Routing - TP-Link TDW8968V3 User Manual

TD-W8968
according to their min upstream/downstream rate. The greater a rule's min upstream/downstream
rate is, the more bandwidth it gets.

4.5.11 Routing

Choose "Advanced Setup" "Routing", it includes three menus: Default Gateway, Static Route
and RIP. The detailed descriptions are provided below.
4.5.11.1 Default Gateway
Choose "Advanced Setup" "Routing" "Default Gateway", you can see the Default Gateway
screen.
4.5.11.2 Static Route
Choose "Advanced Setup" "Routing" "Static Route". You can see the Static Route screen,
this screen allows you to configure the static routes (shown in Figure 4-54). A static route is a
pre-determined path that network information must travel to reach a specific host or network.
To add static routing entries:
1. Click the Add button in Figure 4-54, and you will see the screen as shown in Figure 4-55.
300Mbps Wireless N USB ADSL2+ Modem Router User Guide
Figure 4-53
Figure 4-54
51
