Table of Motherboard Components
LABEL
1. DDRII1
2. ATX_POWER2
3. IDE2
4. IDE1
5. PANEL1
6. SATA1~2
7. CLR_CMOS1
8. PCI1
9. AUDIO1
10. F_USB1~2
11. IR1
12. COM2
13. CPUFAN1
This concludes Chapter 1. The next chapter explains how to install the motherboard.
Introducing the Motherboard
COMPONENTS
240-pin DDR2 SDRAM slot
Standard 20-pin ATX power connector
Secondary IDE connector
Primary IDE connector
Front Panel switch/LED header
Serial ATA connectors
Clear CMOS jumper
32-bit add-on card slot
Front panel Audio header
Front Panel USB headers
Infrared header
Onboard Serial port header
CPU cooling fan connector
5
