Brief Operating Instructions
Micropilot M FMR244
Level-Radar
These are Brief Operating Instructions.
For more detailed information, please refer to the Operating Instructions and the
additional documentation on the CD-ROM provided.
These Brief Operating Instructions are not intended to replace the Operating
Instructions provided in the scope of supply.
The complete device documentation consists of:
• These Brief Operating Instructions
• A CD-ROM with:
– The Operating Instructions
– Approvals and safety certificates
– Additional device-specific information
KA1010F/00/EN/12.09
71030600

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Micropilot M FMR244

Summary of Contents for Endress+Hauser Micropilot M FMR244

  • Page 1 Brief Operating Instructions Micropilot M FMR244 Level-Radar These are Brief Operating Instructions. For more detailed information, please refer to the Operating Instructions and the additional documentation on the CD-ROM provided. These Brief Operating Instructions are not intended to replace the Operating Instructions provided in the scope of supply.

  • Page 2: Table Of Contents

    Table of Contents Micropilot M FMR244 PROFIBUS PA Table of Contents 1 Safety instructions ..........3 1.1 Designated use .

  • Page 3: Safety Instructions

    Micropilot M FMR244 PROFIBUS PA Safety instructions Safety instructions Designated use The Micropilot M is a compact radar level transmitter for the continuous, contactless measurement of liquids, pastes, sludge and solids. The device can also be freely mounted outside closed metal vessels because of its operating frequency of about 26 GHz and a maximum radiated pulsed energy of 1 mW (average power output 1μW).

  • Page 4: Return

    Safety instructions Micropilot M FMR244 PROFIBUS PA 1.3.1 FCC approval This instrument complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This instrument may not cause harmful interference, and this instrument must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Mounting

    Micropilot M FMR244 PROFIBUS PA Mounting Mounting Quick installation guide Observe orientation when installing! Installation in tank (free space): Installation in stilling well: Mark on process connector facing Mark on process connector the nearest tank wall! pointed towards the slots...

  • Page 6: Installation

    Mounting Micropilot M FMR244 PROFIBUS PA Installation 2.3.1 Mounting kit Beside a key AF 60 for installation you need the following tool: • 4 mm (0.16 in) Allen wrench for turning the housing. 2.3.2 General installation instructions • Marker is aligned towards tank wall.
  • Page 7 Micropilot M FMR244 PROFIBUS PA Mounting Standard installation - 80 mm (3.15 in) antenna • The marker is located directly below the housing neck on the stainless steel feedthrough. • As an option for flange mounting, a variable flange seal (see "Accessories") can be used to align the device (solid applications).
  • Page 8 Mounting Micropilot M FMR244 PROFIBUS PA 2.3.5 Orientation • Recommended distance (1) wall - outer edge of nozzle: ~1/6 of tank diameter. Nevertheless the device should not be installed closer than 15 cm (5.91 in) to the tankwall. • Not in the centre (3), interference can cause signal loss.
  • Page 9 Micropilot M FMR244 PROFIBUS PA Mounting 2.3.6 Engineering hints Tank installations • Avoid any installations (1), like limit switches, temperature sensors, etc., inside the signal beam (→ ä 10). • Symmetrical installations (2), i.e. vacuum rings, heating coils, baffles, etc., can also interfere with the measurement.
  • Page 10 Mounting Micropilot M FMR244 PROFIBUS PA 2.3.7 Beam angle α The beam angle is defined as the angle where the energy density of the radar waves reaches half the value of the maximum energy density (3dB-width). Microwaves are also emitted outside the signal beam and can be reflected off interfering installations.
  • Page 11 Micropilot M FMR244 PROFIBUS PA Mounting • For the measurement of absorbing gases such as ammonia NH or some fluorocarbons please use FMR230 in a stilling well. • The measuring range begins, where the beam hits the tank bottom. Particularly with dish bottoms or conical outlets the level cannot be detected below this point.
  • Page 12 Mounting Micropilot M FMR244 PROFIBUS PA 2.3.9 Measuring conditions in solids • The measuring range begins, where the beam hits the bottom. Particularly with conical outlets the level cannot be detected below this point. The maximum measuring range can be increased in such applications by using a top target positioner (see TI345F/00/EN).

  • Page 13: Post-Installation Check

    Micropilot M FMR244 PROFIBUS PA Mounting 2.3.10 Turn housing After mounting, the housing can be turned 350° in order to simplify access to the display and the terminal compartment. Proceed as follows to turn the housing to the required position: •...

  • Page 14: Wiring

    Wiring Micropilot M FMR244 PROFIBUS PA Wiring Warning! When using the measuring instrument in hazardous areas, installation must comply with the corresponding national standards and regulations and the Safety Instructions or Installation or Control Drawings. " Caution! Before connection please note the following: •...

  • Page 15: Wiring In T12 Housing

    Micropilot M FMR244 PROFIBUS PA Wiring Wiring in T12 housing Unscrew housing cover (1). Insert cable (2) through gland (3). Connect cable screen to the grounding terminal (4) within the terminal compartment. Make connection (see terminal assignment). Tighten cable gland (3).

  • Page 16: Terminal Assignment

    Wiring Micropilot M FMR244 PROFIBUS PA Terminal assignment plant ground PA- PA+ L00-FMP4xxxx-04-00-00-en-007 Cable specification PROFIBUS Twisted, screened pairs must be used. The following cable types can be used, for example: • Siemens 6XV1 830-5BH10 (grey) • Kerpen CEL-PE/OSCR/PCV/FRLA FB-02YS(ST)YFL (grey) •...

  • Page 17: Screening/Potential Matching

    Micropilot M FMR244 PROFIBUS PA Wiring Overvoltage protector The level transmitter Micropilot M with T12-housing (housing version "D", see ordering information) is equipped with an internal overvoltage protector (600 V surge arrester) according to DIN EN 60079-14 or IEC 60060-1 (impulse current test 8/20 μs, Î = 10 kA, 10 pulses).

  • Page 18: Operation

    Operation Micropilot M FMR244 PROFIBUS PA Operation General structure of the operating menu The operating menu is made up of two levels: • Function groups (00, 01, 03, …, 0C, 0D): The individual operating options of the instrument are split up roughly into different function groups.

  • Page 19: Display And Operating Elements

    Micropilot M FMR244 PROFIBUS PA Operation The third digit numbers the individual functions within the function group: → • basic setup • tank shape • medium property • process cond Here after the position is always given in brackets (e.g. "tank shape" (002)) after the described function.
  • Page 20 Operation Micropilot M FMR244 PROFIBUS PA 4.2.1 Display Headline Position indicator ENDRESS + HAUSER Symbol Main value Bargraph Unit – Selection list Help text +21dB Envelope curve 0.00 2.305m 10.00 L00-FMRxxxxx-07-00-00-en-003 4.2.2 Display symbols The following table describes the symbols that appear on the liquid crystal display:...
  • Page 21 Micropilot M FMR244 PROFIBUS PA Operation 4.2.3 Key assignment Key(s) Meaning Navigate upwards in the selection list. Edit numeric value within a function. Navigate downwards in the selection list. Edit numeric value within a function. Navigate to the left within a function group.

  • Page 22: Device Address

    Operation Micropilot M FMR244 PROFIBUS PA Device address 4.3.1 Software addressing Software addressing comes into operation, when DIP-switch 8 is in the position "ON". BA034S/04/EN describes, how to set the address in this case. 4.3.2 Hardware addressing T II T II...

  • Page 23: Commissioning

    Micropilot M FMR244 PROFIBUS PA Commissioning Commissioning Function check Make sure that all final checks have been completed before you start up your measuring point: • Checklist "Post-installation check", → ä 13. • Checklist "Post-connection check", → ä 17. Switching on the measuring device...

  • Page 24: Overview Basic Setup

    Commissioning Micropilot M FMR244 PROFIBUS PA Overview Basic Setup level measurement in liquids level measurement in solids flange: flange: reference point of reference point of measurement measurement E = empty calibr. (= zero), setting in 005 F = full calibr. (= span), setting in 006...
  • Page 25 Micropilot M FMR244 PROFIBUS PA Commissioning " Caution! The basic setup is sufficient for successful commissioning in most applications. Complex measuring operations necessitate additional functions that the user can use to customise the Micropilot as necessary to suit his specific requirements. The functions available to do this are described in detail in the BA291F/00/EN.

  • Page 26: Basic Setup With The Device Display

    Commissioning Micropilot M FMR244 PROFIBUS PA Basic Setup with the device display 5.4.1 Function "measured value" (000) ⇒ ENDRESS + HAUSER – This function displays the current measured value in the selected unit (see "customer unit"(042) function). The number of digits after decimal point can be selected in the "no.of decimals"...
  • Page 27 Micropilot M FMR244 PROFIBUS PA Commissioning 5.4.4 Function "tank shape" (002), liquids only ⇒ ENDRESS + HAUSER – This function is used to select the tank shape. Selection: • dome ceiling • horizontal cyl • bypass • stilling well • flat ceiling •...
  • Page 28 Commissioning Micropilot M FMR244 PROFIBUS PA 5.4.5 Function "medium property" (003), liquids only ⇒ ENDRESS + HAUSER – This function is used to select the dielectric constant. Selection: • unknown • DC: < 1.9 • DC: 1.9 ... 4 • DC: 4 ... 10 •...
  • Page 29 Micropilot M FMR244 PROFIBUS PA Commissioning standard calm surface turb. surface For all applications that do not fit into Storage tanks with immersion tube or Storage / buffer tanks with rough any of the following groups. bottom filling. surface due to free filling or mixer nozzles.
  • Page 30 Commissioning Micropilot M FMR244 PROFIBUS PA 5.4.7 Function "vessel / silo" (00A), solids only ⇒ ENDRESS + HAUSER – This function is used to select the vessel / silo. Selection: • unknown • metal silo • concrete silo • bin / bunker •...
  • Page 31 Micropilot M FMR244 PROFIBUS PA Commissioning 5.4.9 Function "process cond." (00C), solids only ⇒ ENDRESS + HAUSER – This function is used to select the process conditions. Selection: • standard • fast change • slow change • test: no filter 5.4.10 Function "empty calibr."...
  • Page 32 Commissioning Micropilot M FMR244 PROFIBUS PA 5.4.12 Function "pipe diameter" (007) ⇒ ENDRESS + HAUSER – This function is used to enter the pipe diameter of the stilling well or bypass pipe.Microwaves propagate more slowly in pipes than in free space. This effect depends on the inside diameter of the pipe and is automatically taken into account by the Micropilot.
  • Page 33 Micropilot M FMR244 PROFIBUS PA Commissioning L00-FMR2xxxx-14-00-06-en-010 distance = ok • mapping is carried out up to the currently measured echo • The range to be suppressed is suggested in the "range of mapping" (052) function Note! Anyway, it is wise to carry out a mapping even in this case.
  • Page 34 Commissioning Micropilot M FMR244 PROFIBUS PA 5.4.15 Function "range of mapping" (052) ⇒ ENDRESS + HAUSER – This function displays the suggested range of mapping. The reference point is always the reference point of the measurement (→ ä 24). This value can be edited by the operator. For manual mapping, the default value is: 0 m.

  • Page 35: Envelope Curve With The Instrument Display

    Micropilot M FMR244 PROFIBUS PA Commissioning 5.4.17 Function "dist./meas.value" (008) ⇒ ENDRESS + HAUSER – The distance measured from the reference point to the product surface and the level calculated with the aid of the empty adjustment are displayed. Check whether the values correspond to the actual meas.
  • Page 36 Commissioning Micropilot M FMR244 PROFIBUS PA 5.5.2 Function "recording curve" (0E2) This function defines whether the envelope curve is read as a • single curve or • cyclic ⇒ ENDRESS + HAUSER – Note! • If the cyclical envelope curve is active in the display, the measured value is refreshed in a slower cycle time.
  • Page 37 Micropilot M FMR244 PROFIBUS PA Commissioning Endress+Hauser...
  • Page 38 Commissioning Micropilot M FMR244 PROFIBUS PA Endress+Hauser...
  • Page 39 Micropilot M FMR244 PROFIBUS PA Commissioning Endress+Hauser...
  • Page 40 www.endress.com/worldwide KA1010F/00/EN/12.09 71030600 CCS/FM+SGML 6.0 71030600...
