RUGGEDCOM WIN7000
Installation Guide
Section 3.4.6

Power and Cable Connections

There are three power connection options for the WIN7000, which are described in the following sections. The
power connection options are as follows:

• PEC (Copper) Type Base Station

• SFA (Optical) Type Base Station
• SFD Type Base Station
The WIN7000 can be equipped with copper or fiber Ethernet connections. These copper and fiber port options
are described in Section 3.4.6.1, "PEC (Copper) Type Base Station"
Base Station".
Use the following tools to fasten or loosen the connectors:
Description
Type-N 1 Nm Variant
Wrench, 20 mm
Modular Plugs
Connector Removal
Tool, BNC/TNC, 12"
Curved Jaw Locking
Plier
Section 3.4.6.1
PEC (Copper) Type Base Station
The power system is supplied by Siemens (WINPS).
To connect the power system and cables, do the following:
Procedure: Connecting the Power System and Cables
1. Connect the supplied combo (DC + Ethernet cable) to the power system (WINPS) port labeled DC + ETH.
2. Connect the other end to port 6 on the WIN7000 unit as shown in
3. Connect the Ethernet input to the 10/100 Base-T connector on the power system.
The following figure shows the physical connection between the WIN7000, the power system, and the AC power
source.
Power and Cable Connections
Manufacturer Tool Number
Tessco 13055
Ideal 35-042
Irvin 502L3
and Section 3.4.6.2, "SFA (Optical) Type
Type Torque
Hexagon 1.35 N·m (11.9 lbf-in)
Round 0.56 N·m (4.9 lbf-in)
Curved 4 N·m (35.4 lbf-in)
Figure 9.
Chapter 3
Installation Procedures
Connector Name
ANT1/ANT2
GPS
DC/ETH
15
