Chapter 3
Installation Procedures
Section 3.4
Installing the Base Station
WARNING!
The equipment should be installed in compliance with the National Electrical Code (NEC), ANSI/
NFPA 70, the Canadian Electrical Code (CEC), Part 1, CSA C22.1; and when applicable, the National
Electrical Safety Code IEEE C2. Unless marked or otherwise identified, the Standard for the Protection
of Electronic Computer/Data Processing Equipment, ANSI/NFPA 75.
The following components are required for the installation:
• Mounting bracket
• WIN7000
• RF antennas
• GPS antenna
• Power supply
• Ground, data, and power cables
To install the WIN7000, follow these general steps:
1. Install the mounting bracket at the chosen location.
2. Install the antennas.
3. Prepare the grounding cables.
4. Lay out the connection cables.
5. Mount the power supply.
6. Mount the base station to the mounting bracket.
7. Connect all cables to the WIN7000 and seal connections with suitable electrical tape or putty.
Section 3.4.1
Sealing Screw
CAUTION!
Do not attempt to open the sealing screw on the bottom side of base-station. Opening the screw will
break the sealing and will cause the moisture getting into the base-station.
10
RUGGEDCOM WIN7000
Installation Guide
Installing the Base Station
