KA01094F/00/EN/14.12
71207242
Products
Brief Operating Instructions
Gammapilot M FMG60
Radiometric Measurement
These Instructions are Brief Operating Instructions; they do not
replace the Operating Instructions included in the scope of
supply.
For detailed information, refer to the Operating Instructions and
other documentation on the CD-ROM provided or visit
"www.endress.com/deviceviewer".
Solutions
Services
Advertisement
Table of Contents
Related Manuals for Endress+Hauser Gammapilot M FMG60
Summary of Contents for Endress+Hauser Gammapilot M FMG60
- Page 1 Solutions Services KA01094F/00/EN/14.12 71207242 Brief Operating Instructions Gammapilot M FMG60 Radiometric Measurement These Instructions are Brief Operating Instructions; they do not replace the Operating Instructions included in the scope of supply. For detailed information, refer to the Operating Instructions and other documentation on the CD-ROM provided or visit "www.endress.com/deviceviewer".
-
Page 2: Table Of Contents
Table of contents Gammapilot M FMG60 FOUNDATION Fieldbus Table of contents 1 Safety instructions ............. 3 1.1 Designated use . -
Page 3: Safety Instructions
Gammapilot M FMG60 FOUNDATION Fieldbus Safety instructions Safety instructions Designated use The Gammapilot M is a compact transmitter for non-contact level, level limit, density and concentration measurement. The measuring range of a single Gammapilot M extends up to 2 m (6.6 ft). -
Page 4: Hazardous Area
Safety instructions Gammapilot M FMG60 FOUNDATION Fieldbus Hazardous area Measuring systems for use in hazardous environments are accompanied by separate "Ex documentation", which is an integral part of these Operating Instructions. Strict compliance with the installation instructions and ratings as stated in this supplementary documentation is mandatory. -
Page 5: Radiation Protection
Gammapilot M FMG60 FOUNDATION Fieldbus Safety instructions Radiation protection The GammapilotM is used in conjunction with a radioactive source, contained in a source con- tainer. When handling radioactive sources, the following instructions have to be observed: 1.5.1 Basic regulations on radiation protection WARNING When handling radioactive sources, all unnecessary radiation exposure should be avoided. -
Page 6: Symbols
Safety instructions Gammapilot M FMG60 FOUNDATION Fieldbus Time Stay as short as possible in the area exposed to radiation. Distance Keep as far away as possible from the radiation source. The local radiation intensity decreases as the square-root of the distance from the radiation source. - Page 7 Gammapilot M FMG60 FOUNDATION Fieldbus Safety instructions 1.6.3 Tool symbols Symbol Meaning Allen key A0011221 1.6.4 Symbols for certain types of information Symbol Meaning Allowed Indicates procedures, processes or actions that are allowed. A0011182 Preferred Indicates procedures, processes or actions thar are preferred.
-
Page 8: Installation
Installation Gammapilot M FMG60 FOUNDATION Fieldbus Installation Incoming acceptance, transport, storage 2.1.1 Incoming acceptance Check the packing and contents for any signs of damage. Check the shipment, make sure nothing is missing and that the scope of supply matches your order. - Page 9 Gammapilot M FMG60 FOUNDATION Fieldbus Installation 2.2.2 Installation conditions for level measurement Conditions • For level measurements the Gammapilot M is mounted vertically; if possible the detector head should point downwards. • In cascading mode no gap should occur between the measuring ranges of the different Gammapilot M.
- Page 10 • If only horizontal pipes are accessible, the path of the ray should also be arranged horizontally to reduce the influence of air bubbles and sediments.. • The Endress+Hauser clamping device (see BA00329F/00/EN, Chapter "Accessories") or an equivalent clamping device should be used for fastening the radiation source container and the Gammapilot M to the measuring tube.
- Page 11 Therefore, dia- gonal irradiation or the use of a measurement section is necessary for small pipe diameters. For the configuration of the measuring system please contact your Endress+Hauser sales orga- nization or use the "Applicator"...
-
Page 12: Water Cooling
Installation Gammapilot M FMG60 FOUNDATION Fieldbus Water cooling "Water cooling", see BA00330F/00/EN. Installation check After installing the device, carry out the following checks: • Is the device damaged (visual inspection)? • Does the device correspond to the measuring point specifications for ambient temperature, measuring range etc.? -
Page 13: Wiring
Gammapilot M FMG60 FOUNDATION Fieldbus Wiring Wiring Terminal compartments The Gammapilot M has got two terminal compartments: • Terminal compartment 1, for – Power supply – Signal output (depending on the instrument version) • Terminal compartment 2, for – Signal output (depending on the instrument version) –... -
Page 14: Cable Entries
Wiring Gammapilot M FMG60 FOUNDATION Fieldbus Cable entries The number and type of cable entries depend on the instrument version ordered. The following types may occur: • Gland M20x1.5 tightening diameter (clamping range): 7.0 to 10.5 mm • Cable entry M20x1.5 •... -
Page 15: Terminal Assignment
Gammapilot M FMG60 FOUNDATION Fieldbus Wiring Terminal assignment Terminal compartment 1 Terminal compartment 2 SIM WP PT100 9 10 11 12 IN CASCADE OUT A0018085 A0018084 90 to 253VAC, 18 to 36 VDC Terminal(s) Meaning Grounding of the cable screen... -
Page 16: Foundation Fieldbus Cable Specifications
Wiring Gammapilot M FMG60 FOUNDATION Fieldbus Terminal compartment for Feature 30 of the ordering information: Power supply wiring/output wiring Supply voltage Signal output Non-Ex; Non-Ex Ex e; Ex ia Ex e; Ex e Ex d (XP); Ex d (XP) Ex d (XP); Ex ia (IS) Dust-Ex;... -
Page 17: Foundation Fieldbus Terminal Voltage
Gammapilot M FMG60 FOUNDATION Fieldbus Wiring FOUNDATION Fieldbus terminal voltage The following values are the voltages across the terminals directly at the device: Type minimum terminal voltage maximum terminal voltage standard 32 V Ex ia (FISCO model) 17.5 V Ex ia (Entity concept) 24 V Approx. -
Page 18: Wiring In Terminal Compartment 1
Wiring Gammapilot M FMG60 FOUNDATION Fieldbus Wiring in terminal compartment 1 CAUTION Before connection please note the following: ‣ When using the instrument in hazardous areas, make sure to comply with national standards and the specifications in the Safety Instructions (XAs). Make sure you use the specified cable gland. -
Page 19: Wiring In Terminal Compartment 2
Gammapilot M FMG60 FOUNDATION Fieldbus Wiring Wiring in terminal compartment 2 CAUTION Before connection please note the following: ‣ Connect potential matching line to transmitter ground terminal and to the ground terminal of the water cooling jacket (if present) before connecting up the instrument ("Potential equalization", ... -
Page 20: Connecting The Remote Display And Operation Fhx40
Wiring Gammapilot M FMG60 FOUNDATION Fieldbus Connecting the remote display and operation FHX40 The remote display and operating unit FHX40 is available as accessory. It is connected to the FHX40-connector of the Gammapilot M via the supplied cable. To do this, the housing of the Gammapilot M needs not to be opened. -
Page 21: 3.11 Post-Connection Check
Gammapilot M FMG60 FOUNDATION Fieldbus Wiring 3.11 Post-connection check After wiring the device, carry out the following checks: • Is the protective earth connected? • Is the Potential Equalization Line connected? • Are the terminals correctly assigned? • Are the cable glands and dummy plugs tight? •... -
Page 22: Operation
Operation Gammapilot M FMG60 FOUNDATION Fieldbus Operation General structure of the operating menu 4.1.1 Function code The functions of the Gammapilot M are arranged in an operating menu. To ensure easy orientation within the menu, a unique position code is indicated on the display for each function. -
Page 23: Display And Operating Elements
Gammapilot M FMG60 FOUNDATION Fieldbus Operation Display and operating elements The LCD module VU331 for displaying and operating is inside the remote display and operating unit FHX40. The measured value can be read off through the FHX40 sight glass. In order to operate the instrument, the FHX40 must be opened by removing the four screws. - Page 24 Operation Gammapilot M FMG60 FOUNDATION Fieldbus 4.2.2 Display symbols The following table describes the symbols that appear on the liquid crystal display: Symbol Meaning ALARM_SYMBOL This alarm symbol appears when the instrument is in an alarm state. If the symbol flashes, this indicates a warning.
-
Page 25: Commissioning
Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Commissioning Calibration: overview Power up instrument see ä 26, "Switching on the measuring device" Basic setup see ä 27, "Basic setup" Calibration for level measurement Calibration for density and concen- Calibration for density measure-... -
Page 26: Switching On The Measuring Device
Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Switching on the measuring device After switching on the supply voltage, the instrument is first initialized. Due to internal memory tests, this takes approx. 2 minutes. On-site display Meaning FMG60 Then, the following appear for approximately five seconds: •... -
Page 27: Basic Setup
Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Basic setup 5.4.1 Function "Present date" (*01) On-site display Meaning Present date Date and time of the basic setup are specified in this function. 17.11.04 10:30 dd.mm.yy hh:mm 5.4.2 Function "Beam type" (*02) On-site display... - Page 28 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus 5.4.4 Function "Operating mode" (*04) On-site display Meaning Operating mode This function is used to specify in which operating mode the Gammapilot M will be used. Stand alone Master Slave NOTICE The selection can be performed only once and the function is automatically locked after that.
- Page 29 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Options/display: • Stand alone: This option is selected if the Gammapilot M is used as a single instrument. • Master: This option is selected if the Gammapilot is located at the beginning of a cascading chain.
- Page 30 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus A0018108 Level measurement (continuous) Density Level limit detection Concentration Density measurement (with temperature compensation if required) Concentration measurement (density measurement followed by linearization) Endress+Hauser...
- Page 31 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning 5.4.6 Function "Density unit" (*06) On-site display Meaning Density unit This function is needed for density and concentration measure- ments only. It is used to select the density unit. g/cm3 lb/gal Further options: •...
- Page 32 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus 5.4.9 Function "Pipe diam. unit" (*09) On-site display Meaning Pipe diam. unit This function is needed for density and concentration measure- ments only. It is used to select the unit for the pipe diameter.
- Page 33 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning 5.4.11 Function "Output damping" (*0B) On-site display Meaning This function is used to specify the output damping (in Output damping seconds) by which changes of the measured value are 60 s attenuated. After a surge in the level or density it takes 5 x until the new measured value is reached.
-
Page 34: Calibration For Level Measurement And Limit Detection
Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Calibration for level measurement and limit detection 5.5.1 Basic principles The calibration points for the measurement are entered in the "calibration" (*1) function group. Each calibration point consists of a level and the associated pulse rate. - Page 35 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Full calibration Refers to the following situation: • The radiation is switched on. • Within the measuring range, the vessel is filled as far as possible (ideally: 100 %, min. 60 %). If the vessel cannot be filled to at least 60 % during the calibration, the full calibration can alternatively performed with the radiation being switched off, which is a way of simulating a filling of 100 %.
- Page 36 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Background calibration Refers to the following situation: • The radiation is switched off. • If possible, the radiation path is completely covered. The background calibration is necessary, in order to register the natural background radiation at the mounting position of the Gammapilot M.
- Page 37 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Methods for entering the calibration points Automatic calibration For an automatic calibration, the vessel is filled to the required value. For the background calibration the radiation remains switched off, for the other calibration points the radiation is switched on.The Gammapilot M automatically records the pulse rate.
- Page 38 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus 5.5.2 Background calibration Excerpt from the operating menu The following excerpt from the operating menu shows how the background calibration is ente- red. The individual functions are explained in the sections below. Backgr. calibr.
- Page 39 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Function "Avg. pulse rate" (*11) On-site display Meaning Avg. pulse rate The average pulse rate is displayed in this function (after selec- tion of "start" in the previous function). Initially, this value fluc- 186 cps tuates (because of the decay statistics), but due to the integra- tion it reaches an average value in the course of time.
- Page 40 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Function "Background pulse rate" (*12) On-site display Meaning Backgr. pulse rate The pulse rate of the background calibration is displayed in this function. By pressing "E" the displayed value can be confirmed 186 cps and the background calibration completed.
- Page 41 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Function "Calibration point" (*13) On-site display Meaning Calibr. point This function is used to select which calibration point ("full/covered" or "empty/free") will be entered. full/covered empty/free Function "Value full" (*14) / Function "Value empty" (*17)
- Page 42 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Function "Calibration" (*15) On-site display Meaning calibration This function is used to start the automatic entering of the selected calibration point. stop/edit start Options: • stop/edit This option must be selected if – the calibration point is not to be entered (e.g. because it has already been entered). The pulse rate of the calibration point is then displayed in the following function, "full calibr."...
- Page 43 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Function "Avg. pulse rate" (*11) On-site display Meaning avg. pulse rate The average pulse rate is displayed in this function (after selec- tion of "start" in the previous function). Initially, this value fluc- 2548 cps tuates (because of the decay statistics), but due to the integra- tion it reaches an average value in the course of time.
- Page 44 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Function "Full calibration" (*16) / Function "Empty calibration" (*18) On-site display Meaning full calibr. The pulse rate of the respective calibration points is displayed in these functions. The displayed value must be confirmed by 33 cps pressing "E".
- Page 45 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning 5.5.4 Additional settings After the calibration has been finished, the Gammapilot M outputs the measuring value via the FOUNDATION Fieldbus interface. Many additional functions are available for optimizing the measuring point. They can be confi- gured as required.
-
Page 46: Calibration For Density And Concentration Measurements
Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Calibration for density and concentration measurements 5.6.1 Basic principles The calibration points for the measurement are entered in the "calibration" (*1) function group. Each calibration point consists of a density value and the associated pulse rate. - Page 47 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Two-point calibration The recommended comparisen procedure for high exactness standards about the whole measuring range is the two-point calibration. First the background calibration occurs. The two calibration points will be adapt. They should differ considerably. After input of both calibration und .
- Page 48 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Methods for entering the calibration points Automatic calibration For an automatic calibration, the desired calibration point is realized at the measuring tube, i.e. the measuring tube is filled with a medium of the desired density. For the background calibra- tion the radiation remains switched off, for the other calibration points the radiation is switched on.
- Page 49 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Function "Background calibration" (*10) On-site display Meaning backgr. cal. This function is used to start the background calibration. stop/edit start Options: • stop/edit This option must be selected if – no background calibration is to be performed but the pulse rate of an existing background calibration is to be displayed instead.
- Page 50 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Function "Avg. pulse rate" (*11) On-site display Meaning avg. pulse rate The average pulse rate is displayed in this function (after selec- tion of "start" in the previous function). 186 cps Initially, this value fluctuates (because of the decay statistics), but due to the integration it reaches an average value in the course of time.
- Page 51 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Function "Background pulse rate" (*12) On-site display Meaning backgr. pul. rate The pulse rate of the background calibration is displayed in this function. By pressing "E" the displayed value can be confirmed 186 cps and the background calibration completed.
- Page 52 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus 5.6.3 Calibration points Excerpt from the operating menu The following excerpt from the operating menu shows, how the density calibration points are entered. The individual functions are explained in the sections below.The functions are only accessible after the background calibration has been performed.
- Page 53 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Function "Calibration" (*15) On-site display Meaning calibration This function is used to start the automatic entering of the selected calibration point. stop/edit start Options: • stop/edit This option must be selected if – the calibration point is not to be entered (e.g. because it has already been entered). The pulse rate of the calibration point is then displayed in the following function "density...
- Page 54 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Function "Avg. pulse rate" (*11) On-site display Meaning avg. pulse rate The average pulse rate is displayed in this function (after selec- tion of "start" in the previous function). Initially, this value fluc- 1983 cps tuates (because of the decay statistics), but in the course of time it reaches an average value.
- Page 55 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Function "Density calibration" (*1B) On-site display Meaning density calibr. The pulse rate of the respective calibration point is displayed in this function. The display value must be confirmed by pressing 1983 cps "E". "-1" indicates, that no pulse rate is present yet. In this case there are two options: •...
- Page 56 Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus Function "Calibration point" (*1D) On-site display Meaning calibr. point This function is used to specify, if the current calibration piont is to be used. not used used clear Further options: • not used The calibration point is not used.
- Page 57 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Function "Ref. pulse rate" (*1F) On-site display Meaning ref. pulse rate This function displays the reference pulse rate I , which results from the currently active calibration points. The value cannot 31687 cps be edited.
-
Page 58: Density Measurement/Temperature-Compensated
Commissioning Gammapilot M FMG60 FOUNDATION Fieldbus 5.6.4 Linearization (for concentration measurements) If the concentration is to be measured in a unit other than the "density unit" (*06), a linearization must be performed after the calibration. This can be done in the "Linearization" (*4) function group. The functions of this group and the linearization procedure are described in Operating Instructions BA00287F/00/EN "Description... - Page 59 Gammapilot M FMG60 FOUNDATION Fieldbus Commissioning Endress+Hauser...
