Jumpers:
SW1:
DIP Switch for CPU voltage and clock ratio
JP4,JP5,JP6:
CPU external (bus) clock
JP14:
Clear CMOS
Connectors:
PS2 MS:
PS/2 mouse connector
KB2:
PS/2 keyboard connector
COM1:
COM1 connector
COM2:
COM2 connector
PRINTER:
Printer connector
PWR2:
ATX power connector
USB:
USB connector
FDC:
Floppy drive connector
IDE1:
IDE1 primary channel
IDE2:
IDE2 secondary channel
FAN1:
CPU Fan connector
FAN2:
CPU Fan connector
FAN3:
Fan Connector
IrDA:
IrDA (Infrared) connector
HDD LED:
HDD LED connector
PANEL:
Front panel (Multifunction) connector
SPWR:
ATX Soft-Power Switch Connector
MODEM-WKUP: MODEM Wake Up Connector
LAN-WKUP:
LAN Wake Up Connector
SB-LINK:
Creative PCI sound card connector
Hardware Installation
2-3
