Advanced Chipset Features

These items define critical timing parameters of the motherboard. You should leave the
items on this page at their default values unless you are very familiar with the technical
specifications of your system hardware. If you change the values incorrectly, you may
introduce fatal errors or recurring instability into your system.
DRAM Clock/Drive Control [Press Enter]
CPU & PCI Bus Control
System BIOS Cacheable
Video RAM Cacheable
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
F5:Previous Values
DRAM Clock/Drive Control
Scroll to this item and press <Enter> to view the following screen:
Current FSB Frequency
Current DRAM Frequency
DRAM Clock
DRAM Timing
x
SDRAM CAS Latency
x Bank Interleave
x
Precharge to Active (Trp)
x
Active to Precharge (Tras)
x
Active to CMD (Trcd)
x
REF to ACT/REF (Trfc)
x
ACT (0) to ACT(1) (TRRD)
Read to Precharge (Trtp)
Write to Read CMD (Twtr)
Write Recovery Time (Twr)
DRAM Command Rate
RDSAIT mode
x
RDSAIT selection
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
F5:Previous Values
Current FSB/DRAM Frequency (100MHz/200MHz)
This item displays current FSB/DRAM frequency.
Phoenix-AwardBIOS CMOS Setup Utility
Advanced Chipset Features
[Press Enter]
[Enabled]
[Disabled]
F6:Fail-Safe Defaults F7:Optimized Defaults
(Press Enter)
Phoenix-AwardBIOS CMOS Setup Utility
DRAM Clock/Drive Control
100MHz
200MHz
[By SPD]
[Auto By SPD]
[ DDR/DDR 2.5 / 4]
Disabled
4T
07T
4T
21T
3T
[2T]
[1T/2T]
[4T]
[2T Command]
[Auto]
03
F6:Fail-Safe Defaults F7:Optimized Defaults
Using BIOS
