 1 restore code Segment 2 Partition 2 restore code Segment 3 Partition 3 restore code Segment 4 Partition 4 restore code Segment 5 Partition 5 restore code Segment 6 Partition 6 restore code Segment 7 Partition 7 restore code Segment 8...
  • Page 95 COMMUNICATOR CODES FOR SLOW SPEED FORMATS ONLY DURESS AUXILIARY 1 (fire) AUXILIARY 2 (medical alarm) KEYPAD PANIC KEYPAD MULTIPLE CODE ENTRY TAMPER BOX TAMPER / BOX TAMPER RESTORE 0-0-0-0 AC FAIL / AC RESTORE 0-0-0-0 0-0-0-0 LOW BATTERY / LOW BATTERY RESTORE 0-0-0-0 POWER SHORT / POWER SHORT RESTORE BELL TAMPER / BELL TAMPER RESTORE...
  • Page 96 PARTITION 1, ACCOUNT CODE 10-10-10-10-10-10 PARTITION 2, ACCOUNT CODE 10-10-10-10-10-10 PARTITION 2, FEATURE SELECTION Segment 1 Segment 2 Segment 3 Quick Arm LED extinguish enable Open/Close Re-Exit Require user code for bypassing zones Bypass Auto Bypass (interior) Bypass sounder alert Restore Silent Panic AC power/ low battery sounder alert...
  • Page 97 PARTITION 4, ACCOUNT CODE 10-10-10-10-10-10 PARTITION 4, FEATURE SELECTION Segment 1 Segment 2 Segment 3 Quick Arm LED extinguish enable Open/Close Re-Exit Require user code for bypassing zones Bypass Auto Bypass (interior) Bypass sounder alert Restore Silent Panic AC power/ low battery sounder alert Trouble Audible Panic Enables bypass toggle...
  • Page 98 10-10-10-10-10-10 PARTITION 6, ACCOUNT CODE PARTITION 6, FEATURE SELECTION Segment 1 Segment 2 Segment 3 Quick Arm LED extinguish enable Open/Close Re-Exit Require user code for bypassing zones Bypass Auto Bypass (interior) Bypass sounder alert Restore Silent Panic AC power/ low battery sounder alert Trouble Audible Panic Enables bypass toggle...
  • Page 99 PARTITION 8, ACCOUNT CODE 10-10-10-10-10-10 PARTITION 8, FEATURE SELECTION Segment 1 Segment 2 Segment 3 Quick Arm LED extinguish enable Open/Close Re-Exit Require user code for bypassing zones Bypass Auto Bypass (interior) Bypass sounder alert Restore Silent Panic AC power/ low battery sounder alert Trouble Audible Panic Enables bypass toggle...
  • Page 100 CONFIGURATION GROUP 1 ALARM CODE CONFIGURATION GROUP 1 CHARACTERISTIC SELECT Segment 1 (Circle Numbers To Program) Fire (enable for fire zone) Delay 1 zone (enable to follow Timer 1 Entry/Exit times) 24 Hour (enable for non-fire 24 hour zone) Delay 2 zone (enable to follow Timer 1 Entry / Exit times) Keyswitch zone Interior (Enable for auto bypass or stay arming) Follower (enable for burglary zones that are...
  • Page 101 CONFIGURATION GROUP 15 ALARM EVENT CODE CONFIGURATION GROUP 15 CHARACTERISTIC SELECT 457-1256-25678 CONFIGURATION GROUP 16 ALARM EVENT CODE CONFIGURATION GROUP 16 CHARACTERISTIC SELECT 0-1256-25678 CONFIGURATION GROUP 17 ALARM EVENT CODE CONFIGURATION GROUP 17 CHARACTERISTIC SELECT 38-0-2 CONFIGURATION GROUP 18 ALARM EVENT CODE CONFIGURATION GROUP 18 CHARACTERISTIC SELECT 5-1257-25678 CONFIGURATION GROUP 19 ALARM EVENT CODE...

  • Page 102: Board Installation

    BOARD INSTALLATION Inside the can, several 2-holed insertion points have been constructed. This allows for either vertical or horizontal placement of the modules. Notice that each insertion point has two sizes of holes -a larger hole and a smaller hole. Diagram 1: The black plastic PCB guides are grooved on one edge where the PC board will be seated.

  • Page 103: Nx-8-Eur Wiring Diagram

    NX-8-EUR W IRING DIAGRAM LED2 NX-8-EUR Installation manual Page 103 02/07/06...

  • Page 104: Terminal Description

    ERMINAL DESCRIPTION TERMINAL DESCRIPTION House Telephone Ring. Telephone Ring. Telephone Tip. House Telephone Tip. EARTH Earth Ground. AC input. Connect to a 16.5V 35VA CE approved transformer. BELL + & BELL - If used as a siren output (default), the speaker rating should be 15 watt at 8 or 16 ohm, or 30/40 watt at 4, 8, or 16 ohms.

  • Page 105: Technical Specifications

    ECHNICAL SPECIFICATIONS Technical specifications NX-8 Operating power - Nominal 16.5 Vac, 50/60Hz, 35VA - Minimum/maximum 14.05 Vac - 18.15 Vac Current consumption Min 100 mA, Max 105 mA Battery max. 12V/18 Ah use rechargeable lead-acid battery only Maximum recharge time 72 hours Auxiliary Power EN50131-6 Grade 2 Type A...

  • Page 106: Technical Specifications Nx-1308, Nx-1316, Nx-1324

    Technical specifications NX-1308, NX-1316, NX-1324 Operating power - Nominal 12 Vdc - Minimum/maximum 9 Vdc - 14 Vdc Operating temperature 0 - 50° C Dimensions 158 x 135x 30 mm Current consumption NX-1308 NX-1316 NX-1324 - Minimum (quiescent, no lighting) 23 mA 23 mA 23 mA...

  • Page 107: Appendix 1: Reporting Fixed Codes In Contact-Id And Sia

    1: R PPENDIX EPORTING FIXED CODES IN ONTACT The table below lists the event codes sent for the following reports (if enabled) when using CONTACT ID or SIA formats. REPORT CONTACT ID MANUAL TEST AUTOTEST OPEN (User Number) CLOSE (User Number) CANCEL (User Number) DOWNLOAD COMPLETE START PROGRAM...

  • Page 108: Appendix 2: Reporting Zone Codes In Sia Or Contact Id

    2: R PPENDIX EPORTING ZONE CODES IN ONTACT The NX-8 has the ability to report SIA level 1 transmissions to either or both phone numbers. Each report in SIA consists of an Event Code and a Zone or User ID. The Zone ID will be the zone number that is in alarm. The event code will come from the chart below, and it will be programmed in the configuration group event code.
  • Page 109 The NX-8 can report Ademco Contact ID transmissions. Each report in Contact ID consists of an Event Code and a Zone ID. The zone ID is the zone that generated the alarm. The event code will come from the chart below, and it will be programmed in the configuration group event code.

  • Page 110: Appendix 3: Expander Numbers For Reporting Expander Trouble

    3: E PPENDIX XPANDER NUMBERS FOR REPORTING EXPANDER TROUBLE The tables below list the device numbers that will be reported for each expander/keypad where a trouble condition is present. For trouble conditions relating to the control panel, the device number is “0”. Keypads KEYPAD PART 1...

  • Page 111: Output Module Nx-507E Or Nx-508E

    Output module NX-507E or NX-508E Output module DIP 1 DIP 2 DIP 3 Expander number reported Hardwired expander NX-216 Starting zone number DIP 1 DIP 2 DIP 3 Expander number reported Zone 9 Zone 17 Zone 25 Zone 33 Zone 41 NX-8-EUR Installation manual Page 111 02/07/06...

  • Page 112: Ce Declaration

    CE D ECLARATION NX-8-EUR Installation manual Page 112 02/07/06...
  • Page 113 NX-8-EUR Installation manual Page 113 02/07/06...
  • Page 114 NX-8-EUR Installation manual Page 114 02/07/06...
  • Page 115 NX-8-EUR Installation manual Page 115 02/07/06...
  • Page 116 NX-8-EUR Installation manual Page 116 02/07/06...
  • Page 117 NX-8-EUR Installation manual Page 117 02/07/06...
  • Page 118 NX-8-EUR Installation manual Page 118 02/07/06...
  • Page 119 NX-8-EUR Installation manual Page 119 02/07/06...
