Wiring Specifications
Refer to the following steps for details on power and
accessory wiring for the operator.
AC Power Wiring
WARNING
ALL AC ELECTRICAL CONNECTIONS TO THE POWER SOURCE AND
THE OPERATOR MUST BE MADE BY A LICENSED ELECTRICIAN AND
MUST OBSERVE ALL NATIONAL AND LOCAL ELECTRICAL CODES.
1. Find the listing on this page corresponding to the model, voltage
USE COPPER WIRE ONLY!
and horsepower rating of your operator.
2. The distance shown in the table is measured in feet from the
operator to the power source. DO NOT EXCEED THE MAXIMUM
DISTANCE. These calculations have been based on standard 115 V
and 230 V supplies with a 10% drop allowable. If your supply is
under the standard rating, the runs listed may be longer than what
your application will handle, and you should not run wire too near
the maximum distance for the gauge of wire you are using.
3. When large-gauge wire is used, a separate junction box (not
supplied) may be needed for the operator power connection.
4. Wire length calculations are based on the National Electrical Code,
Article 430 and have been carefully determined based on motor
inrush, brake solenoids, and operator requirements.
5. Connect power in accordance with local codes. The green ground
wire must be properly connected.
6. Wire insulation must be suitable to the application.
7. Electrical outlets are supplied in all 115 VAC models for convenience
with occasional use or low power consumption devices only. If you
choose to run dedicated equipment from these devices, it will
decrease the distance for maximum length and the charts will no
longer be accurate.
DC Control and Accessory Wiring
1. All control devices are now 24 VDC, which can be run up to
2000 feet with 14 AWG wire.
2. Control wiring must be run in a separate conduit from power wiring.
Running them together may cause interference and faulty signals in
some accessories.
3. A three-wire shielded conductor cable is required to connect two
operators together for dual operation. You must use Belden 8760
Twisted Pair Shielded Cable (or equivalent) only – P/N 2500-1982,
per foot). See Page 23 for details of this connection. Note: The
shield wire should be connected in both the operators.
SWR • SWC • SWD Swing Gate Operator Installation Guide
MODEL SWR POWER WIRING
MAXIMUM DISTANCE (FEET)
VOLTS & HP
SINGLE
316
502
115 VOLTS
800
1/2-HP
1272
2022
764
1218
230 VOLTS
1936
1/2-HP
3076
4896
MODEL SWC POWER WIRING
MAXIMUM DISTANCE (FEET)
VOLTS & HP
SINGLE
222
354
115 VOLTS
566
1/2-HP
900
1430
178
282
115 VOLTS
450
3/4-HP
716
1140
160
254
115 VOLTS
406
1-HP
646
1026
760
1200
208 VOLTS
1924
1/2-HP
3060
4864
604
958
208 VOLTS
1526
3/4-HP
2424
3856
544
864
208 VOLTS
1374
1-HP
2184
3476
894
1422
230 VOLTS
2264
1/2-HP
3600
5724
710
1128
230 VOLTS
1796
3/4-HP
2852
4538
640
1016
230 VOLTS
1616
1-HP
2570
4090
MODEL SWD POWER WIRING
MAXIMUM DISTANCE (FEET)
VOLTS & HP
SINGLE
970
1542
115 VOLTS
2452
1/2-HP
3898
6200
- 2 -
WIRE GAUGE
DUAL
158
12
251
10
400
8
636
6
1011
4
382
12
609
10
968
8
1538
6
2448
4
WIRE GAUGE
DUAL
111
12
177
10
283
8
450
6
715
4
89
12
141
10
255
8
358
6
570
4
80
12
127
10
203
8
323
6
513
4
380
12
600
10
962
8
1830
6
2432
4
302
12
478
10
763
8
1212
6
1928
4
272
12
432
10
686
8
1092
6
1738
4
447
12
711
10
1132
8
1800
6
2862
4
355
12
564
10
898
8
1426
6
2269
4
320
12
508
10
808
8
1285
6
2045
4
WIRE GAUGE
DUAL
485
12
771
10
1226
8
1949
6
3100
4
