Endress+Hauser Micropilot M FMR24 Series Service Information

Service Information
PC-Maulburg
Classification:
for information
X
important, handle re-actively
urgent, handle actively
safety relevant
ID: SIF8901301en0
8
Pages:
Date: Oct. 2006
Micropilot M FMR24x/250, new software version "Pulse Master eXact" 01.05.00
The new SW version Pulse Master eXact 01.05.00 has been introduced in CW39/2006 for the following instruments:
• FMR240 HART and PROFIBUS PA
• FMR244 HART and PROFIBUS PA
• FMR245 HART and PROFIBUS PA
• FMR250 HART and PROFIBUS PA
The following changes have been made to the software function:
• Introduction of new SW parameter for differentiation between liquids and solids applications
• Filter settings of new SW with application parameters
The new software is compatible with these operating tools:
• ToF Tool Fieldtool Package as of version 4.00
• HART Communicator DXR375, revision1, DD revision 1
• Fieldcare version 2.02.02 / DTM library release C-2006
A flash update from software version 01.04.00 to 01.05.00 is not possible due to different hardware. A hardware exchange is required in
any case.
Hints for repair and spare parts for FMR24x
Instruments with software version Pulse Master 01.04.00:
• in case of faulty electronics, the electronics module must be exchanged with the same type with SW 4.0
• if the HF module is faulty, it must be exchanged with the same type for SW4.0
• if an upgrade to 5.0 is desired (for advanced dynamics), HF module and electronics must always be exchanged together
Instruments with software version Pulse Master eXact 01.05.00:
• in case of faulty electronics, the electronics module can only be exchanged with the same type with SW5.0
• if the HF module is faulty, it can only be exchanged with the same type for SW5.0
• spare electronics FMR24x/250 HART software version 01.05.00
• spare electronics FMR24x/250 PROFIBUS PA SW01.05.00
• spare electronics FMR24x/250 FOUNDATION Fieldbus SW01.05.00
• spare HF module advanced dynamics, 26 GHz, for SW 01.05.00
Conversion of an instrument FMR24x for special applications (advanced dynamics)
The conversion is possible for non-Ex instruments or Ex ia / Ex d instruments, however not for solids instruments with certification
WHG / SIL or FM.
Together with the new software version, we offer 2 new HF modules with enhanced dynamics for liquids applications:
• spare HF module max. measuring range = 40 m
• spare HF module max. measuring range = 70 m
A HF module can only be changed in combination with a change to electronics SW5.0.
Endress+Hauser Maulburg
Contact person:
Hans-Joachim Freytag (fr)
Service MSR
Telephone: (+49) 07622 28-2541
hans-joachim.freytag@pcm.endress.com
order number
order number
order number
order number
order number 71026572
order number 5202 4953
7102 6754
7102 6819
7102 6820 (from 1. quarter 07)
7102 6572
please turn over
page 1 of 8
