Chapter 3
Installation Procedures
Figure 11: Fiber Optic Ethernet Port Option
Table: WIN7000 Connectors and Cables
Port
Connector
Number
Name
1
ANT1
2
GND
3
GPS
4
DC/ETH or DC
5
Console
6
F/O
7
ANT2
Section 3.4.6.3
SFD Type Base Station
The power system is supplied by the operator.
To connect the power system and cables, do the following:
Procedure: Connecting the Power System and Cables
1.
Connect the power system DC output to the supplied connector.
18
Connector Type
Cable Type
N type Female
RG 6 or 9
#10 AWG bare
Adjustable nut
copper wire
TNC Female
Proprietary cable
DC/ETH or DC
Proprietary cable
UART 3P to
3-pin
DB9F"
Fiber Optic SM
OFNR I/O with
Optic SM Mini LC
Industrial Plug,
ODVA Cable
N type Female
RG 6 or 9
Function
Connected to external
antenna or omni-directional
antenna
Grounding
GPS signal
48 VDC / Return / 5A +
Ethernet Cat5
Or 48 VDC / Return / 5A
Low level CLI for
technicians
Optic 100M/1GMbit
Connected to external
antenna or omni-directional
antenna
RUGGEDCOM WIN7000
Installation Guide
Connected to
Antenna
Central earth ground, tower
or pole chassis
GPS antenna
Power supply +
Network/Router/Switch
Or Power supply
PC
Network/Router/Switch
Antenna
