Connectivity

Connectivity
The switch connects to Ethernet networks or workstations through the fixed front panel
RJ45 connectors and four uplink ports that support optional Mini‐GBICs.
At the time of this printing, the Mini‐GBICs supported and available from Enterasys are
described in Table
standard.
Table 1-2 Description of Mini-GBICs
Mini-GBIC
MGBIC-LC01
MGBIC-LC03
MGBIC-LC09
MGBIC-MT01
MGBIC-08
MGBIC-02

Management

Management of the module can be either in‐band or out‐of‐band. In‐band remote
management is possible using Telnet, Enterasys Networks' NetSight
application, or the WebView application. Out‐of‐band management is provided through
the RJ45 COM (Communication) port on the front panel using a VT100 terminal or a
VT100 terminal emulator.
1-6 Introduction
1‐2 on page 1‐6. These Mini‐GBICs meet or exceed the IEEE 802.3z‐1998
Specification
Provides one 1000BASE-SX compliant LC fiber-optic multimode port and a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-LC01/MGBIC-MT01 Specifications
Provides one 1000BASE-SX compliant LC fiber-optic multimode port with a
standard LC duplex connector. For optical and operating range specifications,
refer to "MGBIC-LC03 Specifications
Provides one 1000BASE-LX compliant LC fiber-optic single-mode port with a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-LC09 Specifications
Provides one 1000BASE-SX compliant LC fiber-optic multimode port with a
standard MT-RJ connector. For optical and operating range specifications,
refer to "MGBIC-LC01/MGBIC-MT01 Specifications
page A-4.
Provides one 1000BASE-ELX compliant LC fiber-optic single-mode port with a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-08 Specifications
Provides one RJ45 copper connection that is compliant with a 1000BASE-T
standard RJ45 connector. For optical and operating range specifications, refer
to "MGBIC-02 Specifications
(1000BASE-SX)" on page A-4.
(1000BASE-SX)" on page A-4.
(1000BASE-LX)" on page A-5.
(1000BASE-ELX)" on page A-6.
(1000BASE-T)" on page A-6.
(1000BASE-SX)" on
®
