TD-W8968
4.5.9.2 QoS Classification
This section will guide you to create a traffic class rule to classify the upstream traffic, assign
queue which defines the precedence and the interface and optionally overwrite the IP header
DSCP byte.
A rule consists of a class name and at least one condition below. All of the specified conditions in
this classification rule must be satisfied for the rule to take effect.
Click the Add button Figure 4-47, and you can configure the QoS on the next screen.
After you specify the condition, click Save/Apply to save the entry.
4.5.10 Bandwidth Control
Choose "Advanced Setup" "Bandwidth Control" and then you will see the screen as shown in
Figure 4-49. This page allows you to enable this function and to configure the value of Total
Upstream/Downstream Bandwidth.
300Mbps Wireless N USB ADSL2+ Modem Router User Guide
Figure 4-47
Figure 4-48
48
