Operating Instructions
Micropilot M FMR245
Level-Radar
BA00251F/00/EN/13.11
71139070
Valid as of software version:
01.05.00

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Micropilot M FMR245

Summary of Contents for Endress+Hauser Micropilot M FMR245

  • Page 1 Operating Instructions Micropilot M FMR245 Level-Radar BA00251F/00/EN/13.11 71139070 Valid as of software version: 01.05.00...
  • Page 2 Brief operating instructions Micropilot M FMR245 4 to 20 mA HART Brief operating instructions Micropilot M FMR240/244/245/250 - Brief operating instructions KA235F/00/a2/08.06 52025245 Contrast: measured dist./ value meas value Group selection process empty check start media tank tank medium full pipe dist./...

  • Page 3: Table Of Contents

    Certificates and approvals ....9 9.10 Contact addresses of Endress+Hauser ... 75 Registered trademarks .

  • Page 4: Safety Instructions

    Safety instructions Micropilot M FMR245 4 to 20 mA HART Safety instructions Designated use The Micropilot M is a compact radar level transmitter for the continuous, contactless measurement of liquids, pastes, sludge and solids. The device can also be freely mounted outside closed metal vessels because of its operating frequency of about 26 GHz and a maximum radiated pulsed energy of 1 mW (average power output 1 μW).

  • Page 5: Notes On Safety Conventions And Symbols

    Micropilot M FMR245 4 to 20 mA HART Safety instructions Notes on safety conventions and symbols In order to highlight safety-relevant or alternative operating procedures in the manual, the following conventions have been used, each indicated by a corresponding symbol in the margin.

  • Page 6: Identification

    Identification Micropilot M FMR245 4 to 20 mA HART Identification Device designation 2.1.1 Nameplate The following technical data are given on the instrument nameplate: ENDRESS+HAUSER Order Code: Ser.-No.: if modification see sep. label Dat./Insp.: L00-FMR2xxxx-18-00-00-en-001 Information on the nameplate of the Micropilot M...
  • Page 7 Micropilot M FMR245 4 to 20 mA HART Identification 2.1.2 Ordering structure This overview does not mark options which are mutually exclusive. Approval A Non-hazardous area Non-hazardous area, WHG ATEX II 1/2G EEx ia IIC T6, XA, Note safety instruction (XA) (electrostatic charging)!
  • Page 8 Identification Micropilot M FMR245 4 to 20 mA HART Housing A F12 Alu, coated IP65 NEMA4X F23 316L IP65 NEMA4X C T12 Alu, coated IP65 NEMA4X, separate conn. compartment D T12 Alu, coated IP65 NEMA4X+OVP, separate conn. compartment, OVP=overvoltage protection Special version, TSP-no.

  • Page 9: Scope Of Delivery

    The device complies with the applicable standards and regulations as listed in the EC declaration of conformity and thus complies with the statutory requirements of the EC directives. Endress+Hauser confirms the successful testing of the device by affixing to it the CE mark.

  • Page 10: Mounting

    Mounting Micropilot M FMR245 4 to 20 mA HART Mounting Quick installation guide Observe orientation when installing! Installation in tank (free space): Turn housing Mark on process connector facing the nearest tank wall! The housing can be turned 350° in order to simplify access to the...

  • Page 11: Incoming Acceptance, Transport, Storage

    Micropilot M FMR245 4 to 20 mA HART Mounting Incoming acceptance, transport, storage 3.2.1 Incoming acceptance Check the packing and contents for any signs of damage. Check the shipment, make sure nothing is missing and that the scope of supply matches your order.

  • Page 12: Installation Conditions

    Mounting Micropilot M FMR245 4 to 20 mA HART Installation conditions 3.3.1 Dimensions Housing dimensions 65 (2.56) 78 (3.07) max. 110 (4.33) ENDRESS+HAUSER F12 housing (Aluminium) 85 (3.35) mm (in) L00-F12xxxx-06-00-00-en-001 65 (2.56) max. 100 (4.33) 94 (3.7) 78 (3.07)
  • Page 13 Micropilot M FMR245 4 to 20 mA HART Mounting Process connection F12 / T12 / F23 housing R = reference point of measurement Group 20 / Code B, F Group 20 / Code C, G Var. DN 50 Var. DN 80 flange DN 50 flange DN 80 ...
  • Page 14 Mounting Micropilot M FMR245 4 to 20 mA HART 3.3.2 Engineering hints Orientation • Recommended distance (1) wall – outer edge of nozzle: ~1/6 of tank diameter. Nevertheless the device should not be installed closer than 15 cm (5.91 in) to the tankwall.
  • Page 15 Micropilot M FMR245 4 to 20 mA HART Mounting Measurement in a plastic tank If the outer wall of the tank is made of a non-conductive material (e.g. GRP), microwaves can also be reflected off interfering installations outside the signal beam (e.g. metallic pipes (1), ladders (2), grates (3), …).
  • Page 16 Mounting Micropilot M FMR245 4 to 20 mA HART Beam angle The beam angle is defined as the angle α where the energy density of the radar waves reaches half the value of the maximum energy density (3dB-width). Microwaves are also emitted outside the signal beam and can be reflected off interfering installations.
  • Page 17 Micropilot M FMR245 4 to 20 mA HART Mounting Measuring conditions Note! • In case of boiling surfaces, bubbling or tendency for foaming, use FMR230 or FMR231. Depending on its consistence, foam can either absorb microwaves or reflect them off the foam surface.
  • Page 18 Mounting Micropilot M FMR245 4 to 20 mA HART Measuring range The usable measuring range depends on the size of the antenna, the reflectivity of the medium, the mounting location and eventual interference reflections. The maximum configurable range is: • 40 m (131 ft), basic version •...
  • Page 19 Micropilot M FMR245 4 to 20 mA HART Mounting Measuring range depending on vessel type, conditions and product Standard: With additional option F (G): max. measuring range = 40 m (131 ft) max. measuring range = 70 m (230 ft) min.

  • Page 20: Installation Instructions

    Mounting Micropilot M FMR245 4 to 20 mA HART Installation instructions 3.4.1 Mounting kit In addition to the tool needed for flange mounting, you will require the following tool: • 4 mm (0.16 in) Allen wrench for turning the housing.
  • Page 21 Micropilot M FMR245 4 to 20 mA HART Mounting 3.4.3 Installation in stilling well Optimum mounting position marker at instrument flange or threaded boss 1½” BSPT (R 1½”), G 1½" (FMR 244) DN50 DN80…150 1½ NPT ANSI 2” ANSI 3…6”...
  • Page 22 Mounting Micropilot M FMR245 4 to 20 mA HART Examples for the construction of stilling wells Micropilot M FMR245 marker e.g. welding neck flange DIN 2633 stilling well with slots 100 % < 1/10 ø-pipe hole <1/10 pipe diameter, single sided or drilled through...
  • Page 23 Micropilot M FMR245 4 to 20 mA HART Mounting 3.4.4 Installation in bypass Optimum mounting position L00-FMR230xx-17-00-00-en-007 Standard installation For installations in a bypass, follow the engineering hints (→ ä 14) and note the following points: • Marker is aligned perpendicular (90°) to tank connectors.
  • Page 24 Mounting Micropilot M FMR245 4 to 20 mA HART Example for the construction of a bypass. Micropilot M FMR230, FMR240, FMR244 - 80 (3"), FMR245 marker e.g. welding neck flange DIN 2633 full bore ball valve 100% Diameter of the connection pipes...

  • Page 25: Post-Installation Check

    Micropilot M FMR245 4 to 20 mA HART Mounting 3.4.5 Turn housing After mounting, the housing can be turned 350° in order to simplify access to the display and the terminal compartment. Proceed as follows to turn the housing to the required position: •...

  • Page 26: Wiring

    Wiring Micropilot M FMR245 4 to 20 mA HART Wiring Quick wiring guide Wiring in F12/F23 housing " Before connection please note the following: ● The power supply must be identical to the data on the ENDRESS+HAUSER Caution! nameplate (1).
  • Page 27 Micropilot M FMR245 4 to 20 mA HART Wiring Wiring in T12 housing Before connection please note the following: " ● The power supply must be identical to the data on the nameplate (1). ● Switch off power supply before connecting up the device.

  • Page 28: Connecting The Measuring Unit

    Wiring Micropilot M FMR245 4 to 20 mA HART Connecting the measuring unit Terminal compartment Three housings are available: • Aluminium housing F12 with additionally sealed terminal compartment for: – standard, – Ex ia. • Aluminium housing T12 with separate terminal compartment for: –...
  • Page 29 Micropilot M FMR245 4 to 20 mA HART Wiring Supply voltage The following values are the voltages across the terminals directly at the instrument: Terminal voltage Current Communication consumption minimal maximal HART 4 mA 16 V 36 V standard 20 mA 7.5 V...
  • Page 30 Wiring Micropilot M FMR245 4 to 20 mA HART 4.2.1 HART connection with Endress+Hauser RMA422 / RN221N 4...20 mA RMA422 ENDRESS + HAUSER RMA 422 RN221N 1 2 3 4 dsdmdm df das. asdas fa asas la. FMP40: LIC0001 ONLINE...

  • Page 31: Recommended Connection

    Micropilot M FMR245 4 to 20 mA HART Wiring Recommended connection 4.3.1 Equipotential bonding Connect the equipotential bonding to the external ground terminal of the transmitter. 4.3.2 Wiring screened cable " Caution! In Ex applications, the screen must only be grounded on the sensor side. Further safety instructions are given in the separate documentation for applications in explosion hazardous areas.

  • Page 32: Operation

    Operation Micropilot M FMR245 4 to 20 mA HART Operation Quick operation guide ENDRESS + HAUSER – >3 s media type basic setup Return to liquids tank shape medium property safety settings Group Selection solids dome ceiling unknown linearisation horizontal cyl DC: <...
  • Page 33 Micropilot M FMR245 4 to 20 mA HART Operation 5.1.1 General structure of the operating menu The operating menu is made up of two levels: • Function groups (00, 01, 03, …, 0C, 0D): The individual operating options of the instrument are split up roughly into different function groups.

  • Page 34: Display And Operating Elements

    Operation Micropilot M FMR245 4 to 20 mA HART Display and operating elements (liquid crystal display) Orde Orde Ser.- Ser.- r Cod r Cod No.: No.: sber surin sber surin eich eich g rang g rang U 16... U 16...
  • Page 35 Micropilot M FMR245 4 to 20 mA HART Operation 5.2.1 Display Liquid crystal display (LCD): Four lines with 20 characters each. Display contrast adjustable through key combination. Headline Position indicator ENDRESS + HAUSER Symbol Main value Bargraph Unit – Selection list Function groups ->...
  • Page 36 Operation Micropilot M FMR245 4 to 20 mA HART 5.2.3 Key assignment The operating elements are located inside the housing and are accessible for operation by opening the lid of the housing. Function of the keys Key(s) Meaning Navigate upwards in the selection list.

  • Page 37: Local Operation

    Micropilot M FMR245 4 to 20 mA HART Operation Local operation 5.3.1 Locking of the configuration mode The Micropilot can be protected in two ways against unauthorised changing of instrument data, numerical values or factory settings: Function "unlock parameter" (0A4): A value <>...
  • Page 38 Operation Micropilot M FMR245 4 to 20 mA HART 5.3.2 Unlocking of configuration mode If an attempt is made to change parameters on display when the instrument is locked, the user is automatically requested to unlock the instrument: Function "unlock parameter" (0A4):...
  • Page 39 Micropilot M FMR245 4 to 20 mA HART Operation 5.3.3 Factory settings (Reset) " Caution! A reset sets the instrument back to the factory settings. This can lead to an impairment of the measurement. Generally, you should perform a basic setup again following a reset.

  • Page 40: Display And Acknowledging Error Messages

    Operation Micropilot M FMR245 4 to 20 mA HART Display and acknowledging error messages Types of errors Errors that occur during commissioning or measuring are displayed immediately on the local display. If two or more system or process errors occur, the error with the highest priority is the one shown on the display.

  • Page 41: Hart Communication

    Micropilot M FMR245 4 to 20 mA HART Operation HART communication Apart from local operation, you can also parameterise the measuring instrument and view measured values by means of a HART protocol. There are two options available for operation: • Operation via the universal Field Communicator 375, 475.
  • Page 42 FieldCare is an Endress+Hauser asset management tool based on FDT technology. With FieldCare, you can configure all Endress+Hauser devices as well as devices from other manufacturers that support the FDT standard. Hardware and software requirements you can find on the internet: www.endress.com ➞...
  • Page 43 Micropilot M FMR245 4 to 20 mA HART Operation Signal analysis via envelope curve MicropilotM-en-306 Tank linearisation MicropilotM-en-307 Endress+Hauser...

  • Page 44: Commissioning

    Commissioning Micropilot M FMR245 4 to 20 mA HART Commissioning Function check Make sure that all final checks have been completed before you start up your measuring point: • Checklist "Post-installation check", → ä 25. • Checklist "Post-connection check", → ä 31.

  • Page 45: Basic Setup

    Micropilot M FMR245 4 to 20 mA HART Commissioning Basic Setup level measurement in liquids media type media type flange: liquid solid reference point of measurement tank shape vessel / silo dome ceiling metal silo measuring cond measuring cond Unknown Unknown measuring cond.
  • Page 46 Commissioning Micropilot M FMR245 4 to 20 mA HART " Caution! The basic setup is sufficient for successful commissioning in most applications. Complex measuring operations necessitate additional functions that the user can use to customise the Micropilot as necessary to suit his specific requirements. The functions available to do this are described in detail in the BA00291F/00/EN.

  • Page 47: Basic Setup With The Device Display

    Micropilot M FMR245 4 to 20 mA HART Commissioning Basic Setup with the device display Function "measured value" (000) ⇒ ENDRESS + HAUSER – This function displays the current measured value in the selected unit (see "customer unit" (042) function). The number of digits after decimal point can be selected in the "no.of decimals"...
  • Page 48 Commissioning Micropilot M FMR245 4 to 20 mA HART Function "tank shape" (002), liquids only ⇒ ENDRESS + HAUSER – This function is used to select the tank shape. Selection: • dome ceiling • horizontal cyl • bypass • stilling well •...
  • Page 49 Micropilot M FMR245 4 to 20 mA HART Commissioning Function "process cond." (004) , liquids only ⇒ ENDRESS + HAUSER – This function is used to select the process conditions. Selection: • standard • calm surface • turb. surface • agitator •...
  • Page 50 Commissioning Micropilot M FMR245 4 to 20 mA HART Function "vessel / silo" (00A), solids only ⇒ ENDRESS + HAUSER – This function is used to select the vessel / silo. Selection: • unknown • metal silo • concrete silo •...
  • Page 51 Micropilot M FMR245 4 to 20 mA HART Commissioning Function "process cond." (00C), solids only ⇒ ENDRESS + HAUSER – This function is used to select the process conditions. Selection: • standard • fast change • slow change • test:no filter Function "empty calibr."...
  • Page 52 Commissioning Micropilot M FMR245 4 to 20 mA HART Function "full calibr." (006) ⇒ ENDRESS + HAUSER – This function is used to enter the distance from the minimum level to the maximum level (=span). L00-FMR2xxxx-14-00-06-en-009 Note! • If bypass or stilling well was selected in the "tank shape" (002) function, the pipe diameter is requested in the following step.
  • Page 53 Micropilot M FMR245 4 to 20 mA HART Commissioning Function "dist./meas.value" (008) ⇒ ENDRESS + HAUSER – The distance measured from the reference point to the product surface and the level calculated with the aid of the empty adjustment are displayed. Check whether the values correspond to the actual level or the actual distance.
  • Page 54 Commissioning Micropilot M FMR245 4 to 20 mA HART dist. too big • This error cannot be remedied by interference echo mapping • Check the application parameters (002), (003), (004) and "empty calibr." (005) dist. unknown If the actual distance is not known, no mapping can be carried out.
  • Page 55 Micropilot M FMR245 4 to 20 mA HART Commissioning Function "dist./meas.value" (008) ⇒ ENDRESS + HAUSER – The distance measured from the reference point to the product surface and the level calculated with the aid of the empty adjustment are displayed. Check whether the values correspond to the actual level or the actual distance.
  • Page 56 Commissioning Micropilot M FMR245 4 to 20 mA HART 6.4.2 Envelope curve with device display After the basic setup, an evaluation of the measurement with the aid of the envelope curve ("envelope curve" (0E) function group) is recommended. Function "plot settings" (0E1) ⇒...
  • Page 57 Micropilot M FMR245 4 to 20 mA HART Commissioning Function "envelope curve display" (0E3) The envelope curve is displayed in this function. You can use it to obtain the following information: quality of evaluated echo full calibr. evaluated echo is marked empty calibr.
  • Page 58 Commissioning Micropilot M FMR245 4 to 20 mA HART Move mode Then press to switch to Move mode. Either is displayed. • shifts the curve to the right. • shifts the curve to the left. L00-FMxxxxxx-07-00-00-yy-008 Vertical Zoom mode Press once more to switch to Vertical Zoom mode.

  • Page 59: Basic Setup With The Endress+Hauser Operating Program

    Micropilot M FMR245 4 to 20 mA HART Commissioning Basic Setup with the Endress+Hauser operating program To carry out the basic setup with the operating program, proceed as follows: • Start the operating program and establish a connection. • Select the "basic setup" function group in the navigation window.
  • Page 60 Commissioning Micropilot M FMR245 4 to 20 mA HART Basic Setup step 2/4: • Enter the application parameters: – Tank shape – Medium property – Process cond. MicropilotM-en-302 Basic Setup step 3/4: If "dome ceiling", "horizontal cyl", "..." is selected in the "tank shape" function, the following display appears on the screen: •...
  • Page 61 Micropilot M FMR245 4 to 20 mA HART Commissioning Basic Setup step 4/4: • This step starts the tank mapping • The measured distance and the current measured value are always displayed in the header MicropilotM-en-304 6.5.1 Signal analysis via envelope curve After the basic setup, an evaluation of the measurement using the envelope curve is recommended.
  • Page 62 Commissioning Micropilot M FMR245 4 to 20 mA HART 6.5.2 User-specific applications (operation) For details of setting the parameters of user-specific applications, see separate documentation BA00291F/00/EN "Description of Instrument Functions" on the enclosed CD-ROM. Endress+Hauser...

  • Page 63: Maintenance

    Repairs The Endress+Hauser repair concept assumes that the measuring devices have a modular design and that customers are able to undertake repairs themselves (→ ä 74, "Spare Parts"). Please contact Endress+Hauser Service for further information on service and spare parts.

  • Page 64: Accessories

    For details refer to TI00404F/00/EN. Commubox FXA291 The Commubox FXA291 connects Endress+Hauser field instruments with CDI interface (= Endress+Hauser Common Data Interface) to the USB interface of a personal computer or a notebook. For details refer to TI00405C/07/EN. Note! For the instrument you need the "ToF Adapter FXA291" as an additional accessory.

  • Page 65: Remote Display Fhx40

    Micropilot M FMR245 4 to 20 mA HART Accessories Remote display FHX40 Wall-mounting Pipe-mounting (without mounting bracket) (mounting bracket and plate supplied optionally, s. product structure) Separate housing FHX40 (IP 65) Micropilot M (4.8) Levelflex M Prosonic M O rd...

  • Page 66: Trouble-Shooting

    Trouble-shooting Micropilot M FMR245 4 to 20 mA HART Trouble-shooting Trouble-shooting instructions Micropilot M FMR 2xx -Trouble Shooting Check voltage and Not ok Instrument does compare it with the Connect the Instrument works? Ready not respond specifications on the correct voltage nameplate.

  • Page 67: System Error Messages

    Micropilot M FMR245 4 to 20 mA HART Trouble-shooting System error messages Code Description Possible cause Remedy A102 checksum error device has been powered off before data reset; general reset & new could be stored; avoid emc problem; calibr.required emc problem;...
  • Page 68 Trouble-shooting Micropilot M FMR245 4 to 20 mA HART Code Description Possible cause Remedy E641 no usable echo echo lost due to application conditions or check installation; channel 1 built up on antenna optimize orientation of antenna; check calibr. clean antenna (cf. OM)

  • Page 69: Application Errors In Liquids

    Micropilot M FMR245 4 to 20 mA HART Trouble-shooting Application errors in liquids Error Output Possible cause Remedy A warning or alarm Depending on the configuration See table of error 1. See table of error messages messages (→ ä 67) (→...
  • Page 70 Trouble-shooting Micropilot M FMR245 4 to 20 mA HART Error Output Possible cause Remedy → If the surface is not Signal is weakened by 1. Carry out tank mapping basic calm (e.g. filling, the rough surface – the setup emptying, agitator...

  • Page 71: Application Errors In Solids

    Micropilot M FMR245 4 to 20 mA HART Trouble-shooting Application errors in solids Error Output Possible cause Remedy A warning or alarm Depending on the configuration See table of error 1. See table of error messages messages (→ ä 67) (→...

  • Page 72: Orientation Of The Micropilot

    Trouble-shooting Micropilot M FMR245 4 to 20 mA HART Orientation of the Micropilot For orientation a marker is found on the flange or threaded boss of the Micropilot. During installation this must be oriented as follows (→ ä 10): • In tanks: to the vessel wall •...
  • Page 73 Micropilot M FMR245 4 to 20 mA HART Trouble-shooting echo: highest value echo tank bottom L00-FMRxxxxx-19-00-00-en-004 Vessel empty, no interference echo false echo: smallest value false echo echo tank bottom L00-FMRxxxxx-19-00-00-en-005 Vessel empty, interference echo obtained Fix the flange or threaded boss in this position. If necessary, replace the seal.

  • Page 74: Spare Parts

    Trouble-shooting Micropilot M FMR245 4 to 20 mA HART Spare Parts An overview of the spare parts for your device is available in the internet at www.endress.com. To obtain information on the spare parts, proceed as follows: Go to "www.endress.com" and select your country.

  • Page 75: Return

    Micropilot M FMR245 4 to 20 mA HART Trouble-shooting Return The following procedures must be carried out before a transmitter is sent to Endress+Hauser e.g. for repair or calibration: • Remove all residue which may be present. Pay special attention to the gasket grooves and crevices where fluid may be present.

  • Page 76: Technical Data

    Technical data Micropilot M FMR245 4 to 20 mA HART Technical data 10.1 Additional technical data 10.1.1 Input Measured variable The measured variable is the distance between a reference point and a reflective surface (i.e. medium surface). The level is calculated based on the tank height entered.
  • Page 77 Micropilot M FMR245 4 to 20 mA HART Technical data 10.1.4 Performance characteristics Reference operating • temperature = +20 °C ±5 °C (+68 °F ±41 °F) conditions • pressure = 1013 mbar abs. ±20 mbar (15 psi ±0.29psi) • relative humidity (air) = 65 % ±20 % •...
  • Page 78 Technical data Micropilot M FMR245 4 to 20 mA HART Gas phase Temperature Pressure °C °F 1 bar (14.5 psi) 10 bar (145 psi) 50 bar (725 psi) 100 bar (1450 psi) 160 bar (2320 psi) Water 0.20 % (saturated 2.1 %...
  • Page 79 Micropilot M FMR245 4 to 20 mA HART Technical data 10.1.6 Operanditions: Process Process temperature range / Note! Process pressure limits The specific range may be reduced by the selected process condition. The pressure rating (PN) specified on the flanges refers to a reference temperature of 20 °C (68 °F), for ASME flanges to 100 °F.
  • Page 80 Technical data Micropilot M FMR245 4 to 20 mA HART 10.1.7 Mechanical construction Weight • F12/T12 housing: approx 2.5 kg (5.51 lbs) + weight of flange • F23 housing: approx 5.9 kg (13.01 lbs) + weight of flange Material Materials of T12 and F12 housing (seawater-resistant, powder-coated)
  • Page 81 Micropilot M FMR245 4 to 20 mA HART Technical data Materials of F23 housing (corrosion-resistant) F23 housing 316L (1.4404/1.4435) L00-x12xxxx-16-00-00-en-001 Pos. Part Material Housing body: 1.4404; Sensor neck: 1.4435; F23 housing earth connection block: 1.4435 Cover 1.4404 Sealing Fa. SHS: EPDM 70pW FKN...
  • Page 82 PTFE (conform to FDA 21 CFR 177.1550 and USP <88> Class VI) 10.1.8 Certificates and approvals CE approval The measuring system meets the legal requirements of the EC-guidelines. Endress+Hauser confirms the instrument passing the required tests by attaching the CE-mark. RF approvals R&TTE, FCC Overspill protection German WHG, see ZE00244F/00/DE.
  • Page 83 Micropilot M FMR245 4 to 20 mA HART Technical data Ex approval Correlation of safety instructions (XA, XC) and certificates (ZD, ZE) to the instrument: Feature Non-hazardous area ATEX II 1/2G, 1/2D, Alu blind cover, XA IECEx Zone 0/1, Ex ia IIC T6, XA...
  • Page 84 Technical data Micropilot M FMR245 4 to 20 mA HART 10.1.9 Supplementary Documentation Supplementary This supplementary documentation can be found on our product pages on www.endress.com. Documentation • Technical Information (TI00345F/00/EN) • Operating Instructions "Description of instrument functions" (BA00291F/00/EN) • Safety Manual "Functional Safety Manual" (SD00150F/00/EN).
  • Page 85 Micropilot M FMR245 4 to 20 mA HART Technical data Endress+Hauser...

  • Page 86: Appendix

    Appendix Micropilot M FMR245 4 to 20 mA HART Appendix 11.1 Operating menu HART basic setup media type tank shape medium cond. process cond. empty calibr. full calibr. liquid dome ceiling unknown standard enter value enter value horizontal cyl. DK: < 1.9...
  • Page 87 Micropilot M FMR245 4 to 20 mA HART Appendix dist./meas.value check distance range of mapping start mapping dist./meas.value distance = ok input of D and L dist. too small mapping range are displayed manual D and L are displayed pipe diameter dist.

  • Page 88: Patents

    Appendix Micropilot M FMR245 4 to 20 mA HART 11.2 Patents This product may be protected by at least one of the following patents. Further patents are pending. • US 5,387,918 i EP 0 535 196 • US 5,689,265 i EP 0 626 063 •...

  • Page 89: Index

    Micropilot M FMR245 4 to 20 mA HART Index Index installation in tank ......10, 20 interference echo.
  • Page 90 Micropilot M FMR245 4 to 20 mA HART Index Spare Parts ........74 stilling well .
  • Page 91 Erklärung zur Kontamination und Reinigung Please reference the Return Authorization Number (RA#), obtained from Endress+Hauser, on all paperwork and mark the RA# clearly on the outside of the box. If this procedure is not followed, it may result in the refusal of the package at our facility.
  • Page 92 www.endress.com/worldwide BA00251F/00/EN/13.11 71139070 CCS/FM+SGML 9.0 ProMoDo 71139070...
