Self-Adhesive Strip - Intermec EasyCoder F2 Installation And Operation Manual

Paper, cont'd.

Self-Adhesive Strip

Intermec EasyCoder F2 – Installation & Operation Ed. 1
a Web Width (including backing paper):
Maximum .......................... :
Minimum (standard) .......... :
Minimum (Quick-Load) .... :
b Backing Paper
The backing paper must not extend more than a total of 1.6 mm
(0.06") outside the paper and should protrude equally on both sides.
c Paper Width (excluding backing paper):
Maximum .......................... :
Minimum .......................... :
Media Type Setup:
• Fix length strip
• Var length strip
Appendix 2 Media Specifications
60.0 mm (2.36")
25.0 mm (1.00")
40.0 mm (1.57")
58.4 mm (2.30")
23.8 mm (0.94")
90
