TD-W8968
For RADVD:
1) If Randomly Generate is selected, it doesn't need to be configured.
2) If Statically Configure is selected, please complete the following parameters.
•
Prefix: Enter a value for the site prefix.
Click Save/Apply to make the configuration take effect.

4.5.6 NAT

NAT (Network Address Translation) allows you to share one WAN (Wide Area Network) IP
address for multiple computers on your LAN (Local Area Network).
Note:
When you select PPPoA or PPPoE for the WAN Setup, or when you select Enable NAT for the
type of IPoA and IPoE connection
Web-based Utility.
Choose "Advanced Setup" "NAT", there are three submenus under the main menu: Virtual
Servers, Port Triggering, DMZ Host and ALG. Click any of them, and you will be able to
configure the corresponding function.
4.5.6.1 Virtual Servers
Choose "Advanced Setup" "NAT" "Virtual Servers", you can set up virtual servers on the
screen below (shown in Figure 4-30).
Virtual servers can be used for setting up public services on your LAN, such as DNS, Email and
FTP. A virtual server is defined as a service port, and all requests from the Internet to this service
port will be redirected to the computer specified by the server IP. Any PC that was used for a
virtual server must have a static or reserved IP Address because its IP Address may change when
using the DHCP function.
300Mbps Wireless N USB ADSL2+ Modem Router User Guide
(4.5.2 WAN
36
Service), you will see the NAT menu in the
