Removing a Mini-GBIC
To remove a Mini‐GBIC from a
proceed as follows:
1. Attach your antistatic wrist strap (refer to the instructions in your antistatic wrist
strap package) before removing the Mini‐GBIC.
2. Remove the cables connected to the Mini‐GBIC.
3. Locate the release tab under the front end of the Mini‐GBIC. For the type of Mini‐
GBIC shown in Figure
Mini‐GBIC from the port slot. For the type of Mini‐GBIC shown in Figure
on the release tab to release the Mini‐GBIC from the port slot.
4. Grasp the sides of the Mini‐GBIC and pull it straight out of the port slot.
If you are storing or shipping a Mini‐GBIC, which has a fiber‐optic connector, insert its
protective dust cover to protect the ends of the fiber‐optic fibers from dust and
contamination.

Installing the Switch on a Flat Surface

When installing the switch on a flat surface, the installation of the rubber feet is
recommended to prevent the switch from sliding on a flat surface. Installing the rubber
feet is optional if you are installing the switch in a rack. To install the rubber feet, proceed
to "Installing the Rubber Feet" below. For instructions to rack mount the switch, proceed
to "Rack Mounting the Switch" on page 3‐8.
Caution: Do NOT remove a Mini-GBIC from a slot without releasing the locking tab
located at the front of the Mini-GBIC. This can damage the Mini-GBIC. The Mini-GBIC and
its host device are sensitive to static discharges. Use an antistatic wrist strap and observe
all static precautions during this procedure. Failure to do so could result in damaging the
Mini-GBIC or host device. Always leave the Mini-GBIC in the antistatic bag or an
equivalent antistatic container when not installed.
Precaución: NO quite el Mini-GBIC de la ranura sin antes abrir la traba ubicada en la
parte frontal del Mini-GBIC. Si lo hace, puede dañar el Mini-GBIC, puesto que es muy
sensible a las descargas de electricidad estática, al igual que el dispositivo host. Utilice la
pulsera antiestática y tome todas las precauciones necesarias durante este
procedimiento. Si no lo hace, pude dañar el Mini-GBIC o el dispositivo host. Mientras no
esté instalado, mantenga el Mini- GBIC en su bolsa antiestática o en cualquier otro
recipiente antiestático.
3‐3, push in on the release tab as far as it will go to release the
port slot, refer back to Figure 3‐3 and Figure

Installing the Switch on a Flat Surface

3‐4, and
3‐4, pull out
SecureStack B2 Installation Guide 3-5
