Integrated Peripherals

These options display items that define the operation of peripheral components on
the system's input/output ports.
VIA OnChip IDE Device
VIA OnChip PCI Device
SuperIO Device
Onboard LAN Device
Onboard LAN Boot ROM
VIA OnChip IDE Device (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
OnChip SATA
SATA Mode
IDE DMA transfer access
Onchip IDE Channel0
Onchip IDE Channel1
IDE Prefetch Mode
Primary Master
Primary Slave
Secondary Master PIO
Secondary Slave
Primary Master
Primary Slave
Secondary Master UDMA
Secondary Slave
IDE HDD Block Mode
OnChip SATA (Enabled)
Enables or Disables the build-in on-chip Serial ATA.
SATA Mode (IDE)
Use this item to select the mode of the Serial ATA.
IDE DMA transfer access (Enabled)
This item allows you to enable the transfer access of the IDE DMA then burst onto the PCI
bus and nonburstable transactions do not.
OnChip IDE Channel0/1 (Enabled)
Use this item to enable or disable the PCI IDE channels that are integrated on the
motherboard.
Phoenix-AwardBIOS CMOS Setup Utility
Integrated Peripherals
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
F5:Previous Values F6:Fail-Safe Defaults
Phoenix-AwardBIOS CMOS Setup Utility
VIA OnChip IDE Device
[Enabled]
[IDE]
[Enabled]
[Enabled]
[Enabled]
[Enabled]
PIO [Auto]
PIO [Auto]
[Auto]
PIO [Auto]
UDMA [Auto]
UDMA [Auto]
[Disabled]
UDMA [Disabled]
[Enabled]
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
F5:Previous Values F6:Fail-Safe Defaults
