Endress+Hauser Gammapilot M FMG60 Operating Instructions Manual

Radiometric measurement
Hide thumbs Also See for Gammapilot M FMG60:
Table of Contents

Advertisement

Quick Links

BA00329F/00/EN/15.15
71298583
Valid as of software version:
V01.03.08
Products
Operating Instructions
Gammapilot M FMG60
Radiometric Measurement
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Gammapilot M FMG60

Summary of Contents for Endress+Hauser Gammapilot M FMG60

  • Page 1 Products Solutions Services BA00329F/00/EN/15.15 71298583 Valid as of software version: V01.03.08 Operating Instructions Gammapilot M FMG60 Radiometric Measurement...
  • Page 2 You can find an overview of all the device functions in the Appendix. A detailed description of all the instrument functions is given in Operating Instructions BA00287F/00/EN "Gammapilot M - Description of Device Functions" which can be found on the CD-ROM supplied. Endress+Hauser...

  • Page 3: Table Of Contents

    Certificates and approvals ....10 Contact addresses of Endress+Hauser ..80 Registered trademarks ..... 10 Accessories .

  • Page 4: Safety Instructions

    Safety instructions Gammapilot M FMG60 PROFIBUS PA Safety instructions Designated use The Gammapilot M is a compact transmitter for non-contact level, level limit, density and concentration measurement. The measuring range of a single Gammapilot M extends up to 2 m (6.6 ft). Large measuring ranges of any size can be implemented, however, by cascading several Gammapilot M devices.

  • Page 5: Radiation Protection

    Gammapilot M FMG60 PROFIBUS PA Safety instructions Radiation protection The Gammapilot M is used in conjunction with a radioactive source, contained in a source container. When handling radioactive sources, the following instructions have to be observed: 1.4.1 Basic regulations on radiation protection...

  • Page 6: Symbols

    Safety instructions Gammapilot M FMG60 PROFIBUS PA Symbols 1.5.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. A0011189-DE WARNING! WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.
  • Page 7 Gammapilot M FMG60 PROFIBUS PA Safety instructions 1.5.4 Symbols for certain types of information Symbol Meaning Allowed Indicates procedures, processes or actions that are allowed. A0011182 Preferred Indicates procedures, processes or actions thar are preferred. A0011183 Forbidden Indicates procedures, processes or actions that are forbidden.

  • Page 8: Identification

    Identification Gammapilot M FMG60 PROFIBUS PA Identification Parts of the Gammapilot M Terminal head Mounting collar Detector pipe Measuring range marks Terminal compartment 2 Terminal compartment 1 Supplementary nameplate Centering knob Instrument nameplate 10. Cooling water connections 11. Marking of the radiation...

  • Page 9: Nameplates

    Specification of required temperature resistance of the connected cables (only for instrument versions with water cooling jacket) Scope of delivery • Ordered version of the device (including Operating Instructions) • Endress+Hauser operating program (on the CD-ROM supplied) • Accessories as ordered Endress+Hauser...

  • Page 10: Supplied Documentation

    The device takes into account applicable standards and regulations which are listed in the EC declaration of conformity and thus meets the legal requirements of the EC Directives. Endress+Hauser confirms the successful testing of the device by affixing to it the CE mark.

  • Page 11: Installation

    Gammapilot M FMG60 PROFIBUS PA Installation Installation Incoming acceptance, transport, storage 3.1.1 Incoming acceptance Check the packing and contents for any signs of damage. Check the shipment, make sure nothing is missing and that the scope of supply matches your order.

  • Page 12: Installation Conditions

    Installation Gammapilot M FMG60 PROFIBUS PA Installation conditions 3.2.1 Dimensions, weight Gammapilot M (without water cooling jacket) 537 (22.6) mm (in) A0018072 Gammapilot M with water cooling jacket or collimator 537 (22.6) 12 (0.47) 164 (6.46) mm (in) A0018073 Without water cooling...
  • Page 13 Gammapilot M FMG60 PROFIBUS PA Installation 3.2.2 Installation conditions for level measurement Conditions • For level measurements the Gammapilot M is mounted vertically; if possible the detector head should point downwards. • The exit angle of the source container must be exactly aligned to the measuring range of the Gammapilot M.
  • Page 14 Installation Gammapilot M FMG60 PROFIBUS PA 3.2.3 Installation conditions for level limit detection Conditions • For level limit detection, the Gammapilot M should be mounted horizontally at the height of the desired level limit. • The exit angle of the source container must be exactly aligned to the measuring range of the Gammapilot M.
  • Page 15 • If only horizontal pipes are accessible, the path of the ray should also be arranged horizontally to reduce the influence of air bubbles and sediments. • The Endress+Hauser clamping device ( ä 81, "Accessories") or an equivalent clamping device should be used for fastening the radiation source container and the Gammapilot M to the measuring tube.
  • Page 16 Installation Gammapilot M FMG60 PROFIBUS PA 3.2.5 Empty pipe detection A0018077 Gammapilot M Monitoring detector FTG20 or FMG60 Mounting the FTG20 or FMG60 on the FMG60 for empty pipe detection If the pipe becomes empty as a result of operational processes, the radiation on the detector side can hit dangerous levels.

  • Page 17: Water Cooling

    Gammapilot M FMG60 PROFIBUS PA Installation Water cooling For the versions of the Gammapilot with water cooling jacket, the following applies: • Material: 316L • Water connection: 2 x G 1/4"A, DIN ISO 228 • Inlet temperature: max. 40 °C (104 °F) •...
  • Page 18 Installation Gammapilot M FMG60 PROFIBUS PA 3.3.1 Mounting versions A0018079 Recommended mounting position for level measurement: compartment housing at the bottom In exceptional cases (e.g. shortage of space) the compartment housing may be located at the top Mounting position for point level detection and density measurement...

  • Page 19: Installation Check

    Gammapilot M FMG60 PROFIBUS PA Installation 3.3.2 Required flow rate The required flow rate depends on • the ambient temperature at the water cooling jacket • the inlet temperature • the measuring range of the Gammapilot M Typical values are given in the following tables: Ambient temperature T = 75 °C (167 °F)

  • Page 20: Wiring

    Wiring Gammapilot M FMG60 PROFIBUS PA Wiring Terminal compartments The Gammapilot M has got two terminal compartments: • Terminal compartment 1, for – Power supply – Signal output (depending on the instrument version) • Terminal compartment 2, for – Signal output (depending on the instrument version) –...

  • Page 21: Terminal Assignment

    Gammapilot M FMG60 PROFIBUS PA Wiring Terminal assignment Terminal compartment 1 A0018084 90 to 253VAC, 18 to 36 VDC Terminal compartment 2 SIM WP PT100 11 12 IN CASCADE OUT A0018085 Endress+Hauser...
  • Page 22 Wiring Gammapilot M FMG60 PROFIBUS PA Terminal(s) Meaning Grounding of the cable screen 1, 2 Power supply Compartment 2: Signal output, depending on communication version: 3, 4 • 4-20mA with HART Compartment 1: • PROFIBUS PA ,(4) • Foundation Fieldbus...

  • Page 23: Fieldbus Connectors

    Gammapilot M FMG60 PROFIBUS PA Wiring Terminal compartment for Feature 30 of the ordering information: Power supply wiring/output wiring Supply voltage Signal output Non-Ex; Non-Ex Ex e; Ex ia Ex e; Ex e Ex d (XP); Ex d (XP) Ex d (XP); Ex ia (IS) Dust-Ex;...

  • Page 24: Profibus Pa Cable Specifications

    Wiring Gammapilot M FMG60 PROFIBUS PA PROFIBUS PA cable specifications Twisted, shielded pairs must be used. The following specification must be met for explosion hazardous application (EN 50 020, FISCO model): • Loop-resistance (DC): 15 to 150 /km • Specific inductance: 0.4 to 1 mH/km •...

  • Page 25: Wiring In Terminal Compartment 1

    Gammapilot M FMG60 PROFIBUS PA Wiring Wiring in terminal compartment 1 CAUTION Before connection please note the following: ‣ When using the instrument in hazardous areas, make sure to comply with national standards and the specifications in the Safety Instructions (XAs). Make sure you use the specified cable gland.

  • Page 26: Wiring In Terminal Compartment 2

    Wiring Gammapilot M FMG60 PROFIBUS PA Wiring in terminal compartment 2 CAUTION Before connection please note the following: ‣ Connect potential matching line to transmitter ground terminal and to the ground terminal of the water cooling jacket (if present) before connecting up the instrument ("Potential equalization", ...

  • Page 27: Connecting The Remote Display And Operation Fhx40

    Gammapilot M FMG60 PROFIBUS PA Wiring 4.10 Connecting the remote display and operation FHX40 The remote display and operating unit FHX40 is available as accessory. It is connected to the FHX40-connector of the Gammapilot M via the supplied cable. To do this, the housing of the Gammapilot M needs not to be opened.

  • Page 28: Wiring In Cascading Mode

    Wiring Gammapilot M FMG60 PROFIBUS PA 4.11 Wiring in cascading mode N/L- L1/L+ AC/DC A0018091 Power supply (90 to 253V or 18 to 36V Junction box Master Slave End-Slave NOTICE For the positioning of the power switch according to IEC/EN 61010, there are two options: ‣...

  • Page 29: Measuring Solids Flow

    4.12 Measuring solids flow In conjunction with a density measuring device, such as Endress+Hauser' s "Gammapilot M", Promag 55S also determines the rate of solids with regard to the mass, volume or percentage content. The following order information is required for this purpose for Promag 55S: Order option for software function "Solids flow"...

  • Page 30: Operation

    • With a personal computer, Commubox FXA291 with ToF Adapter FXA291 (USB) and the operating program "FieldCare". FieldCare is a graphical operating software for devices from Endress+Hauser. It assists with commissioning, securing data, signal analysis and documentation of the measuring point.

  • Page 31: Display Operation

    Gammapilot M FMG60 PROFIBUS PA Operation Display operation 5.2.1 Display and operating elements The LCD module VU331 for displaying and operating is inside the remote display and operating unit FHX40. The measured value can be read off through the FHX40 sight glass.
  • Page 32 Operation Gammapilot M FMG60 PROFIBUS PA Function of the keys Key(s) Meaning Navigate upwards in the selection list. Edit numeric value within a function. Navigate downwards in the selection list. Edit numeric value within a function. Navigate to the left within a function group.
  • Page 33 Gammapilot M FMG60 PROFIBUS PA Operation 5.2.2 The operating menu Function code The functions of the Gammapilot M are arranged in an operating menu. To ensure easy orientation within the menu, a unique position code is indicated on the display for each function.
  • Page 34 Operation Gammapilot M FMG60 PROFIBUS PA Operation using the onsite display VU331 ENDRESS + HAUSER E S C – E S C E S C E S C >3 s Basic setup Todays date Isotop Return to group selection Calibration...

  • Page 35: Alternative Operation Options

    FieldCare operating program FieldCare is an Endress+Hauser asset management tool based on FDT technology. With FieldCare, you can configure all Endress+Hauser devices as well as devices from other manufacturers that support the FDT standard. Hardware and software requirements you can find on the internet: www.endress.com...

  • Page 36: Lock/Unlock Configuration

    Operation Gammapilot M FMG60 PROFIBUS PA Lock/unlock configuration 5.4.1 Software security locking Enter a number  2457 into the "unlock parameter" (*A4) function in the "diagnostics" (*A) function group. The symbol appears on the display. Changes are no longer possible.

  • Page 37: Profibus Pa Interface

    Gammapilot M FMG60 PROFIBUS PA Operation PROFIBUS PA interface 5.6.1 Device address Selecting the device address • Every PROFIBUS-PA device must be given an address. If the address is not set correctly, the device will not be recognized by the process control system.
  • Page 38 Operation Gammapilot M FMG60 PROFIBUS PA 5.6.2 Device database and type files (GSD) A device database file (GSD) contains a description of the properties of the PROFIBUS-PA device, e.g. the supported transmission rates and the type and format of the digital information output to the PLC.
  • Page 39 Gammapilot M FMG60 PROFIBUS PA Operation 5.6.3 Cyclic data exchange Block model of the Gammapilot M (*68) (*00) (*63) (*69) (*00) (*A5) (*67) OUT SV (*A7) (*69) A0018602 Measuring signal Sensor; signal evaluation Transducer Block; Parameters that describe the device (calibration, linearisation etc.) Analog Input Function Block;...
  • Page 40 Operation Gammapilot M FMG60 PROFIBUS PA Configuration of the cyclic data telegram Use the configuration software of your PLC in order to compose the data telegram from these modules in one of the following ways: Main value In order to transmit the main measured value, select the module "Main Process Value".
  • Page 41 Gammapilot M FMG60 PROFIBUS PA Operation IEEE-754 Floating Point Number The measured value is transmitted as an IEEE 754 floating point number, whereby (E-127) Measured value = (-1) x (1+F) Byte 1 Byte 2 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0...
  • Page 42 Operation Gammapilot M FMG60 PROFIBUS PA 5.6.4 Acyclic data exchange Acyclic data exchange allows device parameters to be changed independently of the communication between the device and a PLC. Acyclic data exchange is used • to transmit device parameters during commissioning and maintenance;...
  • Page 43 Gammapilot M FMG60 PROFIBUS PA Operation 5.6.5 Slot/index tables Device Management Parameter Menu Slot Index Size Type Read Write Storage position [bytes] Class Dir. Object Header STRING constant Comp. List Dir. Entry STRING constant Analog-Input-Block Parameter Menu Slot Index Size...
  • Page 44 Operation Gammapilot M FMG60 PROFIBUS PA Parameter Menu Slot Index Size Type Read Write Storage position [bytes] Class HI HI Alarm UINT8+ dynamic UINT8+ STRING+ UINT16+ FLOAT HI Alarm UINT8+ dynamic UINT8+ STRING+ UINT16+ FLOAT LO Alarm UINT8+ dynamic UINT8+...
  • Page 45 Gammapilot M FMG60 PROFIBUS PA Operation Parameter Menu Slot Index Size Type Read Write Storage position [bytes] Class Write locking UINT16 static Factory reset UINT16 static Descriptor STRING static Device message STRING static Device instal. date STRING static Ident number select...
  • Page 46 Operation Gammapilot M FMG60 PROFIBUS PA Parameter Menu Slot Index Size Type Read Write Storage position [bytes] Class Present Date (*01) STRING static Present Date Day (*01) UINT8 dynamic Present Date Month (*01) UINT8 dynamic Present Date Year (*01) UINT8...
  • Page 47 Gammapilot M FMG60 PROFIBUS PA Operation Parameter Menu Slot Index Size Type Read Write Storage position [bytes] Class Input Level (*42) FLOAT static Linearisation Start Stop (*43) ENUM static Normal. Pulse Rate (*44) INT32 static Unit Selection (*45) ENUM static...
  • Page 48 Operation Gammapilot M FMG60 PROFIBUS PA Parameter Menu Slot Index Size Type Read Write Storage position [bytes] Class Pres. Avg. Pulse Rate (*A5) INT32 dynamic Avg. Raw Pulse Rate (*A6) INT32 dynamic Medium Temp. (*A7) FLOAT dynamic Density Value (*A8)

  • Page 49: Commissioning

    Gammapilot M FMG60 PROFIBUS PA Commissioning Commissioning NOTICE This chapter describes the commissioning of the Gammapilot M using the operating module VU331 (which is located in the remote display and operating unit FHX40). Commissioning using the "FieldCare" or the "Field Xpert SFX100" is similar. For further instructions to the operating program "FieldCare"...
  • Page 50 Commissioning Gammapilot M FMG60 PROFIBUS PA 6.1.1 Basic setup Step Function Entry or selection Comments See page  ä 55 Present date (*01) e.g. Set day with O and S ; 12.11.04 10:30 Confirm with F; The same applies for month, year,...
  • Page 51 Gammapilot M FMG60 PROFIBUS PA Commissioning 6.1.2 Calibration for level measurement and limit detection NOTICE The fundamentals for calibrating for level measurement and level limit detection are described in "Calibration for level measurement and limit detection",  ä 61. Background calibration For details see "Background calibration", ...
  • Page 52 Commissioning Gammapilot M FMG60 PROFIBUS PA "Empty" or "free" calibration For details see "Full and empty calibration or covered and free calibration",  ä 66. Step Function Action/comments • The radiation remains switched on • Empty tank Level: max. 40%...
  • Page 53 Gammapilot M FMG60 PROFIBUS PA Commissioning 6.1.3 Calibration for density and concentration measurements NOTICE The fundamentals for calibrating for density and concentration measurement are described in "Basic principles",  ä 70. Background calibration For details see "Background calibration",  ä 72.

  • Page 54: Switching On The Device

    Commissioning Gammapilot M FMG60 PROFIBUS PA Switching on the device NOTICE Error messages A165 "electronics defect" and A635 "present date not defined" The Gammapilot M contains 2 real-time clocks for the decay compensation, which are permanently compared to each other for safety reasons. In order to bridge voltage interruptions, the clocks are buffered with a capacitor.

  • Page 55: Basic Setup

    Gammapilot M FMG60 PROFIBUS PA Commissioning Basic setup 6.3.1 "Present date" (*01) On-site display Meaning Present date Date and time of the basic setup are specified in this function. Each of these values must be confirmed by "E" after it has been 17.11.04...
  • Page 56 Commissioning Gammapilot M FMG60 PROFIBUS PA 6.3.4 "Operating mode" (*04) On-site display Meaning Operating mode This function is used to specify in which operating mode the Gammapilot M will be used.  Stand alone Master Slave NOTICE The selection can be performed only once and the function is automatically locked after that.
  • Page 57 Gammapilot M FMG60 PROFIBUS PA Commissioning 6.3.5 "Measurement mode" (*05) On-site display Meaning Meas. mode This function is used to select the desired measuring mode.  Level Limit Density Further options: • Level measurement (continuous) • Level limit detection • Density measurement (with temperature compensation if required) •...
  • Page 58 Commissioning Gammapilot M FMG60 PROFIBUS PA 6.3.6 "Density unit" (*06) On-site display Meaning Density unit This function is needed for density and concentration measure- ments only. It is used to select the density unit.  g/cm3 lb/gal Further options: • g/cm •...
  • Page 59 Gammapilot M FMG60 PROFIBUS PA Commissioning 6.3.10 "Pipe diameter" (*0A) On-site display Meaning Pipe diam. This function is needed for density and concentration measure- ments only. It is used to specify the irradiated measuring path 200 mm L. With standard installation, this value is identical to the inner pipe diameter D .
  • Page 60 Commissioning Gammapilot M FMG60 PROFIBUS PA 6.3.11 "Output damping" (*0B) On-site display Meaning This function is used to specify the output damping (in Output damping seconds) by which changes of the measured value are attenua- 60 s ted. After a surge in the level or density it takes 5 x until the new measured value is reached.

  • Page 61: Calibration For Level Measurement And Limit Detection

    Gammapilot M FMG60 PROFIBUS PA Commissioning Calibration for level measurement and limit detection 6.4.1 Basic principles The calibration points for the measurement are entered in the "calibration" (*1) function group. Each calibration point consists of a level and the associated pulse rate.

  • Page 62: Endress+Hauser

    Commissioning Gammapilot M FMG60 PROFIBUS PA Empty calibration Refers to the following situation: • The radiation is switched on. • Within the measuring range, the vessel is emptied as far as possible (ideally: 0%, maximum 40%). Calibration points for limit detection...

  • Page 63: Endress+Hauser

    That is, not only the level but also the associated pulse rate must be entered by the user. For details concerning the calculation of the count rate please refer to your Endress+Hauser sales organization. NOTICE Calibration date and calibration ‣...

  • Page 64: Endress+Hauser

    Commissioning Gammapilot M FMG60 PROFIBUS PA 6.4.2 Background calibration Excerpt from the operating menu The following excerpt from the operating menu shows how the background calibration is entered. The individual functions are explained in the sections below. Backgr. calibr. avg. pulse rate bgr.

  • Page 65: Endress+Hauser

    Gammapilot M FMG60 PROFIBUS PA Commissioning "Avg. pulse rate" (*11) On-site display Meaning Avg. pulse rate The average pulse rate is displayed in this function (after selec- tion of "start" in the previous function). Initially, this value fluc- 186 cps tuates (because of the decay statistics), but due to the integra- tion it reaches an average value in the course of time.

  • Page 66: Endress+Hauser

    Commissioning Gammapilot M FMG60 PROFIBUS PA 6.4.3 Full and empty calibration or covered and free calibration Excerpt from the operating menu The following excerpt from the operating menu shows how the full and empty calibration (for level measurements) or the covered and free calibration (for level limit detection) are entered.

  • Page 67: Endress+Hauser

    Gammapilot M FMG60 PROFIBUS PA Commissioning "Value full" (*14) / "Value empty" (*17) On-site display Meaning value full These functions are needed for level measurements only. They are used to specify the level at which the full or empty 100% calibration are performed.

  • Page 68: Endress+Hauser

    Commissioning Gammapilot M FMG60 PROFIBUS PA "Avg. pulse rate" (*11) On-site display Meaning avg. pulse rate The average pulse rate is displayed in this function (after selection of "start" in the previous function). Initially, this value 2548 cps fluctuates (because of the decay statistics), but due to the integration it reaches an average value in the course of time.

  • Page 69: Endress+Hauser

    Gammapilot M FMG60 PROFIBUS PA Commissioning "Next point" (*19) On-site display Meaning next point This function is used to specify, if a further calibration point is to be entered or not.  Options: • no This option must be selected after both calibration points have been entered. After this selection the Gammapilot M returns to the group selection and the calibration is completed.

  • Page 70: Calibration For Density And Concentration

    Commissioning Gammapilot M FMG60 PROFIBUS PA Calibration for density and concentration measurements 6.5.1 Basic principles The calibration points for the measurement are entered in the "calibration" (*1) function group. Each calibration point consists of a density value and the associated pulse rate.
  • Page 71 Gammapilot M FMG60 PROFIBUS PA Commissioning Multiple-point calibration The multiple-point calibration is recommended particularly for measurements in a large density area or for especially exact measurements. Up to 9 calibration points can be used about the whole measuring range. The calibration points should be located as far from each other as possible and should be uniformly distributed over the measuring range.
  • Page 72 Commissioning Gammapilot M FMG60 PROFIBUS PA 6.5.2 Background calibration Excerpt from the operating menu The following excerpt from the operating menu shows how the background calibration is entered. The individual functions are explained in the sections below. backgr. calib. avg. pulse rate bgr.
  • Page 73 Gammapilot M FMG60 PROFIBUS PA Commissioning "Avg. pulse rate" (*11) On-site display Meaning avg. pulse rate The average pulse rate is displayed in this function (after selec- tion of "start" in the previous function). 186 cps Initially, this value fluctuates (because of the decay statistics), but due to the integration it reaches an average value in the course of time.
  • Page 74 Commissioning Gammapilot M FMG60 PROFIBUS PA 6.5.3 Calibration points Excerpt from the operating menu The following excerpt from the operating menu shows, how the density calibration points are entered. The individual functions are explained in the sections below. The functions are only accessible after the background calibration has been performed.
  • Page 75 Gammapilot M FMG60 PROFIBUS PA Commissioning "Calibration start stop" (*15) On-site display Meaning calibration This function is used to start the automatic entering of the selected calibration point. stop/edit start Options: • stop/edit This option must be selected if – the calibration point is not to be entered (e.g. because it has already been entered). The pulse rate of the calibration point is then displayed in the following function "density...
  • Page 76 Commissioning Gammapilot M FMG60 PROFIBUS PA "Density calibration" (*1B) On-site display Meaning density calibr. The pulse rate of the respective calibration point is displayed in this function. The display value must be confirmed by pressing 1983 cps "E". "-1" indicates, that no pulse rate is present yet. In this case there are two options: •...
  • Page 77 Gammapilot M FMG60 PROFIBUS PA Commissioning "Absorption coefficient" (*1E) On-site display Meaning absorp. coeff. This function displays the absorption coefficient which results from the currently active calibration points. The displayed 7.70 mm2/g value should be used for plausibility checking. NOTICE If only one calibration point is currently active, the absorption coefficient is not calculated.

  • Page 78: Temperature-Compensated

    Commissioning Gammapilot M FMG60 PROFIBUS PA 6.5.4 Linearization (for concentration measurements) If the concentration is to be measured in a unit other than the "density unit" (*06), a linearization must be performed after the calibration. This can be done in the "Linearization"...

  • Page 79: Maintenance And Repairs

    Repairs to Ex-approved devices When carrying out repairs to Ex-approved devices, please note the following: • Repairs to Ex-approved devices may only be carried out by Endress+Hauser Service in Endress+Hauser workshops. • Comply with the prevailing standards, national Ex-area regulations, safety instructions (XA) and certificates.

  • Page 80: Return

    The measuring device must be returned if repairs of a factory calibration are required, or if the wrong measuring device has been ordered or delivered. According to legal regulations, Endress+Hauser, an ISO-certified company, is required to follow certain procedures when handling returned products that are in contact with medium.

  • Page 81: Accessories

    Commubox FXA291 The Commubox FXA291 connects Endress+Hauser field devices with a CDI interface (Endress+Hauser Common Data Interface) and the USB port of a computer or laptop. For details, see TI00405C/07/EN. For Gammapilot M, you also need the "ToF adapter FXA291" accessory.

  • Page 82: Remote Display Fhx40

    Accessories Gammapilot M FMG60 PROFIBUS PA Remote display FHX40 8.5.1 Dimensions 120 (4.72) 88(3.46) 82 (3.23) 118 (4.65) 96 (3.78) max. 80 (3.15) min. 30 (1.18) mm (in) A0018138 Wall-mounting (without mounting bracket) Gammapilot M Cable Pipe-mounting (mounting bracket and plate supplied optionally)
  • Page 83 Gammapilot M FMG60 PROFIBUS PA Accessories 8.5.3 Technical data (cable and housing) Max. cable length 20 m (66 ft) (fixed length including the cast-on plugs) Temperature range Temperature class T5: -40 to +75 °C (-40 to +167 °F) Temperature class T6: -40 to +60 °C (-40 to +140 °F) Degree of protection IP66 (housing);...

  • Page 84: Mounting Device Fhg60 (For Level Measurement And Level Limit Measurement)

    Accessories Gammapilot M FMG60 PROFIBUS PA Mounting device FHG60 (for level measurement and level limit measurement) 8.6.1 Dimensions 88 (3.46) øD M6x80-A2 M6x20-A2 øC max. 6 Nm 116 (4.57) (4.42 lbf ft) 88 (3.46) 63 (2.48) mm (in) A0018139 Spacing as large as possible ...
  • Page 85 8.6.3 Ordering information Detailed ordering information is available as follows: • In the Product Configurator on the Endress+Hauser website: www.endress.com ➞ Select country ➞ Instruments ➞ Select device ➞ Accessories for FMG60 • From your Endress+Hauser sales center: www.endress.com/worldwide Product Configurator - the tool for individual product configuration •...

  • Page 86: Clamping Device For Density Measurement Fhg61

    Accessories Gammapilot M FMG60 PROFIBUS PA Clamping device for density measurement FHG61 For details, see SD01221F/00/EN. Measurement section for density measurement FHG62 For drawings and description, see SD00540F/00/EN. Endress+Hauser...

  • Page 87: Troubleshooting

    Gammapilot M FMG60 PROFIBUS PA Troubleshooting Troubleshooting System error messages 9.1.1 Error signal Errors occurring during commissioning or operation are signaled in the following way: • Error symbol, error code and error description on the display and operating module • PROFIBUS PA signal: –...

  • Page 88: Error Codes

    A110 checksum error Call Endress+Hauser Service A111 electronics defect Switch instrument off/on; If error still is present: call Endress+Hauser service or exchange transmitter A113 electronics defect Switch instrument off/on; If error still is present: call Endress+Hauser service or exchange transmitter...
  • Page 89 Gammapilot M FMG60 PROFIBUS PA Troubleshooting Code Description Remedy W642 I_back calibration running Calibration of the current readback path active A631 background not calibrated Perform background calibration ("calibration" (*1) function group) A632 full/covered not calibrated Perform full/covered calibration ("calibration" (*1) function group)

  • Page 90: Possible Calibration Errors

    Troubleshooting Gammapilot M FMG60 PROFIBUS PA Possible calibration errors Error Possible cause and remedy Pulse rate too low at • Radiation source switched off  empty vessel Switch on source at the source container • Incorrect alignment of radiation beam ...

  • Page 91: Technical Data

    Gammapilot M FMG60 PROFIBUS PA Technical data Technical data 10.1 Additional technical data For the technical data, please refer to the Technical Information TI00363F/00/EN. 10.2 Documentation This supplementary documentation can be found on our product pages at www.endress.com. • Technical Information (TI00363F/00/EN) •...
  • Page 92 Technical data Gammapilot M FMG60 PROFIBUS PA Certificates Allocation to the option, see the Product Configurator on the Endress+Hauser website: www.endress.com ➞ Select country ➞ Instruments ➞ Select device ➞ Product page function: Configure this product General Approval Type of protection...
  • Page 93 Gammapilot M FMG60 PROFIBUS PA Technical data Approval number: KEMA 04 ATEX 1153 Approval Type of protection Power supply wiring/ Output Approval Feature 010 Output wiring (Communication) number Option 030 Option 040 XA00303F 2, 3 XA00332F II 2(1) G Ex de [ia Ga] IIC T6 Gb...
  • Page 94 Option 040 TIIS Ex d [ia] IIC T6 BA00236F CE mark The measuring system meets the legal requirements of the EC-guidelines. Endress+Hauser confirms the device passing the required tests by attaching the CE-mark. GOST Approval for GOST available. Overfill protection WHG for level limit detection.
  • Page 95 Gammapilot M FMG60 PROFIBUS PA Technical data Endress+Hauser...

  • Page 96: Appendix

    Appendix Gammapilot M FMG60 PROFIBUS PA Appendix 11.1 Operating menu for level measurements beam type isotope operating mode basic setup todays date standard / cont. 137Cs slave dd.mm.yy hh:mm modulated 60 Co end slave no compens. not defined stand alone meas.
  • Page 97 Gammapilot M FMG60 PROFIBUS PA Appendix output damping 1 … 999 s Default: 6 s calibration avg. pulse rate full calibr . start -1: not calibrated stop/edit next point calibration avg. pulse rate empty calibr . start -1: not calibrated...

  • Page 98: Operating Menu For Level Limit Detection

    Appendix Gammapilot M FMG60 PROFIBUS PA 11.2 Operating menu for level limit detection basic setup todays date beam type isotope operating mode dd.mm.yy hh:mm standard / cont. 137Cs slave modulated 60 Co end slave no compens. not defined stand alone meas.
  • Page 99 Gammapilot M FMG60 PROFIBUS PA Appendix output damping 1 … 999 s Default: 6 s calibration avg. pulse rate S1 1 full calibr . start -1: not calibrated stop/edit next point calibration avg. pulse rate S1 1 empty calibr .

  • Page 100: Operating Menu For Density And Concentration

    Appendix Gammapilot M FMG60 PROFIBUS PA 11.3 Operating menu for density and concentration measurements operating mode basic setup todays date beam type isotope slave dd.mm.yy hh:mm standard / cont. 137Cs 60 Co end slave modulated not defined no compens. stand alone meas.
  • Page 101 Gammapilot M FMG60 PROFIBUS PA Appendix Dichteeinheit Min. Dichte Max. Dichte Einh. Rohrdm. Rohrdurchm. Integr .zeit g/cm3 1 … 999 s Werkseinst.: … 60 s nächst. Pkt. Dichteabgl. Dichtewert Abgleichp. Absorp. Koef f. Ref. Pulsrate nicht temperatur- nicht benutzt -1: kein Abgleich...

  • Page 102: Index

    Gammapilot M FMG60 PROFIBUS PA Index Symbols Display operation ......31, 34 Display symbols ........31 *01 - Present date .
  • Page 103 Gammapilot M FMG60 PROFIBUS PA Radiation protection ....... 5 Recalibration ........71 Repair .
  • Page 104 71298583 www.addresses.endress.com...
