Setting the DME wipe pattern position
(Position)
1
Open the Home > M/E-1 > Key1 > Transition > DME
Wipe menu (11101.53).
2
Set the [Position] button in the [Position] group to the
on state and set the following parameters.
No. Parameter
1 H
2 V
To return the pattern position to the center of the
screen
Press the [Center] button in the [Position] group.
Setting the DME wipe pattern size (Size)
1
Open the Home > M/E-1 > Key1 > Transition > DME
Wipe menu (11101.53).
2
Set the [Size] button to the on state and set the
following parameter.
No. Parameter
1 Size
Setting the DME wipe pattern cropping
(Crop)
1
Open the Home > M/E-1 > Key1 > Transition > DME
Wipe menu (11101.53).
2
Set the [Crop] button in the [Crop Mode] group to the
on state and set the following parameters.
No. Parameter
1-1 H
1-2 V
1-3 All
2-1 Top
2-2 Left
2-3 Right
2-4 Bottom
Adjustment
Horizontal position
• Negative values move left.
• Positive values move right.
Vertical position
• Negative values move
down.
• Positive values move up.
Adjustment
Size
Adjustment
Simultaneous adjustment of
crop of left and right edges
Simultaneous adjustment of
crop of top and bottom edges
Simultaneous adjustment of
crop of top, bottom, left, and
right edges
Crop of top edge
Crop of left edge
Crop of right edge
Crop of bottom edge
To crop to 4:3 aspect ratio
Press the [4:3 Crop] button in the [Crop Mode] group.
To set the movement during transition execution
In the [Crop Transition] group, select the crop operation
as the transition executes.
Cut: The cropping does not change during the transition,
and the cropping is removed after the transition has
completed.
Last 5%: The cropping is maintained for the first 95% of
the transition, and is removed during the last 5% of
the transition.
Linear: The cropping is removed from the start of the
transition through the course of the transition.
To set the timing of transition completion
When the [Last 5%] button in the [Crop Transition] group
is selected, you can set the transition completed timing to
70%, 95%, or 100% of the execution time.
In the [Release Transition] group, select the timing of
transition completion.
Last 30%: The transition completes at the 70% point of
the transition progress. The transition interval from
70% to 95% becomes a dead band. The cropping is
removed during the last 5% of the transition.
Last 5%: The transition completes at the 95% point of
the transition progress. The cropping is removed
during the remaining 5%.
Off: The transition completes at the 100% point. During
the last 5% of the transition, the transition and
cropping removal proceed together.
