TD-W8968
4.11.1 Settings
This section provides three important functions for managing the modem router: Export(Backup),
Import(Update) and Restore Default. The detailed manipulations are described below.
4.11.1.1 Export
Choose "Management" "Settings" "Export", you can see the Export screen, this screen
(shown in Figure 4-116) allows you to save the current configuration of the modem router as a
backup file.
To back up the modem router's current settings:
1.
Click the Backup Settings button on the preceding screen (pop-up Figure 4-116), the
following screen will then appear (shown in Figure 4-117).
2.
Click the Save button, and save the file as the appointed file (shown in Figure 4-118).
300Mbps Wireless N USB ADSL2+ Modem Router User Guide
Figure 4-116
Figure 4-117
92
